21-16 DS785UM1
Copyright 2007 Cirrus Logic
I
2
S Controller
EP93xx User’s Guide
2
1
2
1
21
I2STXLinCtrlData
Address:
0x8082_0028 - Read/Write
Default:
0x0000_0000
Definition:
Line Control Data Register
Bit Descriptions:
RSVD: Reserved. Unknown During Read.
Left_Right_Justify: Determines how the data word is justified when being
transmitted on the sdo line output.
0 - left justified.
1 - right justified
TXUF_REPEAT_SAMPLE:On TX underflow, the I
2
S controller transmits all
zeros if this bit is “1”.
If this bit is “0” the I
2
S controller repeats the last sample on
underflow.
TXDIR: Transmit data shift direction.
0 - MSB first
1 - LSB first
I2STXCtrl
Address:
0x8082_002C - Read/Write
Default:
0x0000_0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
1514131211109876543 2 1 0
RSVD Left_Right_Justify TXUF_REPEAT_SAMPLE TXDIR
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
151413121110987654321 0
RSVD TXUFIE TXEMPTY_int_level
