54 DS680F2
CS42L52
3/1/13
6.14 Playback Control 2 (Address 0Fh)
6.14.1 Headphone Mute
Configures a digital mute on headphone channel x.
6.14.2 Speaker Mute
Configures a digital mute on speaker channel x.
6.14.3 Speaker Volume Setting B=A
Configures independent or ganged volume control of the speaker output.
6.14.4 Speaker Channel Swap
Configures a channel swap on the speaker channels.
6.14.5 Speaker MONO Control
Configures a parallel full-bridge output for the speaker channels.
6.14.6 Speaker Mute 50/50 Control
Configures how the speaker channels mute.
76543210
HPBMUTE HPAMUTE SPKBMUTE SPKAMUTE SPKB=A SPKSWAP SPKMONO MUTE50/50
HPxMUTE Headphone Mute
0 Disabled
1 Enabled
SPKxMUTE Speaker Mute
0 Disabled
1 Enabled
SPKB=A Single Volume Control Affected Volume Controls
0 Disabled
SPKxMUTE (“Speaker Mute” on page 54),
SPKxVOL[7:0] (“Speaker Volume Control” on page 64)
1 Enabled
SPKSWAP Speaker Output
0 Channel A
1 Channel B
Application: “Mono Speaker Output Configuration” on page 32
SPKMONO Parallel Full Bridge Output
0 Disabled
1 Enabled
Application: “Mono Speaker Output Configuration” on page 32
MUTE50/50 Speaker Mute 50/50
0 Disabled; The PWM amplifiers outputs modulated silence when SPKxMUTE is enabled.
1
Enabled; The PWM amplifiers switch at an exact 50%-duty-cycle signal (not modulated) when SPKxMUTE is
enabled.
