58 DS680F2
CS42L52
3/1/13
6.19 ADCx Mixer Volume: ADCA (Address 18h) and ADCB (Address 19h)
6.19.1 ADC Mixer Channel x Mute
Configures a digital mute on the ADC mix in the DSP.
6.19.2 ADC Mixer Channel x Volume
Sets the volume/gain of the ADC mix in the DSP.
6.20 PCMx Mixer Volume: PCMA (Address 1Ah) and PCMB (Address 1Bh)
6.20.1 PCM Mixer Channel x Mute
Configures a digital mute on the PCM mix from the serial data input (SDIN) to the DSP.
6.20.2 PCM Mixer Channel x Volume
Sets the volume/gain of the PCM mix from the serial data input (SDIN) to the DSP.
76543210
AMIXxMUTE AMIXxVOL6 AMIXxVOL5 AMIXxVOL4 AMIXxVOL3 AMIXxVOL2 AMIXxVOL1 AMIXxVOL0
AMIXxMUTE ADC Mixer Mute
0 Disabled
1 Enabled
AMIXxVOL[6:0] Volume
001 1000 +12.0 dB
... ...
000 0001 +0.5 dB
000 0000 0 dB
111 1111 -0.5 dB
... ...
001 1001 -51.5 dB
Step Size: 0.5 dB
76543210
PMIXxMUTE PMIXxVOL6 PMIXxVOL5 PMIXxVOL4 PMIXxVOL3 PMIXxVOL2 PMIXxVOL1 PMIXxVOL0
PMIXxMUTE PCM Mixer Mute
0 Disabled
1 Enabled
PMIXxVOL[6:0] Volume
001 1000 +12.0 dB
... ...
000 0001 +0.5 dB
000 0000 0 dB
111 1111 -0.5 dB
... ...
001 1001 -51.5 dB
Step Size: 0.5 dB
