SECTION TABLE OF CONTENTS PAGE 1 1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 2 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2 3 UNDERSTANDING THE FEATURES OF YOUR VEHICLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131 3 4 UNDERSTANDING YOUR INSTRUMENT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . .
INTRODUCTION CONTENTS 䡵 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . .4 䡵 VEHICLE IDENTIFICATION NUMBER . . . . . . . .6 䡵 HOW TO USE THIS MANUAL . . . . . . . . . . . . . .4 䡵 VEHICLE MODIFICATIONS/ALTERATIONS . . . .7 䡵 WARNINGS AND CAUTIONS . . . . . . . . . . . . . .
4 INTRODUCTION When it comes to service, remember that your authorized dealer knows your vehicle best, has factory-trained techCongratulations on selecting your new FCA US LLC nicians and genuine MOPAR® parts, and cares about vehicle. Be assured that it represents precision workmanyour satisfaction. ship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. CHRYSLER is a registered trademark of FCA US LLC.
INTRODUCTION 5 1
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against operating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against procedures that could result in damage to your vehicle. If you do not read this entire Owner’s Manual, you may miss important information. Observe all Warnings and Cautions.
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Stamped VIN Location NOTE: It is illegal to remove or alter the VIN.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2 CONTENTS 䡵 A WORD ABOUT YOUR KEYS . . . . . . . . . . . . .12 ▫ Rearming Of The System . . . . . . . . . . . . . . . . .18 ▫ Wireless Ignition Node (WIN) . . . . . . . . . . . . .12 ▫ To Arm The System . . . . . . . . . . . . . . . . . . . .18 ▫ Key Fob . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 ▫ To Disarm The System . . . . . . . . . . . . . . . . . .18 ▫ Removing Key Fob From Ignition . . . . . . . . . .13 ▫ Tamper Alert . . . . . . .
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Sound Horn With Remote Lock . . . . . . . . . . . .24 ▫ How To Use Remote Start . . . . . . . . . . . . . . . .31 ▫ Using The Panic Alarm . . . . . . . . . . . . . . . . . .25 䡵 DOOR LOCKS . . . . . . . . . . . . . . . . . . . . . . . . .35 ▫ Power Open/Close Power Liftgate — If Equipped . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 ▫ Manual Door Locks . . . . . . . . . . . . . . . . . . . . .35 ▫ Power Door Locks — If Equipped . .
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 䡵 OCCUPANT RESTRAINT SYSTEMS . . . . . . . . . .61 䡵 SAFETY TIPS . . . . . . . . . . . . . . . . . . . . . . . . .123 ▫ Important Safety Precautions . . . . . . . . . . . . . .61 ▫ Transporting Passengers . . . . . . . . . . . . . . . . .123 ▫ Seat Belt Systems . . . . . . . . . . . . . . . . . . . . . .62 ▫ Exhaust Gas . . . . . . . . . . . . . . . . . . . . . . . . .123 ▫ Supplemental Restraint System (SRS) . . . . . . . .
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle is equipped with a keyless ignition system. This system consists of a Key Fob with Remote Keyless Entry (RKE) transmitter and a Wireless Ignition Node (WIN) with integral ignition switch. You can insert the Key Fob into the ignition switch with either side up. When released from the START position, the switch automatically returns to the ON/RUN position.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob operates the ignition switch. Insert the square end of the Key Fob into the ignition switch located on the instrument panel and rotate to the desired position. It also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob. The emergency key allows for entry into the vehicle should the battery in the vehicle or the RKE transmitter go dead.
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Power window switches will also remain active for up to 10 minutes after the ignition switch has been turned to OFF, depending upon the accessory delay setting. Opening either front door will cancel this feature. WARNING! • Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 CAUTION! An unlocked car is an invitation to thieves. Always remove the Key Fob from the ignition and lock all doors when leaving the vehicle unattended. will cause the reminder chime to sound. Refer to “Starting Procedures” in “Starting And Operating” for further information. SENTRY KEY The Sentry Key Immobilizer system prevents unauthorized vehicle operation by disabling the engine.
