6.6.5 DAC Interface Format
Configures the digital interface format for data on SDIN.
Note: Select the audio word length for Right Justified using the AWL[1:0] bits (“Audio Word Length” on
page 47).
6.6.6 Audio Word Length
Configures the audio sample word length used for the data into SDIN and out of SDOUT.
Note: When the internal MCLK/LRCK ratio is set to 125 in master mode, the 32-bit data width option
for DSP Mode is not valid unless SCLK=MCLK.
6.7 Interface Control 2 (Address 07h)
6.7.1 SCLK equals MCLK
Configures the SCLK signal source for master mode.
Note: This bit is only valid for MCLK = 12.0000 MHz.
6.7.2 SDOUT to SDIN Digital Loopback
Configures an internal loops the signal on the SDOUT pin to SDIN.
DACDIF[1:0] DAC Interface Format
00 Left Justified, up to 24-bit data
01 I²S, up to 24-bit data
10 Right Justified
11 Reserved
Application: “Digital Interface Formats” on page 35
AWL[1:0]
Audio Word Length
DSP Mode Right Justified (DAC ONLY)
00 32-bit data 24-bit data
01 24-bit data 20-bit data
10 20-bit data 18-bit data
11 16-bit data 16-bit data
Application: “DSP Mode” on page 35
765432 1 0
Reserved SCLK=MCLK DIGLOOP 3ST_SP INV_SWCH BIASLVL2 BIASLVL1 BIASLVL0
SCLK=MCLK Output SCLK
0 Re-timed signal, synchronously derived from MCLK
1 Non-retimed, MCLK signal
DIGLOOP Internal Loopback
0 Disabled; SDOUT internally disconnected from SDIN
1 Enabled; SDOUT internally connected to SDIN
