POWER CONSUMPTION See (Note 20).
20. Unless otherwise noted, test conditions are as follows: All zeros input, slave mode, sample
rate = 48 kHz; No load. Digital (VD) and logic (VL) supply current will vary depending on speed mode
and master/slave operation. “Required Initialization Settings” on page 37 written on power up.
21. RESET
pin 25 held LO, all clocks and data lines are held LO.
22. RESET
pin 25 held HI, all clocks and data lines are held HI.
23. VL current will slightly increase in master mode.
Power Ctl. Registers Typical Current (mA)
Operation
02h 03h 04h
PDN_PGAB PDN_PGAA PDN_ADCB PDN_ADCA PDN PDN_MICB PDN_MICA PDN_MICBIAS PDN_HPB[1:0] PDN_HPA[1:0] PDN_SPKB[1:0] PDN_SPKA[1:0]
V
i
VHP
i
VA
i
VD
i
VL
VL=3.3V
(Note 23)
i
VP
VP=3.7V
Total
Power
(mW
rms
)
1
Off (Note 21)
xxxxxxxxx x x x
1.8 0.00 0.00 0.00
0.00 0.00
0.00
2.5 0.00 0.00 0.00 0.00
2
Standby (Note 22) xxxx1xxxx x x x
1.8 0.00 0.00 0.01
0.00 0.00
0.02
2.5 0.00 0.00 0.02 0.05
3
Mono Record ADC 1 110011111111111
1.8 0.00 1.67 2.32
0.03 0.00
7.24
2.5 0.00 1.87 3.72 14.05
PGA to ADC1010011111111111
1.8 0.00 2.1 2.31
0.03 0.00
7.99
2.5 0.00 2.3 3.72 15.13
MIC to PGA to ADC
(with Bias)
1010010011111111
1.8 0.00 3.48 2.32
0.03 0.00
10.49
2.5 0.00 3.71 3.72 18.65
MIC to PGA to ADC
(no Bias)
1010010111111111
1.8 0.00 3.15 2.32
0.03 0.00
9.90
2.5 0.00 3.37 3.73 17.83
4
Stereo Record ADC1100011111111111
1.8 0.00 2.31 2.37
0.03 0.00
8.48
2.5 0.00 2.53 3.82 15.95
PGA to ADC0000011111111111
1.8 0.00 3.18 2.37
0.03 0.00
10.04
2.5 0.00 3.42 3.81 18.15
MIC to PGA to ADC
(no Bias)
0000000111111111
1.8 0.00 5.32 2.37
0.03 0.00
13.90
2.5 0.00 5.57 3.81 23.53
5
Mono Playback to Headphone 1 111011110111111
1.8 1.59 1.99 2.72
0.01 0.00
11.36
2.5 2.07 2.62 4.27 22.43
6
Mono Playback to Speaker 1 111011111111010
1.8 0.00 0.20 4.42
0.01 1.00
12.05
2.5 0.00 0.22 6.77 21.21
7
Stereo Playback to Headphone 1 111011110101111
1.8 2.77 2.00 2.91
0.01 0.00
13.84
2.5 3.27 2.63 4.28 25.48
8
Stereo Playback to Speaker 1111011111111010
1.8 0.00 0.20 4.38
0.01 1.00
11.98
2.5 0.00 0.22 6.80 21.28
9
Stereo Passthrough to Head-
phone
1111011110101111
1.8 2.79 1.91 1.06
0.01 0.00
10.39
2.5 3.18 2.14 1.81 17.85
10
Mono Record and Playback
PGA in (no MIC) to Mono HP
1010011111101111
1.8 1.77 3.95 4.28
0.03 0.00
18.05
2.5 2.13 4.77 6.63 33.90
11
Phone Monitor
MIC (w/bias) in to Mono Out
1010010011101111
1.8 1.76 5.33 4.28
0.03 0.00
20.52
2.5 2.15 6.19 6.69 37.65
12
Stereo Record and Playback
PGA in (no MIC) to St. HP Out
0000011110101111
1.8 2.76 5.05 4.64
0.03 0.00
22.46
2.5 3.21 5.90 7.17 40.78
13
Stereo Rec. and Full Playback
PGA (no MIC) to St. HP and SPK
0000011110101010
1.8 3.49 5.24 7.20
0.03 1.00
32.47
2.5 3.95 6.10 10.46 55.07
