6.35.3 Noise Gate Threshold and Boost
THRESH sets the threshold level of the noise gate. Input signals below the threshold level will be attenu-
ated to -96 dB. NG_BOOST configures a +30 dB boost to the threshold settings.
6.35.4 Noise Gate Delay Timing
Sets the delay time before the noise gate attacks.
Note: The Noise Gate attack rate is a function of the sampling frequency, Fs, and the ANLGSFTx (“Ch.
x Analog Soft Ramp” on page 49) and ANLGZCx (“Ch. x Analog Zero Cross” on page 49) setting unless
the respective disable bit (“ALCx Soft Ramp Disable” on page 55 or “ALCx Zero Cross Disable” on
page 56) is enabled.
6.36 Status (Address 2Eh) (Read Only)
For all bits in this register, a “1” means the associated error condition has occurred at least once since the
register was last read. A”0” means the associated error condition has NOT occurred since the last reading
of the register. Reading the register resets all bits to 0.
6.36.1 Serial Port Clock Error (Read Only)
Indicates the status of the MCLK to LRCK ratio.
Note: On initial power up and application of clocks, this bit will report 1 as the serial port re-synchroniz-
es.
THRESH[2:0] Minimum Setting (NG_BOOST = 0) Minimum Setting (NG_BOOST = 1)
000 -64 dB -34 dB
001 -67 dB -37 dB
010 -70 dB -40 dB
011 -73 dB -43 dB
100 -76 dB -46 dB
101 -82 dB -52 dB
110 Reserved -58 dB
111 Reserved -64 dB
Application: “Noise Gate” on page 27
NGDELAY[1:0] Delay Setting
00 50 ms
01 100 ms
10 150 ms
11 200 ms
Application: “Noise Gate” on page 27
76543210
Reserved SPCLKERR DSPAOVFL DSPBOVFL PCMAOVFL PCMBOVFL ADCAOVFL ADCBOVFL
SPCLKERR Serial Port Clock Status:
0 MCLK/LRCK ratio is valid.
1 MCLK/LRCK ratio is not valid.
Application: “Serial Port Clocking” on page 33
