14 DS680F2
CS42L52
3/1/13
ADC DIGITAL FILTER CHARACTERISTICS
5. Response is clock-dependent and will scale with Fs. Note that the response plots (Figures 26 to 29 on
page 78) have been normalized to Fs and can be de-normalized by multiplying the X-axis scale by Fs.
HPF parameters are for Fs = 48 kHz.
Parameters (Note 5) Min Typ Max Unit
Passband (Frequency Response) to -0.1 dB corner 0 - 0.4948 Fs
Passband Ripple -0.09 - 0.17 dB
Stopband 0.6 - - Fs
Stopband Attenuation 33 - - dB
Total Group Delay -7.6/Fs- s
High-Pass Filter Characteristics (48 kHz Fs)
Frequency Response -3.0 dB
-0.13 dB
-
-
3.6
24.2
-
-
Hz
Hz
Phase Deviation @ 20 Hz - 10 - Deg
Passband Ripple - - 0.17 dB
Filter Settling Time -10
5
/Fs 0 s
