CS5560

±2.5 V / 5 V, 50 kSps, 24-bit, High-throughput

ΔΣ

ADC

Features & Description

 Differential Analog Input

 On-chip Buffers for High Input Impedance

 Conversion Time = 20 μS

 Settles in One Conversion

 Linearity Error = 0.0005%

 Signal-to-Noise = 110 dB

 24 Bits, No Missing Codes

 Simple three/four-wire serial interface

 Power Supply Configurations:

- Analog: +5 V / GND; IO: +1.8 V to +3.3 V

- Analog: ±2.5 V; IO: +1.8 V to +3.3 V

 Power Consumption:

- ADC Input Buffers On: 90 mW

- ADC Input Buffers Off: 60 mW

General Description

The CS5560 is a single-channel, 24-bit analog-to-digital

converter capable of 50 kSps conversion rate. The input

accepts a fully differential analog input signal. On-chip

buffers provide high input impedance for both the AIN in-

puts and the VREF+ input. This significantly reduces the

drive requirements of signal sources and reduces errors

due to source impedances. The CS5560 is a delta-sigma

converter capable of switching multiple input channels at

a high rate with no loss in throughput. The ADC uses a

low-latency digital filter architecture. The filter is designed

for fast settling and settles to full accuracy in one conver-

sion. The converter's 24-bit data output is in serial form,

with the serial port acting as either a master or a slave. The

converter is designed to support bipolar, ground-refer-

enced signals when operated from ±2.5V analog supplies.

The converter can operate from an analog supply of 0-5V

or from ±2.5V. The digital interface supports standard log-

ic operating from 1.8, 2.5, or 3.3 V.

ORDERING INFORMATION:

See Ordering Information on page 32.

AIN+

AIN-

SCLK

SMODE

VREF+

VREF-

RDY

OSC/CLOCK

GENERATOR

CONV

BP/UP

DIGITAL CONTROL

SERIAL

INTERFACE

ADC

DIGITAL

FILTER

LOGIC

MCLK

SDO

RST

SLEEP

VLR

VLR2

V1-

V2-

BUFEN

V2+

V1+

CS5560

TST

DCR

MAY ‘09

DS713PP2
