7-17
Cisco ONS 15454 Installation and Operations Guide
November 2001
Chapter 7 Card Provisioning
Provisioning Electrical Cards
Step 5 Click Apply.
Thresholds -
Section
CV Coding violations Numeric. Defaults (Near End
only):
10000 (15 minutes)
100000 (1 day)
ES Errored seconds 500 (15 minutes)
5000 (1 day)
SES Severely errored seconds 500 (15 minutes)
5000 (1 day)
SEFS Severely errored framing
seconds
500 (15 minutes)
5000 (1 day)
Thresholds -
Path
CV Coding violations Numeric. Defaults (Near and Far
End):
15 (15 minutes)
125 (1 day)
ES Errored seconds 12 (15 minutes)
100 (1 day)
FC Failure count 10 (15 minutes)
10 (1 day)
SES Severely errored seconds 3 (15 minutes)
7 (1 day)
UAS Unavailable seconds 10 (15 minutes)
10 (1 day)
STS
STS # EC-1 port (Line #) and STS #
available for Intermediate Path
Performance Monitoring.
Enable IPPM Enables IPPM for the EC-1 port
and STS #
Unchecked (default); IPPM not
enabled
Checked; IPPM is enabled
Alarming
Port Port number 1 - 12
Profile Sets the alarm profile for the
port.
Default
Inherited
Custom profiles (if any)
Suppress
Alarms
Suppresses alarm display for the
port.
Unselected (default)
Selected
Table 7-6 EC1-12 Card Parameters (continued)
Subtab Parameter Description Options
