MONITOR AFx™ V3.
Contents About This Guide.................................................................................................................................... ii Notices....................................................................................................................................................iii Welcome.......................................................................................................................................1 Introduction to Security Management ...........
About This Guide This guide provides details on performing various tasks in a MONITOR AFx™ system using an LCD keypad. Year-2000 Compliance The MONITOR AFx™ system is fully year2000 compliant, allowing calendar dates, leapyears, and weekdays to be handled properly for the year 2000, and beyond. Firmware Revisions: This manual can be used with panel firmware V2.x and V3.x, but be aware that: + Support for controlled elevators and floors pertains to panels with V3 firmware and newer.
Industry Canada Notice of Limitations Notice: The Industry Canada Label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements documents(s). The Department does not guarantee the equipment will operate to the user's satisfaction.
FCC Class A Digital Device Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
If the terminal equipment (MONITOR AFx) causes harm to the telephone network, the telephone company will notify you in advance that temporary dis-continuance of service may be required. But if advance notice isn't practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a compliant with the FCC if you believe it is necessary.
vi MONITOR AFx™ v3.3 LCD Keypad User's Guide 500-9030v3.
Welcome 500-9030v3.
Introduction to Security Management General Concepts Seamlessly Integrated Security MONITOR AFx™ systems provide a seamless integration between managing system security and controlling personnel access at the facility. This provides assurance that unauthorized access will be detected for immediate attention, while allowing authorized persons to enter at their designated doors and times without triggering an alarm.
Guard Tours Through the MONITOR AFx™ Director software, the routes taken by Guards can be initially set up, and then monitored for a specific user (guard) at any time. Each 'tour' will consist of chosen access-controlled doors, plus additional guard tour stations (checkpoints) that my be key-switches, or other types of input points—along with the acceptable time for the guard to arrive at each location. Reporting No security management system would be complete without the ability to generate reports.
System Components and Software System Software and Licensing The MONITOR AFx™ Director Software The MONITOR AFx Director software provides a familiar Windows interface supporting these easy-to use features: • An authorized technician (service user) can configure all aspects of the system; • Authorized admin. persons have the ability to easily manage personnel, monitor activity, and perform typical maintenance tasks.
Dual-Language Framework The MONITOR AFx system provides a framework for dual-language support, allowing for dual-language installations, as new language-versions of the software and panels become available. Once installed in the desired languages (subject to availability), operators and users can be set as to their preferred language— allowing all operator screens, on-line help, and/or LCD-keypad screens to appear in the appropriate language for the person who is presently logged in.
Overview of Tasks (What can be Done from Where) Adjusting the 'Closing' Time (Worklate) for an Active Schedule The 'closing' time for a schedule can be adjusted: • By an authorized operator using the MONITOR AFx Director software. • By an authorized user/entrant at a system LCD keypad; Cardholder Administration The administration of users/cardholders can be done: • Through this MONITOR AFx Director Software (via modems or direct-connect); • Locally through a system keypad (with 2-line LCD display).
Avoiding False Alarms No matter how full-featured, and reliable a security system is, a number of steps must be taken to absolutely minimize the likelihood of false alarms occurring. These include: 1) Ensuring the system's configuration accurately reflects the requirements at the site (regarding the working times and movement of personnel during a typical workweek, etc.).
The MONITOR AFx™ LCD Keypad ▲ 1' - # GHI 7 PRS Like the rest of the keypad, these buttons are backlit for use in poor lighting conditions. 2 ABC 3 5 JKL 6 MNO X 8 TUV WXY 0 Z_Q 9 DEF ✴ ▲ ▲ 4 The MONITOR AFx LCD keypad provides an integrated 2-line display and multi-function backlit keypad. (The keypad is hidden behind a hinged access cover.
Common Tasks Entering at an Access-Controlled Door Reader/Door Mode Area Setting Disarmed (Off) Locked & Card Only Present card, open the door Locked & Card+PIN Locked & Card or UID/PIN Locked & UID/PIN Only Present card, enter PIN Present card or enter open the door user no., enter PIN open the door Enter UID+PIN (or PIN only), open the door Present card, enter PIN Present card or enter open the door user no.
