7-14
Cisco ONS 15454 Installation and Operations Guide
November 2001
Chapter 7 Card Provisioning
Provisioning Electrical Cards
Step 5 Click Apply.
Step 6 Repeat Steps 4 – 5 for each subtab that has parameters you want to provision.
7.2.5 EC1-12 Card Parameters
The EC1-12 provides 12 STS-1 electrical ports. Each port operates at 51.840 Mbps. Table 7-6 shows the
parameters for the EC1-12 card.
Procedure: Modify Line and Threshold Settings for the EC-1 Card
Step 1 Display the EC1-12 in CTC card view.
Sonet Thrshld
CV Coding violations Numeric. Defaults (Near/Far End):
• 15 (15 minutes, STS and VT
Term)
• 125 (1 day, STS and VT Term)
ES Errored seconds Numeric. Defaults (Near/Far End):
• 12 (15 minutes, STS and VT
Term)
• 100 (1 day, STS and VT Term)
FC Failure count Numeric. Defaults (Near/Far End):
• 10 (15 minutes, STS Term)
• 10 (1 day, STS Term)
SES Severely errored seconds Numeric. Defaults (Near/Far End):
• 3 (15 minutes, STS and VT Term)
• 7 (1 day, STS and VT Term)
UAS Unavailable seconds Numeric. Defaults (Near/Far End):
• 10 (15 minutes, STS and VT
Term)
• 10 (1 day, STS and VT Term)
Alarming
Port Port number 1 - 6
Profile Sets the alarm profile for the
port
• Default
• Inherited
• Custom profiles (if any)
Suppress
Alarms
Suppresses alarm display for
the port
• Unselected (default)
• Selected
Table 7-5 DS3XM-6 Parameters (continued)
Subtab
Parameter Description Options
