1-68
Cisco ONS 15454 Installation and Operations Guide
November 2001
Chapter 1 Hardware Installation
ONS 15454 Software and Hardware Compatibility Matrix
1.18 ONS 15454 Software and Hardware Compatibility Matrix
Table 1-12 provides a matrix showing software and hardware compatibility for ONS 15454 Releases 2.0,
2.1, 2.2.0, 3.0. and 3.1.
Power connections are fused properly (15A recommended).
-48V DC (tolerance -42 to -57V DC) power is present at DC A and DC B terminals (if used)
when power is applied.
The fan-tray air filter is installed in the fan tray with the flow direction arrow on the filter
frame pointing up.
The fan-tray assembly is installed. When installed, fans will run on high speed with no
TCC+s installed.
If used, Ethernet patchcords are connected to Ethernet cards.
Fiber-optic and/or Ethernet patchcords route through the faceplate clips, into the
cable-management tray, through the side cutout, and along the sides of the ONS 15454.
The fan-tray assembly can be removed without disturbing fiber or Ethernet patchcords.
The LCD is working. (Use LCD buttons to toggle through slots, ports and states of cards.)
The door is mounted with hinges on hinge pins.
Doors open and close without disturbing fiber or Ethernet patchcords.
Table 1-11 Installation Checklist (continued)
Description Check
Table 1-12 ONS 15454 Software and Hardware Compatibility
Hardware 2.00.0x (2.0) 2.10.0x (2.1) 2.20.0x (2.2.0) 3.00.0x (3.0) 3.10.0x (3.1)
TCC Required Required Fully
Compatible
Not Supported Not Supported
TCC+ Not Supported Not Supported Fully
Compatible
Required Required
XC Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
XCVT Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
XC10G Not Supported Not Supported Not Supported Not Supported Fully
Compatible
AIC Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
EC1-12 Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
DS1-14 Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
DS1N-14 Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
Fully
Compatible
