CS61880
20 DS450PP3
TRING2 58 M10 O Transmit Ring Output Port 2
RTIP2 60 M8 I Receive Tip Input Port 2
RRING2 61 L8 I Receive Ring Input Port 2
TTIP3 64 N10 O Transmit Tip Output Port 3
TRING3 63 P10 O Transmit Ring Output Port 3
RTIP3 67 P8 I Receive Tip Input Port 3
RRING3 66 N8 I Receive Ring Input Port 3
TTIP4 117 B10 O Transmit Tip Output Port 4
TRING4 118 A10 O Transmit Ring Output Port 4
RTIP4 120 A8 I Receive Tip Input Port 4
RRING4 121 B8 I Receive Ring Input Port 4
TTIP5 124 D10 O Transmit Tip Output Port 5
TRING5 123 C10 O Transmit Ring Output Port 5
RTIP5 127 C8 I Receive Tip Input Port 5
RRING5 126 D8 I Receive Ring Input Port 5
TTIP6 129 D5 O Transmit Tip Output Port 6
TRING6 130 C5 O Transmit Ring Output Port 6
RTIP6 132 C7 I Receive Tip Input Port 6
RRING6 133 D7 I Receive Ring Input Port 6
TTIP7 136 B5 O Transmit Tip Output Port 7
TRING7 135 A5 O Transmit Ring Output Port 7
RTIP7 139 A7 I Receive Tip Input Port 7
RRING7 138 B7 I Receive Ring Input Port 7
SYMBOL LQFP FBGA TYPE DESCRIPTION