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE After turning the ignition switch to the ON/RUN posiCAUTION! (Continued) tion, the Vehicle Security Light will turn on for three seconds for a bulb check. If the light remains on after the Use of these systems may result in vehicle starting bulb check, it indicates that there is a problem with the problems and loss of security protection. electronics.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 Duplication of Key Fobs may be performed at an autho- • This device must accept any interference that may be received, including interference that may cause underized dealer, this procedure consists of programming a sired operation. blank Key Fob to the vehicle electronics. A blank Key Fob is one that has never been programmed.
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Rearming Of The System The Vehicle Security Alarm will rearm itself after the 15 additional minutes of headlights and Vehicle Security Light flashing if the Vehicle Security Alarm has not been disabled. If the condition which initiated the alarm is still present, the Vehicle Security Alarm will ignore that condition and monitor the remaining doors and ignition. To Arm The System Follow these steps to arm the Vehicle Security Alarm: 1.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 • Grasp the Passive Entry Unlock Door Handle (if • The Vehicle Security Alarm remains armed during equipped, refer to ⬙Keyless Enter-N-Go⬙ in ⬙Things To power liftgate entry. Pushing the liftgate button will not disarm the Vehicle Security Alarm. If someone Know Before Starting Your Vehicle⬙ for further inforenters the vehicle through the liftgate and opens any mation). door, the alarm will sound.
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE exterior lights will flash, and the horn will sound. If this This feature also turns on the approach lighting in the outside mirrors (if equipped). Refer to “Mirrors” in occurs, disarm the Vehicle Security Alarm. “Understanding The Features Of Your Vehicle” for furTamper Alert ther information.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 NOTE: If your vehicle is equipped with illuminated approach lights under the outside mirrors, they can be turned off by using the Electronic Vehicle Information Center (EVIC) controls (if NOT equipped with a touchscreen radio) or the Uconnect radio (if equipped with a touchscreen radio). Refer to “Electronic Vehicle Information Center (EVIC)” or “Uconnect Settings” in “Understanding Your Instrument Panel” for further information.
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE (optional). Some features can be programmed to the customers preferences. For example, flash headlights or sound horn on LOCK.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 • For vehicles not equipped with the EVIC, the Remote Unlock feature can be enabled or disabled by performPush and release the UNLOCK button on the RKE ing the following steps: transmitter once to unlock the driver’s side or twice to unlock all doors and liftgate. This will also turn on the 1. Perform this operation while standing outside the Illuminated Entry system. vehicle. Remote Unlock Doors And Liftgate Remote Key Unlock On First Press 2.
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Pushing the LOCK button on the RKE transmit- • For vehicles not equipped with the EVIC, perform the following steps: ter while you are inside the vehicle will activate the Vehicle Security Alarm. Opening a door with the Vehicle 1. Perform this operation while standing outside the Security Alarm activated will cause the alarm to sound. vehicle. Push the UNLOCK button to deactivate the Vehicle 2.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 NOTE: Pushing the LOCK button on the RKE transmit- NOTE: ter while you are in the vehicle will activate the Vehicle • When you turn off the Panic Alarm by pushing the Security Alarm. Opening a door with the Vehicle Security PANIC button a second time, you may have to move Alarm activated will cause the alarm to sound. Push the closer to the vehicle due to the Radio Frequency (RF) UNLOCK button to deactivate the Vehicle Security noises of the system. Alarm.
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If equipped with a rear interior switch on the left rear If the vehicle is locked and the Vehicle Security Alarm is pillar, pushing this switch once will close the liftgate only. armed, pushing the LEFT Power Sliding Door button twice unlocks the power sliding door and disarms VeThe liftgate cannot be opened from this switch. hicle Security Alarm.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 Turn Off Flash Lights With RKE Lock — If Equipped than 10 seconds. Then, push and hold the LOCK button while still holding the UNLOCK button. This feature will cause the turn signal lights to flash when 3. Release both buttons at the same time. the doors are locked or unlocked with the RKE transmit4. Test the feature while outside of the vehicle by Pushter. This feature can be turned on or turned off.
