7. CS3318 REGISTER DESCRIPTIONS

Notes:

1. When addressing the CS3318 with the Individual Chip Address, all registers are read/write in I²C Mode

and write-only in SPI Mode, unless otherwise noted.

2. When addressing the CS3318 with the Group Chip Addresses, all registers are write-only in both I²C

and SPI Mode.

7.1 Ch 1-8 Volume - Addresses 01h - 08h

7.1.1 Volume Control (Bits 7:0)

Default = 11010010

Function:

The individual volume control registers allow the user to gain or attenuate the respective channels in

0.5 dB increments. The volume changes are implemented as dictated by the ZCMode[1:0] and Tim-

eOut[2:0] bits in the Device Config 2 register (see “Device Configuration 2 - Address 0Ch” on

page 34).

The value of the Volume Control register is mapped to the desired 0.5 dB step volume setting by the

following equation:

In the equation above, “Desired Volume Setting in dB” is determined by rounding the desired ¼ dB

resolution volume setting down to ½ dB resolution.

It should be noted that input values outside the CS3318’s analog range of +22 dB to -96 dB are valid,

however, the volume of each channel will be limited to the CS3318’s analog range (see “Volume Lim-

its” on page 20).

76543210

Vol7 Vol6 Vol5 Vol4 Vol3 Vol2 Vol1 Vol0

11111110 +22

11111101 +21.5

11111100 +21

11010100 +1

11010011 +0.5

11010010 0

11010001 -0.5

11010000 -1

00010100 -95

00010011 -95.5

00010010 -96

* QuarterX = ‘0’. See “¼ dB Control (Bit 0 - 7)” on page 32.

Table 5. Example Volume Settings
