46 DS680F2
CS42L52
3/1/13
6.5.6 MCLK Divide By 2
Divides the input MCLK by 2 prior to all internal circuitry.
Note: In slave mode, this bit is ignored when the AUTO bit (“Auto-Detect” on page 44) is disabled.
6.6 Interface Control 1 (Address 06h)
6.6.1 Master/Slave Mode
Configures the serial port I/O clocking.
6.6.2 SCLK Polarity
Configures the polarity of the SCLK signal.
6.6.3 ADC Interface Format
Configures the digital interface format for data on SDOUT.
6.6.4 DSP Mode
Configures a data-packed interface format for both the ADC and DAC.
Notes:
1. Select the audio word length using the AWL[1:0] bits (“Audio Word Length” on page 47).
2. The interface format for both the ADC and the DAC must be set to “Left-Justified” when DSP Mode
is enabled.
MCLKDIV2 MCLK signal into CODEC
0 No divide
1 Divided by 2
Application: “Serial Port Clocking” on page 33
76543210
M/S
INV_SCLK ADCDIF DSP DACDIF1 DACDIF0 AWL1 AWL0
M/S Serial Port Clocks
0 Slave (input ONLY)
1 Master (output ONLY)
INV_SCLK SCLK Polarity
0 Not Inverted
1 Inverted
ADCDIF ADC Interface Format
0 Left Justified
1I²S
Application: “Digital Interface Formats” on page 35
DSP DSP Mode
0 Disabled
1 Enabled
Application: “DSP Mode” on page 35
