DS680F2 61
CS42L52
3/1/13
6.22.2 Beep Volume
Sets the volume of the beep signal.
Note: This setting must not change when BEEP is enabled.
6.23 Beep and Tone Configuration (Address 1Eh)
6.23.1 Beep Configuration
Configures a beep mixed with the HP/Line and SPK output.
Notes:
1. When used in analog pass-through mode, the output alternates between the signal from the PGA and
the beep signal. The beep signal does not mix with the analog signal from the PGA.
2. Re-engaging the beep before it has completed its initial cycle will cause the beep signal to remain ON
for the maximum ONTIME duration.
6.23.2 Beep Mix Disable
Configures how the beep mixes with the serial data input.
Note: This setting must not change when BEEP is enabled.
BEEPVOL[4:0] Gain
00110 +6.0 dB
··· ···
00000 -6 dB
11111 -8 dB
11110 -10 dB
··· ···
00111 -56 dB
Step Size: 2 dB
Application: “Beep Generator” on page 29
76543210
BEEP1 BEEP0 BEEPMIXDIS TREBCF1 TREBCF0 BASSCF1 BASSCF0 TCEN
BEEP[1:0] Beep Occurrence
00 Off
01 Single
10 Multiple
11 Continuous
Application: “Beep Generator” on page 29
BEEPMIXDIS Beep Output to HP/Line and Speaker
0 Mix Enabled; The beep signal mixes with the digital signal from the serial data input.
1
Mix Disabled; The output alternates between the signal from the serial data input and the beep signal. The
beep signal does not mix with the digital signal from the serial data input.
Application: “Beep Generator” on page 29