If You Are Being Forced to Enter Overview of Screens (Topics) A duress (panic) alarm is triggered when you enter your PIN with the last two digits reversed. (This can be done at reader keypads, system LCD keypads, and condominium LED keypads.) When logged in, you will see only the topics that you have the authority to use.
Time: This allows changing the time and/or date for a system panel. Verify: This allows a person to prove they are present. This lets a monitoring facility know that you are present after accidentally tripping a sensor, and/or silencing a false alarm. Schdule: This allows extending the scheduled closing time for an area (the "work-late" feature), or suspending a schedule altogether. Keypad Entry Basics Use the buttons directly under the display to select items indicated on-screen.
12 MONITOR AFx™ v3.3 LCD Keypad User's Guide 500-9030v3.
Alarms, Arming and Disarming 500-9030v3.
Alarm Monitoring Features Depending on how the system is set up, specific alarms may be indicated by any of the following items: • An alarm message will appear on specific keypad(s); • Keypad 'sonalerts' (beepers) may sound; • A local siren may be triggered; • An alarm message may be transmitted to a central monitoring facility (and/or to a management PC running the MONITOR AFx Director software); • A programmable "output" may be triggered (this can cause a horn to sound, or perform any other type of automa
Sirens Steps: Conventional Siren Fire Alarm: Intermittent Tone (see previous details). 1) Enter your user ID and/or password to log into the keypad. !! In Alarm !! Enter ID: _ _ _ 2) Select Yes to silence the alarm. Silence System? ↓Yes ↓No View↓ 3) Select Yes again to verify who you are. Verify User? ↓Yes ↓No 4) To Verify User Enter your PIN Enter PIN: _ _ _ _ when prompted. This will signal the monitoring facility that you wish to cancel the false alarm. 5) To disarm area(s), select "Off".
Using the Emergency Keys There are three emergency keys that will activate an emergency alarm. This will be transmitted to the monitoring facility, and may also trigger a local alarm, activate a programmable output, and/or trigger a numeric pager (depending on how the system is set up). Worklate: Extending the Scheduled Closing Time To transmit an emergency alarm, press the button on both sides of the specific symbol at the same time.
Suspending Schedules for an Area or Areas Arming/Disarming or Viewing the Present Arming-Level A schedule can be blocked altogether if you do not want a scheduled closing to occur. With the appropriate authority, you can arm and disarm the system, or specific area(s) using an LCD keypad. Steps: 1) 2) 3) 4) 5) Enter your user ID and/or PIN to log into the keypad. Welcome Enter ID: _ _ _ Menu Options Press the key until you see ↓Verify ↓Schdule "Schedule".
7) Points not Ok! Select View to view points that ↓View are currently bypassed or not Ok. At this time the system will indicate points that are not OK and force you to either bypass or secure these points in order to arm the system. 8) Select the desired AreaName.....Off topic: ↓Pts ↓Next All↓ • Pts: Bypassable points (sensors) in the displayed area; • Next: Show the next area; • All: All bypassable points regardless of area.
Checking Status and Controlling Items 500-9030v3.
Status and Control Features Checking the System Status Using an LCD keypad, you can: (monitored conditions for a panel) The system status feature shows the status of all conditions (tamper, low battery, etc.) that are being monitored for the panel associated with your keypad. • Check the status of various items in the system and view the present arming-level of desired area(s).
Checking the Status of Sensors (Points) and Areas The Points-status feature allows checking the status of sensors in the system (and viewing the arming-level for areas). Steps: 1) Enter your user ID and/or PIN to log into the keypad. Welcome Enter ID: _ _ _ 2) Select access other functions. Push 3) Select Yes to view Status. View Status? ↓Yes ↓No 4) Select Points.
Checking Status or Controlling Readers or Doors 7) If you selected D0x: Door Name Door, the door ↓DoorState ?↓ state will be shown, and you'll have these options: • " ": Press this key to scan through the doors in the system (or the selected area); • Select the door state: Then, you can use the keys to access a command (and press the key under the command to select it); • " " / "?": " " shows the area for the door. "?" jumps to the next door that is not OK.
Checking the Status of a Condominium Unit Checking the Status of an Application Module (HSC / Smart) (Condominium/Multi-Tenant Keypad) You can check the status of any "application" modules in the system. (An application module provides increased functionality such as Printer capability.) For systems that include condominium (multitenant) keypads, the MONITOR AFx Director software is required to set up the system.