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Remove the emergency key by sliding the mechanical latch at the top of the RKE transmitter sideways with If you do not have a programmed RKE transmitter, your thumb and then pull the key out with your other contact your authorized dealer for details. hand. Transmitter Battery Replacement Programming Additional Transmitters The recommended replacement battery is one CR2032 battery. NOTE: • Perchlorate Material — special handling may apply. See www.dtsc.ca.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 2. Insert the tip of the emergency key or a #2 flat blade screwdriver into the slot and gently pry the two halves of the RKE transmitter apart. Make sure not to damage the seal during removal. 2 Separating Transmitter Case Inserting Key Into Transmitter Case Slot 3. Remove and replace the battery. When replacing the battery, match the + sign on the battery to the + sign on the inside of the battery clip, located on the back cover.
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. To assemble the RKE transmitter case, snap the two 1. A weak battery in the transmitter. The expected life of the battery is a minimum of three years with normal halves together. usage. General Information This device complies with Part 15 of the FCC rules and 2. Closeness to a radio transmitter such as a radio station tower, airport transmitter, and some mobile or CB RSS-210 of Industry Canada. Operation is subject to the radios.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 NOTE: • Ignition key removed from ignition switch • The vehicle must be equipped with an automatic • transmission to be equipped with Remote Start. • • Obstructions between the vehicle and the Key Fob may • reduce this range.
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) System, windows, door locks or other controls could cause serious injury or death. The EVIC message stays active until the ignition is turned to the ON/RUN position. To Enter Remote Start Mode Remote Start Abort Message On Electronic Vehicle Information Center (EVIC) — If Equipped Push and release the REMOTE START button on the RKE transmitter twice within five seconds.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 • For security, power window and power sunroof op- To Exit Remote Start Mode And Drive The Vehicle eration (if equipped) are disabled when the vehicle is Before the end of the 15-minute cycle, push and release in the Remote Start mode. the UNLOCK button on the RKE transmitter to unlock • The engine can be started two times (15 minutes the doors and disarm the Vehicle Security Alarm (if cycles) with the RKE transmitter. However, the igni- equipped).
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles not equipped with the Keyless Enter- Cancel Remote Start N-Go feature, the ignition switch must be in the Remote Starting will also cancel if any of the following ON/RUN position in order to drive the vehicle. occur: • For vehicles not equipped with the Keyless Enter- • The engine stalls or engine speed exceeds 2500 rpm.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 To Turn Off The Engine While In Remote Start Mode DOOR LOCKS Manual Door Locks Push and release the REMOTE START button one time or Lock the front doors by pushing down on the lock knobs allow the engine to run for the entire 15 minute cycle. on each door trim panel. NOTE: To avoid unintentional shutdowns while in the If the lock knob is down when you shut either front door, Remote Start Mode, the system will not allow the Remote the door will lock.
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Manual Door Lock If the lock knob is rearward when you shut either side sliding door, the door will lock. Make sure the keys are not inside the vehicle before closing the door.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 WARNING! WARNING! (Continued) • For personal security and safety in the event of a collision, lock the vehicle doors before you drive as well as when you park and leave the vehicle. • Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage.
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE operate. A chime will sound if the Key Fob is in the ignition switch and a door is open, as a reminder to remove the Key Fob. Driver Power Door Lock Switches If you push the power door lock switch while the Key Fob is in the ignition, and any front door is open, the Front Passenger Power Door Switches power locks will not operate. This prevents you from accidentally locking your keys in the vehicle.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 If you push the power door lock switch while the sliding The Unlock Doors Automatically On Exit feature will not operate if there is any manual operation of the power door is open, the sliding door will lock. door locks (lock or unlock).
