STD-302S 429MHz operation guide

OG_STD-302S-429M_v11e Circuit Design, Inc.
5
OPERATION GUIDE
Receiver part
Item MIN TYP MAX Remarks
Receiver type Double superheterodyne
1st IF frequency MHz 21.7
2nd IF frequency kHz 450
Maximum input level dBm 10
BER (0 error/2556 bits)
*1
dBm -108 -115 PN 9 4800bps
BER (1 % error)
*2
dBm -120 PN 9 4800bps
Sensitivity 12dB/ SINAD dBm -120 fm1 k/ dev 2kHz CCITT
Spurious response rejection
*3
dB
70 1 st Mix, 2 signal method, 1 % error
55 2 nd Mix, 2 signal method, 1 % error
Adjacent CH selectivity
*3
dB 50
+/- 12.5kHz,
2 signal method, 1 % error
Intermodulation
*4
dB 50 2 signal method, 1 % error
DO output level V 0 2.8 L = GND H = 2.8 V
RSSI rising time ms
30 50 CH shift of 12.5 kHz (from PLL setup)
50 70 When power ON (from PLL setup)
Time until valid Data-out
*5
ms
50 100 CH shift of 12.5 kHz (from PLL setup)
70 120 When power ON (from PLL setup)
Spurious radiation dBm -60 -54 Conducted 50 ohm
RSSI mV
300 350 400 With -97 dBm at 429.5 MHz
190 240 290 With -113 dBm at 429.5 MHz
Specifications are subject to change without prior notice
Notice
 The time required until a stable DO is established may get longer due to the possible frequency drift
caused by operation environment changes, especially when switching from TX to RX, from RX to TX
and changing channels. Please make sure to optimize the timing. The recommended preamble is more
than 20 ms.
 Antenna connection is designed as pin connection.
 RF output power, sensitivity, spurious emission and spurious radiation levels may vary with the trace
used between the RF pin and the coaxial connection. Please make sure to verify those parameters
before use.
 The feet of the shield case should be soldered to a wide GND pattern to avoid any change in
characteristics.
Notes about the specification values
*1 BER: RF level where no error per 2556 bits is confirmed with the signal of PN9 and 4800 bps.
*2 BER (1 % error) : RF level where 1% error per 2556 bits is confirmed with the signal of PN9 and 4800 bps.
*3 Spurious response, CH selectivity: Jamming signal used in the measurement is unmodulated.
*4 Intermodulation: Ratio between the receiver input level with BER 1% and the signal level (PN9 4800 bps)
added at the points of 'Receiving frequency - 200 kHz ' + ' Receiving frequency -100kHz' with which BER
1% is achieved.
*5 Time until valid Data-out : Valid DO is determined at the point where Bit Error Rate meter starts detecting
the signal of 4800bps, 1010repeated signal.
All specifications are specified based on the data measured in a shield room using the PLL setting controller
board prepared by Circuit Design.
Measuring equipment:
SG=ANRITUS communication analyzer MT8802
Spectrum analyzer = ANRITSU MS2830A
BER measure = ANRITSU MP1201G
