48 DS680F2
CS42L52
3/1/13
6.7.3 Tri-State Serial Port Interface
Determines the state of the serial port drivers.
Notes:
1. Slave/Master Mode is determined by the M/S
bit in “Master/Slave Mode” on page 46.
2. When the serial port is tri-stated in master mode, the ADC and DAC serial ports are clocked internally.
6.7.4 Speaker/Headphone Switch Invert
Determines the control signal polarity of the SPK/HP_SW pin.
6.7.5 MIC Bias Level
Sets the output voltage level on the MICBIAS output pin.
6.8 Input x Select: ADCA and PGAA (Address 08h), ADCB and PGAB (Address 09h)
6.8.1 ADC Input Select
Selects the specified analog input signal into ADCx.
3ST_SP
Serial Port Status
Slave Mode Master Mode
0 Serial Port clocks are inputs and SDOUT is output Serial Port clocks and SDOUT are outputs
1 Serial Port clocks are inputs and SDOUT is HI-Z Serial Port clocks and SDOUT are HI-Z
INV_SWCH SPK/HP_SW pin 6 Control
0 Not inverted
1 Inverted
BIASLVL[2:0] Output Bias Level
000 0.5 x VA
001 0.6 x VA
010 0.7 x VA
011 0.8 x VA
100 0.83 x VA
101 0.91 x VA
110 Reserved
111 Reserved
7 6 5 4 3210
ADCASEL2 ADCASEL1 ADCASEL0 PGAASEL5 PGAASEL4 PGAASEL3 PGAASEL2 PGAASEL1
ADCxSEL[2:0] Selected Input to ADCx
000 AIN1x
001 AIN2x
010 AIN3x
011 AIN4x
100 PGAx - Use PGAxSEL bits (“PGA Input Mapping” on page 49) to select input channels
101 Reserved
110 Reserved
111 Reserved
Application: “Analog Inputs” on page 25
