CDB5480U_REV_D.PL
BILL OF MATERIAL
Item Cirrus P/N Rev
Description Qty Reference Designator MFG MFG P/N Notes Status
36 020-01816-Z1 A
RES 1k OHM 1/8W ±1% NPb 0805 FILM 0 R9 R13 R23 R24 DALE CRCW08051K00FKEA NO POP A
37 021-00347-Z1 A
RES 2.2 OHM 1/8W ±5% NPb 0805 FILM 0 R11 R20 DALE CRCW08052R20JNEA NO POP A
38 021-00407-Z1 A
RES 680 OHM 1/8W ±5% NPb 0805 FILM 4 R25 R26 R27 R48 DALE CRCW0805680RJNEA A
39 021-00238-Z1 A
RES 680 OHM 1/10W ±5% NPb 0603 FILM 2 R29 R32 KOA RK73B1JTTD681J A
40 021-00259-Z1 A
RES 5.1k OHM 1/10W ±5% NPb 0603 FIL 3 R30 R31 R47 DALE CRCW06035K10JNEA A
41 021-00266-Z1 A
RES 10k OHM 1/10W ±5% NPb 0603 FILM 1 R33 DALE CRCW060310K0JNEA A
42 020-00673-Z1 A
RES 0 OHM 1/10W ±5% NPb 0603 FILM 9 R34 R35 R36 R37 R38 R40 R41 R42 R43 DALE CRCW06030000Z0EA A
43 021-00242-Z1 A
RES 1k OHM 1/10W ±5% NPb 0603 FILM 3 R44 R45 R46 DALE CRCW06031K00JNEA A
44 020-01473-Z1 A
RES 0 OHM 1/18W ±1% NPb 0805 FILM 2 R51 R54 DALE CRCW08050000Z0EA A
45 020-00914-Z1 A
RES 130 OHM 1/10W ±1% NPb 0603 FILM 1 R55 DALE CRCW0603130RFKEA A
46 020-00673-Z1 A
RES 0 OHM 1/10W ±5% NPb 0603 FILM 0 R56 DALE CRCW06030000Z0EA NO POP A
47 021-00718-Z1 A
RES 20 OHM 1/3W ±5% NPb 1210 FILM 1 R57 DALE CRCW121020R0JNEA A
48 120-00002-Z1 A
SWT SPST 130G 0/1 5mm TACT ESD NPb 2 S1 S2 ITT INDUSTRIES PTS645TL50 LFS INSTALL AFTER WASH PROCESS A
49 110-00045-Z1 A
CON TEST PT .1"CTR TIN PLAT NPb BLK 8 TP1 TP2 TP5 TP6 TP7 TP8 TP9 TP10 KEYSTONE 5001 A
50 065-00333-Z4 B2
IC CRUS BIDIR ENER MEAS NPb QFN24L 1 U1 CIRRUS LOGIC CS5480-INZ/B2 ECO867,ECO900, ECO934 A
51 060-00569-Z1 A
IC ISOL 4CH 2.5kV 4/0 NPb SOIC16N 2 U2 U3 SILICON LABORATORIES SI8440BB-D-IS1
A
52 175-00031-Z1 A
OPT COUP TRANS 50-600% NPb DIP4 2 U4 U5 TOSHIBA TLP781(F) A
53 062-00229-Z1 A
IC PGM USB 64kB FLAS MCU NPb LQFP32 1 U6 SILICON LABORATORIES INC C8051F342-GQ PROGRAM AT TEST
A
54 160-00012-Z1 A
LCD MODULE 3.3V 16x2 16x64mm NPb 1 U7 TOPWAY LMB162AFC-2
NEED HDR16X1-SSW-116-01-G-S,
TSW-116-07-G-S, #2 STANDOFF .500
LENGTH, SCREWS
A
55 061-00392-Z1 A
IC DIG DC/DC CONV 5V 1W NPb SMD8 1 U8 V-INFINITY VBT1-S5-S5-SMT A
56 060-00319-Z1 A
IC LNR VREG μPWR 150mA NPb SOT23-5 1 U9 NATIONAL SEMICONDUCTOR LP2985IM5-3.3/NOPB
A
57 100-00120-Z1 A
XTL 4.096MHZ HC49US 30ppm 20pF NPb 1 Y1 ECS ECS-41-20-4X INSTALL PIN SOCKETS A
58 070-00006-Z1 A
DIODE TR 6.8V 600W NPb AXL 2 Z1 Z2 LITTELFUSE P6KE6.8 A
59 070-00200-Z1 A
DIODE TVS 3.3V 2LN ESD NPb SOT23 1 Z3 COMCHIP TECHNOLOGY CTES033V3-G
A
60 603-00474-Z1 D
ASSY DWG CDB5480U-Z-NPb REF CIRRUS LOGIC 603-00474-Z1 ECO867 A
61 240-00474-Z1 D
PCB CDB5480U-Z-NPb 1 CIRRUS LOGIC 240-00474-Z1 ECO867 A
62 600-00474-Z1 D2
SCHEM CDB5480U-Z-NPb REF CIRRUS LOGIC 600-00474-Z1 ECO867, ECO900, ECO934 A
63 422-00013-Z1 D
LBL SUBASSY PRODUCT ID AND REV 1 CIRRUS LOGIC 422-00013-01 A
64 080-00003-Z1 A
WIRE BPOST 1.5X.25 24/19 GA BLU NPb 2 XJ36 XJ37 SQUIRES L-1.5X.25TX.25T_TYPE_E_ A
65 135-00003-Z1 A
SKT 1P .100"L .041"DIA GLD NPb 2 XY1(2 PINS) AUGAT 8134-HC-5P2 A
66 300-00025-Z1 A
SCREW 4-40X5/16" PH MACH SS NPb 7 XMH1 XMH2 XMH3 XMH4 XMH5 XMH6 XMH7 BUILDING FASTENERS PMSSS 440 0031 PH A
67 110-00013-Z1 D
CON SHUNT 2P .1"CTR BLK NPb 31 MOLEX 15-29-1025 INSTALL AT TEST A
70 422-00180-Z1 A
LBL RoHS
1
IMAGE-TEK LPP0054
PLACE LABEL ON THE SECONDARY
SIDE
A