24 MONITOR AFx™ v3.3 LCD Keypad User's Guide 500-9030v3.
Administration and Maintenance Tasks 500-9030v3.
Changing Your Own PIN 1) Enter your user ID and/or PIN to log into the keypad. Welcome Enter ID: _ _ _ 2) Press to scroll to the PIN option. Push Select PIN to change your PIN. Menu Options ↓PIN ↓Users Enter your new 4digit or 5-digit PIN. New PIN _ _ _ _ For User: UID# 3) 4) 3) Enter an available 0xx Select User user number (and ↓OK select Ok), or select Ok, and then press until a user number appears with "Add" (instead of Edit and Delete).
More: Provides access to additional screens. Name: Use the keypad to enter the ↓OK user's name, and select Ok when finished. . . . . Viewing or Changing Settings for a User For an existing user, you can view or edit their settings as desired. Tip: Check the letters on the numeric keypad. Then, for each letter of the name, quickly press the specific key until the letter appears (e.g., pressing 2 yields 2, A, B, C; 0 provides 0, Z, , Q, etc).
PIN: This allows New PIN - - - 0xx setting or changing For User ID Personal the Number for this user. (You'll be asked to enter it twice--to help protect against typing errors.) The last two digits of the PIN must be different. Also, do not use consecutive numbers such as 1234. Name: Use the UserName . . . . keypad to enter the ↓OK user's name, and select Ok when finished. Tip: Check the letters on the numeric keypad.
5) 6) Del? Then, select Yes to delete the user, ↓Yes or select Cancel if you changed your mind. Viewing the History ↓Cancel To return to the main screen (log out), press the ( ) key a few times, or let the system time-out (1 minute). All activity that occurs in the system can be viewed one event at a time. This includes area/door activity, as well as the tasks that users have performed at a keypad. Depending on your system type and licensing, up to 65 536 events will be recorded.
Printing the History Log If your system includes a printer-capable module (such as HSC), you can print the history log. (This will be sorted by date). Depending on your system type and licensing, up to 65 536 events will be recorded. Changing the Printed History Language You can change the language for the printed history log when needed. Supported languages will depend on your system firmware revision and/or the version of your MONITOR AFx Director software.
Testing Monitored Sensors (Performing a Walk Test) Steps: A Walk Test allows you to test specific sensors (points) in the system, to ensure that they are functioning correctly. 1) Enter your user ID and/or PIN to log into the keypad. Welcome Enter ID: _ _ _ A walk test can be done by users with "System Test" authority. 2) Press until "Test" appears, and select Test. Menu Options ↓Test ↓Time 3) Select Area. Test? ↓Area A walk test must be completed within 15 minutes. Emergency points (i.e.
Testing Panic Buttons (Performing a Holdup Test) Testing Sirens (System Test) A Holdup Test allows you to test "holdup" points in the system, to ensure that they are functioning correctly. A holdup test can be done by users with "System Test" authority. 1) Enter your user ID and/or PIN to log into the keypad. Welcome Enter ID: _ _ _ 2) Press until "Test" appears, and select Test. Menu Options ↓Test ↓Time 3) Select Area. Test? ↓Area 5) ↓System Now, choose one AreaName.....
Reference Topics 500-9030v3.
System Information (Areas, Authorities, etc.) Your MONITOR AFx system has information specific to your installation. This information should be recorded below upon installation for each panel.
System Configuration Aspects: Function Key Reference Programmed Entry and Exit Delays: The Function key ( ƒ ) is pressed and held in conjunction with the number keys for customized functions. Entry Delay:_______ Exit Delay:_______ Note: Function keys are not active until configured by a service technician.
Schedules for User Access and System Automation About Schedules Schedules are customizable time-windows that can: Up to 50 schedules can be defined as necessary. • Allow areas to 'open' (disarm), and 'close' (arm) automatically; • Set times when authorized entrants will be able to enter assigned areas; • Allow doors to unlock and relock automatically. Once defined, schedules can be assigned to areas, readers/doors, and user authority levels. This is done when the system is being set up.
