CS5560
4 DS713PP2
5/4/09
1. CHARACTERISTICS AND SPECIFICATIONS
• Min / Max characteristics and specifications are guaranteed over the specified operating conditions.
• Typical characteristics and specifications are measured at nominal supply voltages and T
A
= 25°C.
• VLR = 0 V. All voltages with respect to 0 V.
ANALOG CHARACTERISTICS T
A
= -40 to +85 °C; V1+ = V2+ = +2.5 V, ±5%; V1- = V2- = -2.5 V,
±5%; VL -VLR = 3.3 V, ±5%; VREF = (VREF+) - (VREF-) = 4.096V; MCLK = 16 MHz; SMODE = VL.
BUFEN = V1+ unless otherwise stated. Connected per Figure 6. Bipolar mode unless otherwise stated.
1. No missing codes is guaranteed at 24 bits resolution over the specified temperature range.
2. One LSB is equivalent to (2 x VREF) ÷ 2
24
or (2 x 4.096) ÷ 16,777,216 = 488 nV.
3. Scales with MCLK.
Parameter Min Typ Max Unit
Accuracy
Linearity Error - 0.0005 - ±%FS
Differential Linearity Error (Note 1, 2) - ±0.1 - LSB
24
Positive Full-scale Error - 1.0 - %FS
Negative Full-scale Error - 1.0 - %FS
Full-scale Drift (Note 2) - 1 - ppm / °C
Unipolar Offset (Note 2) - +2000 - LSB
24
Unipolar Offset Drift (Note 2) - 2 - LSB / °C
Bipolar Offset (Note 2) - ±1000 - LSB
24
Bipolar Offset Drift (Note 2) - 1 - LSB / °C
Noise - 9.5 - μVrms
Dynamic Performance
Peak Harmonic or Spurious Noise 997 Hz, -0.5 dB Input - -111 - dB
Total Harmonic Distortion 997 Hz, -0.5 dB Input - -108 -95 dB
Signal-to-Noise 108 110 - dB
S/(N + D) Ratio -0.5 dB Input, 997 Hz
-60 dB Input, 997 Hz
95
-
109
50
-
-
dB
dB
-3 dB Input Bandwidth (Note 3) - 42 - kHz
