CHAPTER
4-1
Cisco ONS 15454 Installation and Operations Guide
November 2001
4
IP Networking
This chapter explains how to set up Cisco ONS 15454s in internet protocol (IP) networks and includes:
• Scenarios showing Cisco ONS 15454s in common IP network configurations
• Procedures for creating static routes
• Procedures for using the Open Shortest Path First (OSPF) protocol
The chapter does not provide a comprehensive explanation of IP networking concepts and procedures.
Note To set up ONS 15454s within an IP network, you must work with a LAN administrator or other
individual at your site who has IP networking training and experience. To learn more about IP
networking, many outside resources are available. IP Routing Fundamentals, by Mark Sportack
(Cisco Press, 1999), provides a comprehensive introduction to routing concepts and protocols in IP
networks.
4.1 IP Networking Overview
ONS 15454s can be connected in many different ways within an IP environment:
• They can be connected to LANs through direct connections or a router.
• IP Subnetting can create ONS 15454 node groups, which allow you to provision non-DCC
connected nodes in a network.
• Different IP functions and protocols can be used to achieve specific network goals. For example,
Proxy Address Resolution Protocol (ARP) enables one LAN-connected ONS 15454 to serve as a
gateway for ONS 15454s that are not connected to the LAN.
• You can create static routes to enable connections among multiple CTC sessions with ONS 15454s
that reside on the same subnet but have different destination IP addresses.
• If ONS 15454s are connected to OSPF networks, ONS 15454 network information is automatically
communicated across multiple LANs and WANs.
