CS5560
8 DS713PP2
5/4/09
SWITCHING CHARACTERISTICS (CONTINUED)
T
A
= -40 to +85 °C; V1+ = V2+ = +2.5 V, ±5%; V1- = V2- = -2.5 V, ±5%;
VL - VLR = 3.3 V, ±5%, 2.5 V, ±5%, or 1.8 V, ±5%
Input levels: Logic 0 = 0V = Low; Logic 1 = VD+ = High; CL = 15 pF.
12. SDO and SCLK will be high impedance when CS is high. In some systems it may require a pull-down resistor.
13. SCLK = MCLK/2.
Parameter Symbol Min Typ Max Unit
Serial Port Timing in SSC Mode (SMODE = VL)
Data hold time after SCLK rising t
7
-10-ns
Serial Clock (Out) Pulse Width (low)
(Note 12, 13) Pulse Width (high)
t
8
t
9
50
50
-
-
-
-
ns
ns
RDY
rising after last SCLK rising t
10
-8-MCLKs
CS
falling to MSB stable t
11
-10-ns
First SCLK rising after CS
falling t
12
-8-MCLKs
CS
hold time (low) after SCLK rising t
13
10 - - ns
SCLK, SDO tristate after CS
rising t
14
-5-ns
MCLK
RDY
SCLK(o)
SDO
CS
t
12
t
8
t
13
t
9
t
7
t
11
MSB MSB–1
LSB
LSB+1
t
14
t
10
Figure 2. SSC Mode - Read Timing, CS falling after RDY falls (Not to Scale)