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • If you unlock the doors using the Passive Entry door handles, but do NOT pull the handle, the doors will • Passive Entry may be programmed ON/OFF. Refer to automatically lock after 60 seconds. “Electronic Vehicle Information Center (EVIC)/ Personal Settings (Customer-Programmable Fea- To Unlock From The Driver’s Side: tures)” in “Understanding Your Instrument Panel” for With a valid Passive Entry RKE transmitter within 5 ft further information. (1.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 NOTE: If “Unlock All Doors 1st Press” is programmed, all doors will unlock when you grab hold of the driver’s front door handle. To select between “Unlock Driver Door 1st Press” and “Unlock All Doors 1st Press,” refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer-Programmable Features)” in “Understanding Your Instrument Panel” for further information.
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Preventing Inadvertent Locking Of Passive Entry RKE unlocks all vehicle doors and chirps the horn three times Transmitter In Vehicle (on the third attempt ALL doors will lock and the Passive Entry RKE transmitter can be locked in the vehicle).
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 To Lock The Vehicle’s Doors With one of the vehicle’s Passive Entry RKE transmitters within 5 ft (1.5 m) of the driver or passenger front door handle, push the door handle LOCK button to lock all four doors. Do NOT grab the door handle, when pushing the door handle button. This could unlock the door(s).
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: WINDOWS • After pushing the door handle button, you must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle, without the vehicle reacting and unlocking.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 Power Windows You can control either the front or rear windows using switches located on the driver’s door trim panel. The switches will operate only when the ignition switch is in the ON/RUN or ACC position and during power accessory delay. 2 Driver’s Power Window Switches NOTE: Power Window switches will also remain active for up to 10 minutes after the ignition switch has been turned to OFF, depending upon the accessory delay setting.
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Window Lockout Switch — If Equipped Front Passenger Power Window Switch The driver may lock out the rear power windows by There is a single switch on the front passenger’s door pushing the bar switch just below the power window trim panel which operates the passenger door window switches. and a set of switches that lock and unlock all doors.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 Auto-Down Feature — If Equipped The front window switches may be equipped with an Auto-Down feature. Push the window switch past the detent, release, and the window will go down automatically. To open the window part way, push the window switch part way and release it when you want the window to stop.
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Any impact due to rough road conditions may trigger the auto reverse function unexpectedly during autoclosure. If this happens, pull the switch lightly to the The front driver and front passenger switches may be first detent and hold to close window manually. equipped with an Auto Up feature. Lift the window switch fully upward to the second detent, release, and the WARNING! window will go up automatically.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 2. Push the window switch down firmly to the second detent to open the window completely and continue to hold the switch down for an additional two seconds after the window is fully open. 2 Sliding Side Door Power Window Switch — If Equipped Second row passengers may open and close the sliding door window by a single switch on the door handle assembly.
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Wind Buffeting To keep your door operating properly, observe the following guidelines: Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the • Always open the door smoothly. ears. Your vehicle may exhibit wind buffeting with the • Avoid high impacts against the door stop when openwindows down, or the sunroof (if equipped) in certain ing the door.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 NOTE: The left side sliding door cannot be opened while the fuel door is open. This feature operates only when the sliding door is fully closed prior to opening the fuel door. Push the button on the RKE transmitter twice within five seconds to open a power sliding door. When the door is fully open, pushing the button twice within five seconds a second time will close the door.
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE master lock button, located in the overhead console, to disable the switches and handles for the rear seat passengers. NOTE: • The power sliding side door switches will not open the power sliding door if the shift lever is in gear or the vehicle speed is above 0 mph (0 km/h). To close the power sliding door with the shift lever in gear and vehicle speed at 0 mph (0 km/h), the brake must be pushed.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 door switch is pushed. To close the door, wait until it Power Sliding Side Door Open Flash is fully open and then push the switch again. The left and right exterior hazard lights will flash for 12 • If the power sliding door encounters multiple obstruc- seconds when either sliding door is opened.
