DS583F2 43
CS42516
1Fh
RCVR Mode
Ctrl 2
Reserved TMUX2 TMUX1 TMUX0 Reserved RMUX2 RMUX1 RMUX0
page 63
default
0 0 00000 0
20h
Interrupt
Status
UNLOCK Reserved QCH DETC DETU Reserved OverFlow RERR
page 63
default
XXXXXXX X
21h
Interrupt
Mask
UNLOCKM Reserved QCHM DETCM DETUM Reserved OverFlowM RERRM
page 64
default
0 0 00000 0
22h
Interrupt
Mode MSB
UNLOCK1 Reserved QCH1 DETC1 DETU1 Reserved OF1 RERR1
page 65
default
0 0 00000 0
23h
Interrupt
Mode LSB
UNLOCK0 Reserved QCH0 DETC0 DETU0 Reserved OF0 RERR0
page 65
default
0 0 00000 0
24h
Buffer Ctrl
LOCKM1 LOCKM0 Reserved Reserved Reserved BSEL CAM CHS
page 65
default
0 1 00000 0
25h RCVR CS
Data.
AUX3 AUX2 AUX1 AUX0 PRO AUDIO
COPY ORIG
page 66.
default
0 0 00000 0
26h
RCVR
Errors
Reserved QCRC CCRC UNLOCK V CONF BIP PAR
page 67
default
0 0 00000 0
27h
RCVR
Errors Mask
Reserved QCRCM CCRCM UNLOCKM VM CONFM BIPM PARM
page 68
default
0 0 00000 0
28h
MUTEC
Reserved Reserved MCPolarity M_AOUTA1 M_AOUTB1 M_AOUTA2
M_AOUTB2
M_AOUTA3
M_AOUTB3
Reserved
page 69
default
0 0 01111 1
29h
RXP7/GPO
7
Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0
page 69
default
0 0 00000 0
2Ah
RXP6/GPO
6
Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0
page 69
default
0 0 00000 0
2Bh
RXP5/GPO
5
Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0
page 69
default
0 0 00000 0
2Ch
RXP4/GPO
4
Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0
page 69
default
0 0 00000 0
2Dh
RXP3/GPO
3
Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0
page 69
default
0 0 00000 0
Addr Function 7 6 5 4 3 2 1 0
