AN375
26 AN375REV4
5.3 Bill of Materials
Item Rev DescripƟon Qty Reference Designator MFG MFG P/N
1 DIODE RECT 200V 0.8A NPB MINIDIP 1 BR1 DIODES INC HD02-T
2 CAP 33uF ±20% 35V ALUM ELEC NPb RAD 1 C1 PANASONIC ECA1VHG330
3 CAP 0.1uF ±10% 250V MPET NPb RAD 1 C2 PANASONIC ECQE2104KF
4 CAP 56pF ±5% 50V C0G NPb 0603 2 C3 C8 KEMET NP-C0603C560J5GAC
5 CAP 680uF ±20% 35V AL ELEC NPb RAD 1 C4 PANASONIC EEUFR1V681
6 A CAP 0.047uF ±10% 25V X7R NPb 0603 1 C6 KEMET C0603C473K3RAC
7 CAP 100pF ±5% 50V C0G NPb 0603 1 C7 KEMET NP-C0603C101J5GAC
8 CAP 2200pf ±10% 2KV X7R NPb 1210 1 C9 KEMET C1210C222KGRAC
9 CAP 0.1uF ±10% 25V X7R NPb 0603 1 C10 KEMET C0603C104K3RAC
10 CAP 0.047uF ±5% 250V POLY NPb RAD 1 C11 EPCOS B32529C3473J
11 CAP 0.068uF ±10% 250V MPOLY NPb RAD 1 C13 PANASONIC ECQE2683KB
12 CAP 1000PF ±10% 500V X7R NPb 0805 1 C14 KEMET C0805C102KCRAC
13 DIODE RECT 600V 1A 50mA NPb DO-41 1 D1 DIODES INC 1N4005
14 DIODE 600V 1A NPb SMA DO-214AC 1 D3 MCC GS1J-LTP
15 DIODE SWT 250V 0.4A NPb SOT-23 1 D4 DIODES INC BAV23S-7-F
16 DIODE HS SWT 100V 300mA NPb SOD323 1 D5 MICRO COMMERCIAL 1N4148WX-TP
17 DIODE SCHOTTKY 350mA 30V NPb SOD323 1 D6 MICRO COMMERCIAL SD103BWS-TP
18 DIODE SKY RECT 100V 2A NPb DO-214AC 1 D7 MCC SS210-TP
19 NO POP PAD H40 P64 NPb TH 4 E1 E2 E5 E6 NO POP NP-PAD-H40P64
20 IND 10000uH 0.053A MINI-DRUM NPb TH 1 L1 RENCO RL-5480-3-10000
21 XFMR 2.6mH ±10% 10KHz NPb TH 1 L2 KUNSHAN EAGERNESS EF16-CL01
22 THERM 100K OHM ±5% 0.10mA NPb 0603 1 NTC MURATA NCP18WF104J03RB
23 TRAN MSFET nCH 60V 360mA NPb SOT-23 1 Q1 NXP 2N7002P,215
24 TRAN MOSFET nCH 1.3A 600V NPb DPAK 1 Q2 ALPHA & OMEGA AOD1N60
25 TRAN MOSFET nCH 2.5A 600V NPb DPAK 1 Q4 ALPHA & OMEGA AOD3N60
26 RES 0 OHM 1/10W ±5% NPb 0603 FILM 2 R1 R20 DALE CRCW06030000Z0EA
27 RES 47 OHM 1/10W ±1% NPb 0603 2 R2 R19 PANASONIC ERJ3EKF47R0V
28 RES 3.3K OHM 1W ±5% NPb AXL 1 R3 BC COMPONENTS PR01000103301JR500
29 RES 1k OHM 2W ±5% MTL FLM NPb AXL 1 R4 VISHAY PR02000201001JR500
30 RES 27K OHM 1/8W ±0.1% NPb 0805 1 R5 PANASONIC ERA-6YEB273V
31 RES 2.67 OHM 1/4W ±1% NPb 1206 1 R6 KOA RK73H2BTTD2R67F
32 RES 750k OHM 1/8W ±1% NPb 0805 FILM 2 R7 R8 PANASONIC ERJ6ENF7503V
33 RES 47OHM 2W 1% FUSIBLE MTL NPb AX 1 R9 YAGEO FKN2WSFTF73-47R
34 RES 69.8k OHM 1/10W ±1% NPb 0603 1 R10 DALE CRCW060369K8FKEA
35 RES 499K OHM 1/4W ±1% MTL NPb AXL 1 R11 VISHAY CCF55499KFKE36
36 RES 43.2k OHM 1/10W ±1% NPb 0603 1 R13 DALE CRCW060343K2FKEA
37 RES 82 OHM 1/2W ±5% C FLM NPb AXL 1 R15 KOA CF1/2CT52R820J
38 RES 71.5k OHM 1/10W ±1% NPb 0603 1 R17 DALE CRCW060371K5FKEA
39 RES 14k OHM 1/10W ±1% NPB 0603 FILM 1 R18 DALE CRCW060314K0FKEA
40 RES 2.61k OHM 1/10W ±1% NPb 0603 1 R23 DALE CRCW06032K61FKEA
41 A0 IC CRUS TRIAC DIM PFC 120V NPb SO16 1 U1 CIRRUS LOGIC CS1615-FSZ/A0
42 VARISTOR 240V 210pF 15J 7mm NPb RAD 1 VR1 BOURNS MOV-07D241K
43 DIODE ZENER 500mW 16V NPb SOD123F 1 Z1 NXP NZH16C,115
Figure 10. Bill of Materials
