18 DS734F5
6 Ordering Information
6 Ordering Information
The CS485xx family part number is CS485NI-XYZR where:
• N–Product Number Variant
• I–ROM ID Number
• X–Product Grade
• Y–Package Type
• Z–Lead (Pb) Free
• R–Tape and Reel Packaging
Note: Contact the factory for availability of the automotive grade package.
7 Environmental, Manufacturing, and Handling Information
Table 6-1. Ordering Information
Part No. Grade Temp. Range Package
CS48520-CQZ Commercial 0 to +70° C 48-pin LQFP
CS48540-CQZ Commercial 0 to +70° C
CS48540-DQZ Automotive –40 to +85° C
CS48560-CQZ Commercial 0 to +70° C
CS48560-DQZ Automotive –40 to +85° C
Table 7-1. Environmental, Manufacturing, and Handling Information
Model Number Peak Reflow Temp
MSL Rating
1
1.MSL (Moisture Sensitivity Level) as specified by IPC/JEDEC J-STD-020.
Max Floor Life
CS48520-CQZ 260° C 3 7 days
CS48540-CQZ
CS48540-DQZ
CS48560-CQZ
CS48560-DQZ
