1. CHARACTERISTICS AND SPECIFICATIONS
• Min / Max characteristics and specifications are guaranteed over the specified operating conditions.
• Typical characteristics and specifications are measured at nominal supply voltages and T
A
= 25°C.
• VLR = 0 V. All voltages measured with respect to 0 V.
ANALOG CHARACTERISTICS T
A
= -40 to +85 °C; V1+ = V2+ = +2.5 V, ±5%; V1- = V2- = -2.5 V,
±5%; VL -VLR = 3.3 V, ±5%; VREF = (VREF+) - (VREF-) = 4.096V; MCLK = 16 MHz; SMODE = VL, unless other-
wise stated; BUFEN = V1+ unless otherwise stated. Connected per Figure 6. Bipolar mode unless otherwise
stated.
1. No missing codes is guaranteed at 16 bits resolution over the specified temperature range.
2. Total drift over specified temperature range after reset at power-up, at 25º C.
3. One LSB is equivalent to VREF ÷ 2
16
or 4.096 ÷ 65536 = 62.5 µV.
4. Scales with MCLK.
Parameter Min Typ Max Unit
Accuracy
Linearity Error - 0.0008 - ±%FS
Differential Linearity Error (Note 1) - - ±0.1 LSB
16
Positive Full-scale Error - 1.0 - %FS
Negative Full-scale Error - 1.0 - %FS
Full-scale Drift (Note 2, 3) - ±1 - LSB
16
Bipolar Offset (Note 3) - ±15 - LSB
16
Bipolar Offset Drift (Note 2, 3) - ±1 - LSB
16
Noise - 140 - µVrms
Dynamic Performance
Peak Harmonic or Spurious Noise 1 kHz, -0.5 dB Input
12 kHz, -0.5 dB Input
-
-
-96
-96
-
-
dB
dB
Total Harmonic Distortion 1 kHz, -0.5 dB Input - -95 -82 dB
Signal-to-Noise 77 80 - dB
S/(N + D) Ratio -0.5 dB Input, 1 kHz
-60 dB Input, 1 kHz
-
-
80
21
-
-
dB
dB
-3 dB Input Bandwidth (Note 4) - 168 - kHz
