User's Manual

ENEN
Installation
Important: This camera should be placed where the WiFi signal is
strong for optimal performance.
1. Separate the mounting
template on the bottom
of this camera from the
bracket by pressing the
snap as picture shows
2. Mount the template on the
wall by using the supplied
screws
3. Push and press the bracket
of the camera into the
template carefully, and then
adjust the angle to achieve
best shooting effect
Specications
Image sensor
Min. illumination
Shutter time
Lens
Angle of view
Video compression
Bit rate
Max. image resolution
Frame rate
Storage
Wireless standards
Frequency range
Channel bandwidth
Operating conditions
Power supply
Power consumption
Dimensions (L x W x H)
Sony 1/2.9" CMOS sensor
Color: 0.01Lux@ (F1.2, AGC ON)
Black and white : 0.001Lux@
(F1.2, AGC ON)
1/50s to 1/100,000s
2.4mm F2.0
115°
H.264
Self-adaption
1920 X 1080
20fps (1920 X 1080)
Built-in microSD card slot, up to 32GB
IEEE802.11b/g/n
2.412 GHz ~ 2.462 GHz
20/40MHz Support
Temperature: 0 °C - 60 °C
(32 °F - 140 °F)
Humidity: < 95% (non-condensing)
DC 5V 1A
5W MAX
80 x 80 x 150 mm
