44 DS583F2
CS42516
2Eh
RXP2/GPO
2
Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0
page 69
default
0 0 00000 0
2Fh
RXP1/GPO
1
Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0
page 69
default
0 0 00000 0
30h
Q Subcode
Address3 Address2 Address1 Address0 Control3 Control2 Control1 Control0
page 71
default
XXXXXXX X
31h
Q Subcode
Track7 Track6 Track5 Track4 Track3 Track2 Track1 Track0
page 71
default
XXXXXXX X
32h
Q Subcode
Index7 Index6 Index5 Index4 Index3 Index2 Index1 Index0
page 71
default
XXXXXXX X
33h
Q Subcode
Minute7 Minute6 Minute5 Minute4 Minute3 Minute2 Minute1 Minute0
page 71
default
XXXXXXX X
34h
Q Subcode
Second7 Second6 Second5 Second4 Second3 Second2 Second1 Second0
page 71
default
XXXXXXX X
35h
Q Subcode
Frame7 Frame6 Frame5 Frame4 Frame3 Frame2 Frame1 Frame0
page 71
default
XXXXXXX X
36h
Q Subcode
Zero7 Zero6 Zero5 Zero4 Zero3 Zero2 Zero1 Zero0
page 71
default
XXXXXXX X
37h
Q Subcode
A.Minute7 A.Minute6 A.Minute5 A.Minute4 A.Minute3 A.Minute2 A.Minute1 A.Minute0
page 71
default
XXXXXXX X
38h
Q Subcode
A.Second7 A.Second6 A.Second5 A.Second4 A.Second3 A.Second2 A.Second1 A.Second0
page 71
default
XXXXXXX X
39h
Q Subcode
A.Frame7 A.Frame6 A.Frame5 A.Frame4 A.Frame3 A.Frame2 A.Frame1 A.Frame0
page 71
default
XXXXXXX X
3Ah -
C or U Data
Buffer
CU Buffer7 CU Buffer6 CU Buffer5 CU Buffer4 CU Buffer3 CU Buffer2 CU Buffer1 CU Buffer0
51h
page 71
default
XXXXXXX X
Addr Function 7 6 5 4 3 2 1 0
