CS5560
30 DS713PP2
5/4/09
SCLK – Serial Clock Input/Output, Pin 23
The SMODE pin determines whether the SCLK signal is an input or an output signal. SCLK
determines the rate at which data is clocked out of the SDO pin. If the converter is in SSC
mode, the SCLK frequency will be determined by the master clock frequency of the converter
(either MCLK or the internal oscillator). In SEC mode, the user determines the SCLK frequency.
If SMODE = VL (SSC Mode), SCLK will be in a high-impedance state when CS
is high.
RDY
– Ready, Pin 24
At the end of any conversion RDY
falls to indicate that a conversion word has been placed into
the serial port. RDY
will return high after all data bits are shifted out of the serial port or two mas-
ter clock cycles before new data becomes available if the CS
pin is inactive (high); or two mas-
ter clock cycles before new data becomes available if the user holds CS
low but has not started
reading the data from the converter when in SEC mode.
