DS680F2 45
CS42L52
3/1/13
6.5.2 Speed Mode
Configures the speed mode of the CODEC in slave mode and sets the appropriate MCLK divide ratio for
LRCK and SCLK in master mode.
Notes:
1. Slave/Master Mode is determined by the M/S
bit in “Master/Slave Mode” on page 46.
2. Certain sample and MCLK frequencies require setting the SPEED[1:0] bits, the 32k_GROUP bit
(“32kHz Sample Rate Group” on page 45) and/or the VIDEOCLK bit (“27 MHz Video Clock” on
page 45) and RATIO[1:0] bits (“Internal MCLK/LRCK Ratio” on page 45). Low sample rates may also
affect dynamic range performance in the typical audio band. Refer to the referenced application for
more information.
3. These bits are ignored when the AUTO bit (“Auto-Detect” on page 44) is enabled.
6.5.3 32kHz Sample Rate Group
Specifies whether or not the input/output sample rate is 8 kHz, 16 kHz or 32 kHz.
6.5.4 27 MHz Video Clock
Specifies whether or not the external MCLK frequency is 27 MHz
6.5.5 Internal MCLK/LRCK Ratio
Configures the internal MCLK/LRCK ratio.
SPEED[1:0]
Slave Mode Master Mode
Serial Port Speed MCLK/LRCK Ratio SCLK/LRCK Ratio
00 Double-Speed Mode (DSM - 50 kHz -100 kHz Fs) 128 64
01 Single-Speed Mode (SSM - 4 kHz -50 kHz Fs) 256 64
10 Half-Speed Mode (HSM - 12.5kHz -25 kHz Fs) 512 64
11 Quarter-Speed Mode (QSM - 4 kHz -12.5 kHz Fs)
1024
64
Application: “Serial Port Clocking” on page 33
32kGROUP 8 kHz, 16 kHz or 32 kHz sample rate?
0 No
1Yes
Application: “Serial Port Clocking” on page 33
VIDEOCLK 27 MHz MCLK?
0 No
1Yes
Application: “Serial Port Clocking” on page 33
RATIO[1:0] Internal MCLK Cycles per LRCK SCLK/LRCK Ratio in Master Mode
00 128 64
01 125 62
10 132 66
11 136 68
Application: “Serial Port Clocking” on page 33
