6. REGISTER DESCRIPTION
All registers are read/write except for the Chip I.D. and Revision Register and Interrupt Status Register, which are
read only. See the following bit definition tables for bit assignment information. The default state of each bit after a
power-up sequence or reset is listed in each bit description. Unless otherwise specified, all “Reserved” bits must
maintain their default value.
6.1 Chip I.D. and Revision Register (Address 01h) (Read Only)
6.1.1 Chip I.D. (Read Only)
I.D. code for the CS42L52.
6.1.2 Chip Revision (Read Only)
CS42L52 revision level.
6.2 Power Control 1 (Address 02h)
6.2.1 Power Down ADC Charge Pump
Configures the power state of the ADC charge pump.
6.2.2 Power Down PGAx
Configures the power state of PGA channel x.
Notes:
1. The CS42L52 employs a scheme for controlling the power to the PGA when PASSTHRU (“Passthrough
Analog” on page 52) is enabled. Refer to the referenced application for more information.
2. This bit should be used in conjunction with ADCxSEL and PGAxSEL bits to determine the analog
76543210
CHIPID4 CHIPID3 CHIPID2 CHIPID1 CHIPID0 REVID2 REVID1 REVID0
CHIPID[4:0] Device
11100 CS42L52
REVID[2:0] Revision Level
000 A0
001 A1
010 B0
011 B1
76543210
PDN_CHRG Reserved Reserved PDN_PGAB PDN_PGAA PDN_ADCB PDN_ADCA PDN
PDN_CHRG ADC Charge Pump Status
0 Powered Up
1 Powered Down
PDN_PGAx PGA Status
0 Powered Up (ONLY when the ADC or the analog passthru is used)
1 Powered Down
Application “Analog In to Analog Out Passthrough” on page 31