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. A single chime will sound to signify that you have successfully completed the programming. You can turn the feature back on by repeating the previous procedure. Power Sliding Side Door Power Switch To provide a safer environment for small children riding in the rear seats, the second row sliding door switches and handles may be overridden by pushing the OFF side of the Power Switch located in the front overhead console.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 Sliding Side Door Child Protection Lock To provide a safer environment for small children riding in the rear seats, the sliding doors are equipped with a Child Protection Door Lock system. 2 NOTE: When the Child Protection Door Lock system is engaged, the door can be opened only by using the outside door handle even though the inside door lock is in the unlocked position. To Engage The Child Protection Door Lock 1. Open the sliding side door.
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • After engaging the Child Protection Door Lock, always test the door from the inside to make certain it is in the desired position. • When the Child Protection Door Lock system is engaged, (even if the inside door lock is in the unlocked position) the door can be opened only by using the outside door handle, the RKE transmitter, the switches on the overhead console or the switches located on the trim panel just in front of the power sliding door.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 • The power sliding door will operate from the outside door handle, the RKE transmitter, the switches on the 1. Open the sliding side door. overhead console, or the switches located on the 2. Slide the Child Protection Door Lock control outward B-pillar trim panel, just in front of the power sliding door when the shift lever is in PARK, regardless of the (away from the vehicle) to disengage the Child Protection Door Lock. child lock lever position.
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To open the liftgate, push the liftgate release handle Power Liftgate — If Equipped located on the underside of the license plate bar and pull The power liftgate may be opened manually or by using the liftgate open with one fluid motion. the button on the Remote Keyless Entry (RKE) transmitter. Push the button on the transmitter twice within five seconds, to open the power liftgate.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 The power liftgate may be closed by pushing the button, located in the upper left trim in the liftgate opening. Pushing once will only close the liftgate. This button cannot be used to open the liftgate.
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE When the RKE transmitter button is pushed and the • There are also pinch sensors attached to the side of the Flash Lights feature is enabled, the tail lights will flash liftgate opening. Light pressure anywhere along these and several audible beeps will occur to signal that the strips will cause the liftgate to return to the open liftgate is opening or closing. position. WARNING! During power operation, personal injury or cargo damage may occur.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 • The power liftgate will not operate in temperatures below −12°F (−24°C) or temperatures above 143°F (62°C). Be sure to remove any buildup of snow or ice from the liftgate before pushing any of the power liftgate buttons. • If the power liftgate encounters multiple obstructions within the same cycle, the system will automatically stop and must be opened or closed manually.
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE OCCUPANT RESTRAINT SYSTEMS Here are some simple steps you can take to minimize the risk of harm from a deploying air bag: Some of the most important safety features in your vehicle are the restraint systems: 1. Children 12 years old and under should always ride buckled up in a vehicle with a rear seat. • Seat Belt Systems 2.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 4. Never allow children to slide the shoulder belt behind them or under their arm. 5. You should read the instructions provided with your child restraint to make sure that you are using it properly. 6. All occupants should always wear their lap and shoulder belts properly. 7. The driver and front passenger seats should be moved back as far as practical to allow the Advanced Front Air Bags room to inflate. 8. Do not lean against the door or window.
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Research has shown that seat belts save lives, and they can reduce the seriousness of injuries in a collision. Some of the worst injuries happen when people are thrown from the vehicle. Seat belts reduce the possibility of ejection and the risk of injury caused by striking the inside of the vehicle. Everyone in a motor vehicle should be belted at all times.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 blinking the Seat Belt Reminder Light and sounding an intermittent chime. Once the BeltAlert warning sequence has completed, the Seat Belt Reminder Light will remain on until the seat belts are buckled. The BeltAlert warning sequence may repeat based on vehicle speed until the driver and occupied outboard front seat passenger seat belts are buckled. The driver should instruct all occupants to buckle their seat belts.
