User's Manual

6
General Features and Characteristics
Figure 1. Scanner Features
ITEM NO.
DESCRIPTION
1 Red Output Window (Laser Aperture)
2 Safety and Product label (Figure 3)
3 Speaker for audible indicators
4 LCD display
5 Multi-functional Keypad
6 Charging and communication contacts
7 IrDA Communication port
8 Battery Compartment release
9 Scan Button
Figure .2.Cradle Features
ITEM NO.
DESCRIPTION
1 Safety and Product label
2 RS232 communication port
3 Power Adapter port
4 LED power indicator
5 LED Transmission indicator
6 Rubber footpads
1
2 3
4
5
F
1
2
4
5
3
7
8
9
Fi
g
ure 3 Product Label
Fi
g
ure 4 O
p
timus and Cradle