Schedule __ _________ Schedule __ _________ Schedule __ _________ Schedule __ _________ Int Start Stop 1 _____ _____ 2 _____ _____ 3 _____ _____ 4 _____ _____ 5 _____ _____ 6 _____ _____ Mon Tue Wed Thu Fri Schedule for type 1 Holidays: ______ Schedule for type 2 Holidays: ______ Schedule for type 3 Holidays: ______ Int Start Stop Sun Wed 1 _____ _____ 2 _____ _____ 3 _____ _____ 4 _____ ___
Holidays and Time-Change Dates About Holidays Holidays are defined dates that: • Automatically change the system time between Daylight Savings Time and Standard Time on the applicable days (H001 & H002), or; • Are treated as being either 'after-hours' for the entire holiday, or days for which different schedule times will apply.
Photocopy and/or fill in the holiday list for your MONITOR AFx system: # Holiday (Name, Date, Type) # Holiday (Name, Date, Type) 17 _________________________________ 1 Daylight-Savings (Optional) 2 Standard Time 18 _________________________________ (Optional) 3 _________________________________ 19 _________________________________ 4 ________________________________ 20 _________________________________ 5 _________________________________ 21 _________________________________ 6 __________
Authority Levels (Profiles) for Users About Authority Levels Authorities determine the features that groups of alarm panel users will be able to use, and when and where they can use their access card to enter controlled areas. Up to 100 user-authorities can be set up (through a system keypad), with each one containing up to 4 'profiles' of settings—allowing a different set of authorities to be assigned to different areas, or groups of areas in the facility.
Authority Level #, Name: User Ranges: Auth. Ranges: Area Profile: Sched: Areas: Silence Alarms Bypass (& Reinst) Arm/Disarm to O/S/O Days Access O/S/O : : Panic Token View Status Auto-Remove Arm/Disarm to O/S/O PM Entry via type A/B/C Doors (days) W. Patient View History System Test Master Override Entry via type A/B/C Doors (PM) Reset W.P.
Residential Fire Safety / Evacuation Plan No fire detection system should be considered 100 percent foolproof. This fire alarm system can provide early warning of a developing fire, Such a system, however, does not ensure protection against property damage, or loss of life resulting from a fire. Any fire alarm system can fail to warn for a number of reasons such as: smoke not reaching a detector that is behind a closed door.
• If you live in a high-rise building, use the stairs — never the elevator — in case of fire. • Choose a meeting place a safe distance from your home and mark it on the escape plan. A good meeting place would be a tree, telephone pole, or a neighbor's home. In case of fire, everyone should gather at the meeting place. • Make sure the street number/address of your home is visible to firefighters. • Memorize the emergency number of the local fire department.
Arming Station Reference MONITOR AFx™ Arming Station (option) The optional MONITOR AFx Arming Station allows many system tasks to be performed without having to login at the LCD Keypad. The following is an overview of the available commands. For more information on entering at a controlled door and/or disarming the system, refer to the "Welcome" and "Alarm" chapters. “Badge” refers to presenting your card or user-ID and PIN as if to gain entry at the specific door. If badging with user-ID and/or PIN (i.e.
MONITOR AFx Arming Station LEDs The optional MONITOR AFx Arming Station has three LEDs to indicate door, system and arming status. The following list indicates the LED messages and audible results from the Arming Station. For detailed information on Keypad Tones, see MONITOR Keypad Tones. Work Late LED Solid yellow lit within 15 minutes to the scheduled closing time. Off if the area is not scheduled or there are more than 15 minutes to the scheduled closing time.
Wireless Keypad Reference MONITOR AFx Wireless Keypad (option) The optional MONITOR AFx Wireless Handheld Keypad allows system commands to be performed using the wireless keypad. Below is a list of the available Wireless Keypad commands, and their proper Key sequences. “login” refers to entering your User ID and PIN.
Error Messages and Trouble Indications Trouble LED LCD Error Messages The following section contains a comprehensive list of error messages that may appear on the LCD user log on screen for MONITOR AFx. The condition responsible for each message is indicated below. Power Failure: AC Failure. System Trouble: Main Panel Tamper, module Communications, module Substitution, module Tamper, Fuse Trouble. Battery Trouble: Panel or module battery low voltage or missing/disconnected.