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The seat belt webbing retractor will lock only during very sudden stops or collisions. This feature allows the shoulder part of the seat belt to move freely with you under normal conditions. However, in a collision the seat belt will lock and reduce your risk of striking the inside of the vehicle or being thrown out of the vehicle. WARNING! (Continued) • Relying on the air bags alone could lead to more severe injuries in a collision.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 WARNING! (Continued) WARNING! (Continued) your seat belt safely and to keep your passengers safe, too. • Two people should never be belted into a single seat belt. People belted together can crash into one another in a collision, hurting one another badly. Never use a lap/shoulder belt or a lap belt for more than one person, no matter what their size. • A lap belt worn too high can increase the risk of injury in a collision.
68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) bones. Wear the seat belt over your shoulder so that your strongest bones will take the force in a collision. • A shoulder belt placed behind you will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt. The lap and shoulder belt are meant to be used together. • A frayed or torn seat belt could rip apart in a collision and leave you with no protection.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 2 Pulling Out The Latch Plate Inserting Latch Plate Into Buckle 3. When the seat belt is long enough to fit, insert the latch 4. Position the lap belt so that it is snug and lies low plate into the buckle until you hear a “click.” across your hips, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt.
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE position. If necessary, slide the latch plate down the webbing to allow the seat belt to retract fully. Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. Positioning The Lap Belt 2.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 Adjustable Upper Shoulder Belt Anchorage In the front and second row outboard seats the shoulder belt can be adjusted upward or downward to position the seat belt away from your neck. Push or squeeze the anchorage button to release the anchorage, and move it up or down to the position that serves you best.
72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE stored out of the way in the headliner for added conve- 2. Grasp the mini-latch plate and pull the seat belt over nience to open up utilization of the storage areas behind the seat. the front seats when the seat is not occupied. 1. Remove the mini-latch plate and regular latch plate from its stowed position in the headliner slightly behind the third row seat.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 3. Route the shoulder belt to the inside of the left head 4. When the seat belt is long enough to fit, insert the restraint. mini-latch plate into the mini-buckle until you hear a “click.
74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Sit back in seat. Slide the regular latch plate up the webbing as far as necessary to allow the seat belt to go around your lap. Rear Center Seat Belt Buckled 7. Position the lap belt so that it is snug and lies low across your hips, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder Rear Center Seat Belt Buckled belt. To loosen the lap belt if it is too tight, pull on the 6.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 8. Position the shoulder belt on your chest so that it is comfortable and not resting on your neck. The retractor will withdraw any slack in the seat belt. 9. To release the seat belt, push the red button on the buckle. 10. To disengage the mini-latch plate from the minibuckle for storage, insert the regular latch plate into the center red slot on the mini-buckle. The seat belt will automatically retract to its stowed position.
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Extender. The Seat Belt Extender should be used Seat Belts And Pregnant Women only if the existing seat belt is not long enough. When the Seat Belt Extender is not required for a different occupant, it must be removed. WARNING! • ONLY use a Seat Belt Extender if it is physically required in order to properly fit the original seat belt system.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 Position the lap belt snug and low below the abdomen and across the strong bones of the hips. Place the shoulder belt across the chest and away from the neck. Never place the shoulder belt behind the back or under the arm . NOTE: These devices are not a substitute for proper seat belt placement by the occupant. The seat belt still must be worn snugly and positioned properly. The pretensioners are triggered by the Occupant Restraint Controller (ORC).
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Switchable Automatic Locking Retractors (ALR) — If Equipped The seat belts in the passenger seating positions may be equipped with a Switchable Automatic Locking Retractor (ALR) which is used to secure a child restraint system. For additional information, refer to “Installing Child Restraints Using The Vehicle Seat Belt” under the “Child Restraints” section of this manual. The table below defines the type of feature for each seating position.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 If the passenger seating position is equipped with an ALR and is being used for normal usage, only pull the seat belt webbing out far enough to comfortably wrap around the occupant’s mid-section so as to not activate the ALR. If the ALR is activated, you will hear a clicking sound as the seat belt retracts.
