34 DS680F2
CS42L52
3/1/13
input master clock (MCLK) in Master Mode. Refer to the tables below for the required setting in register 05h
and 06h associated with a given MCLK and sample rate.
Referenced Control Register Location
M/S
Register 05h
Register 06h
“Master/Slave Mode” on page 46
“Clocking Control (Address 05h)” on page 44
“Interface Control 1 (Address 06h)” on page 46
MCLK
(MHz)
Sample Rate,
Fs (kHz)
SPEED[1:0]
(AUTO=’0’b)
32kGROUP VIDEOCLK RATIO[1:0] MCLKDIV2
12.2880
8.0000 11 1 0 00 0
12.0000 11 0 0 00 0
16.0000 10 1 0 00 0
24.0000 10 0 0 00 0
32.0000 01 1 0 00 0
48.0000 01 0 0 00 0
96.0000 00 0 0 00 0
11.2896
11.0250 11 0 0 00 0
22.0500 10 0 0 00 0
44.1000 01 0 0 00 0
88.2000 00 0 0 00 0
18.4320
(Slave
Mode
ONLY)
8.0000 11 1 0 00 0
12.0000 11 0 0 00 0
16.0000 10 1 0 00 0
24.0000 10 0 0 00 0
32.0000 01 1 0 00 0
48.0000 01 0 0 00 0
96.0000 00 0 0 00 0
16.9344
(Slave
Mode
ONLY)
8.0182 11 0 0 10 0
11.0250 11 0 0 00 0
22.0500 10 0 0 00 0
44.1000 01 0 0 00 0
88.2000 00 0 0 00 0
12.0000
8.0000 11 1 0 01 0
11.029411 0 0110
12.0000 11 0 0 01 0
16.0000 10 1 0 01 0
22.0588 10 0 0 11 0
24.0000 10 0 0 01 0
32.0000 01 1 0 01 0
44.1176 01 0 0 11 0
48.0000 01 0 0 01 0
88.2353 00 0 0 11 0
96.0000 00 0 0 01 0
24.0000
8.0000 11 1 0 01 1
11.029411 0 0111
12.0000 11 0 0 01 1
16.0000 10 1 0 01 1
22.0588 10 0 0 11 1
24.0000 10 0 0 01 1
32.0000 01 1 0 01 1
44.1176 01 0 0 11 1
48.0000 01 0 0 01 1
88.2353 00 0 0 11 1
96.0000 00 0 0 01 1
Table 1. MCLK, LRCK Quick Decode
