APPENDIX A. BILL OF MATERIALS
CIRRUS LOGIC
CDB5480U_REV_D.PL
BILL OF MATERIAL
Item Cirrus P/N Rev
Description Qty Reference Designator MFG MFG P/N Notes Status
1 001-04187-Z1 A
CAP 0.027uF ±5% 50V X7R NPb 0805 10 C1 C2 C4 C5 C6 C9 C11 C12 C34 C35 KEMET C0805C273J5RAC A
2 001-10064-Z1 A
CAP 15pF ±5% 50V C0G NPb 0603 1 C3 KEMET C0603C150J5GAC A
3 001-04523-Z1 A
CAP 1uF ±10% 16V X7R NPb 0805 2 C7 C28 KEMET C0805C105K4RAC A
4 001-02194-Z1 A
CAP 0.1uF ±10% 25V X7R NPb 0603 1 C8 KEMET C0603C104K3RAC A
5 001-04345-Z1 A
CAP 0.1uF ±10% 50V X7R NPb 0805 2 C10 C31 KEMET C0805C104K5RAC A
6 001-01994-Z1 A
CAP 0.01uF ±10% 16V X7R NPb 0603 2 C13 C19 MURATA GRM188R71C103KA01D A
7 001-02194-Z1 A
CAP 0.1uF ±10% 25V X7R NPb 0603 3 C14 C15 C16 MURATA GRM188R71E104KA01D A
8 001-10226-Z1 A
CAP 1uF ±10% 25V X5R NPb 0603 4 C17 C18 C20 C21 MURATA GRM188R61E105KA12 A
9 001-02189-Z1 A
CAP 0.1uF ±10% 16V X7R NPb 0603 5 C22 C23 C25 C27 C29 KEMET C0603C104K4RAC A
10 012-00010-Z1 A
CAP 47uF ±20% 16V NPb ELEC CASE C 2 C24 C30 PANASONIC EEE1CA470WR A
11 001-10127-Z1 A
CAP 22pF ±10% 50V C0G NPb 0603 1 C26 KEMET C0603C220K5GAC A
12 001-10233-Z1 A
CAP 4.7uF ±20% 25V X7R NPb 1206 2 C32 C36 TDK C3216X7R1E475M A
13 012-00013-Z1 A
CAP 4.7uF ±20% 25V ELEC NPb CASE B 1 C33 PANASONIC EEE1EA4R7SR A
14 165-00004-Z2 A
LED SUP RED 100mcd NPb SMD 4 D1 D2 D3 D6 EVERLIGHT 28-21SRC/TR8 A
15 070-00055-Z1 A
DIODE ARRAY 5V (TVS) ESD NPb SOT143 1 D5 LITTELFUSE SP0503BAHTG A
16 110-00055-Z1 A
CON TERM BLCK 4 POS 5mm NPb BLU TH 3 J1 J3 J12 ON-SHORE TECHNOLOGY ED 100/4DS
A
17 110-00056-Z1 A
CON TERM BLOCK 2POS 5mm NPb BLU TH 2 J4 J27 ON-SHORE TECHNOLOGY ED 100/2DS
A
18 115-00016-Z1 A
HDR 3x2 ML .1"CTR 062 S GLD NPb 1 J6 SAMTEC TSW-103-07-G-D A
19 115-00257-Z1 A
HDR 2x2 ML .1" 093BD ST GLD NPb TH 5 J7 J8 J11 J13 J14 SAMTEC TSW-102-08-G-D A
20 115-00009-Z1 A
HDR 3x1 ML .1" 062 ST GLD NPb TH 9 J15 J16 J18 J20 J26 J38 J43 J50 J58 SAMTEC TSW-103-07-G-S A
21 115-00029-Z1 A
HDR 8x2 ML .1" 062BD ST GLD NPB TH 2 J17 J19 SAMTEC TSW-108-07-G-D A
22 115-00014-Z1 A
HDR 2x1 ML .1" 062BD ST GLD NPb TH 16
J21 J23 J39 J40 J41 J44 J45 J46 J48 J49 J51 J52 J53
J54 J55 J56
SAMTEC TSW-102-07-G-S
A
23 115-00276-Z1 A
HDR 16X1 ML .1" 062 S GLD NPb TH 1 J22 SAMTEC TSW-116-07-G-S
SOLDER J22 AND U7(LCD) TO
PRINTED CIRCUIT BOARD
A
24 110-00041-Z1 A
CON RA USB BLK NPb TH 1 J24 AMP 292304-1 A
25 115-00003-Z1 A
HDR 5x2 ML .1"CTR S GLD NPb 1 J25 SAMTEC TSW-105-07-G-D A
26 110-00014-Z1 A
CON XLR CHASSIS 3P FML SILV NPb 0 J28 J30 J31 NEUTRIK NC3FD-H NO POP A
27 115-00014-Z1 A
HDR 2x1 ML .1" 062BD ST GLD NPb TH 0 J32 J34 J35 SAMTEC TSW-102-07-G-S NO POP A
28 110-00008-Z1 A
CON BPOST 2" SILV NYLON INS BLK NPb 1 J36 JOHNSON COMPONENTS 111-0103-001
REQUIRES WIRE, 1.5L X 0.25T X 0.25T
TYPE E 24/19 BLU SQUIRES ELEC. INC.
A
29 110-00010-Z1 A
CON BPOST 2" SILV NYLON INS RED NPb 1 J37 JOHNSON COMPONENTS 111-0102-001
REQUIRES WIRE, 1.5L X 0.25T X 0.25T
TYPE E 24/19 BLU SQUIRES ELEC. INC.
A
30 115-00024-Z1 A
HDR 1x1 ML .1"CTR S NPb GLD 1 J57 SAMTEC TSW-101-07-G-S A
31 080-00004-Z1 A
WIRE JUMPER 2P 0.1" BRASS NPb TH 8 JP1 JP2 JP3 JP4 JP5 JP6 JP7 JP8 COMPONENTS CORPORATION TP-101-10
A
32 304-00022-Z1 A
SPCR STANDOFF NYL HEX 1.0/4-40 NPb 7 MH1 MH2 MH3 MH4 MH5 MH6 MH7 KEYSTONE 1902E
REQUIRES SCREW 4-40X5X16" PH
STEEL 300-00025-Z1
A
33 020-01702-Z1 A
RES 100 OHM 1/8W ±1% NPb 0805 FILM 4 R1 R2 R21 R22 DALE CRCW0805100RFKEA A
34 020-01816-Z1 A
RES 1k OHM 1/8W ±1% NPb 0805 FILM 7 R5 R6 R7 R49 R50 R52 R53 DALE CRCW08051K00FKEA A
35 020-06362-Z1 A
RES 422k OHM 1/4W ±1% NPb 1206 4 R8 R12 R14 R15 DALE CRCW1206422KFKEAA