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Never place a rear-facing child restraint in front of an air bag. A deploying Passenger Advanced Front Air Bag can cause death or serious injury to a child 12 years or younger, including a child in a rearfacing child restraint. • Only use a rear-facing child restraint in a vehicle with a rear seat. How To Engage The Automatic Locking Mode 1. Buckle the combination lap and shoulder belt. 2.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 WARNING! (Continued) only used to install rear-facing or forward-facing child restraints that have a harness for restraining the child. the Active Head Restraints (AHR) to deploy. If a rear impact requires deployment, both the driver and front passenger seat AHRs will be deployed. When AHRs deploy during a rear impact, the front half of the head restraint extends forward to minimize the gap between the back of the occupant’s head and the AHR.
82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Active Head Restraint (AHR) Components 1 — Head Restraint Front Half (Soft Foam and Trim) 2 — Seatback 3 — Head Restraint Back Half (Decorative Plastic Rear Cover) 4 — Head Restraint Guide Tubes • All occupants, including the driver, should not operate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a collision.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 WARNING! (Continued) as loose cargo could contact the Active Head Restraint during sudden stops. Failure to follow this warning could cause personal injury if the Active Head Restraint is deployed. dealer to reset the AHR. Attempting to reset the AHR may result in damage to the system that could impair its function.
84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Restraint System (SRS) • Seat Belt Pretensioners Air Bag System Components • Seat Belt Buckle Switch Your vehicle may be equipped with the following air bag • Seat Track Position Sensors system components: Advanced Front Air Bags • Occupant Restraint Controller (ORC) This vehicle has Advanced Front Air Bags for both the driver and front passenger as a supplement to the seat • Air Bag Warning Light belt restraint systems.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 WARNING! Advanced Front Air Bag And Knee Impact Bolster Locations 1 — Driver And Passenger Advanced Front Air Bags 2 — Passenger Knee Impact Bolster 3 — Driver Knee Impact Bolster/Supplemental Driver Knee Air Bag • Being too close to the steering wheel or instrument panel during Advanced Front Air Bag deployment could cause serious injury, including death. Air bags need room to inflate.
86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the driver or front passenger seat belt is buckled. The seat belt buckle switch may adjust the inflation rate of the The Advanced Front Air Bag system has multistage Advanced Front Air Bags. driver and front passenger air bags.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 WARNING! (Continued) • Relying on the air bags alone could lead to more severe injuries in a collision. The air bags work with your seat belt to restrain you properly. In some collisions, air bags won’t deploy at all. Always wear your seat belts even though you have air bags. Advanced Front Air Bag Operation Advanced Front Air Bags are designed to provide additional protection by supplementing the seat belts.
88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE way as the air bags inflate to their full size. The Advanced Front Air Bags fully inflate in less time than it takes to blink your eyes. The air bags then quickly deflate while helping to restrain the driver and front passenger. Supplemental Driver Knee Air Bag This vehicle is equipped with a Supplemental Driver Knee Air Bag mounted in the instrument panel below the steering column.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 89 When the SAB deploys, it opens the seam on the outboard side of the seatback’s trim cover. The inflating SAB deploys through the seat seam into the space between the occupant and the door. The SAB moves at a very high speed and with such a high force that it could injure occupants if they are not seated properly, or if items are positioned in the area where the SAB inflates. Children are at an even greater risk of injury from a deploying air bag.
90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Supplemental Side Air Bag Inflatable Curtains (SABICs): Located above the side windows. The trim covering the SABICs is labeled “SRS AIRBAG” or “AIRBAG.” SABICs may help reduce the risk of head or other injuries to front and rear seat outboard occupants in certain side impacts and/or vehicle rollover events, in addition to the injury reduction potential provided by the seat belts and body structure. The SABICs deploy downward, covering the side windows.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 91 WARNING! • Your vehicle is equipped with left and right Supplemental Side Air Bag Inflatable Curtains (SABICs). Do not stack luggage or other cargo up high enough to block the deployment of the SABICs. The trim covering above the side windows where the SABIC and its deployment path are located should remain free from any obstructions. • Your vehicle is equipped with SABICs.
92 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE help keep you in position, away from inflating Side Air Bags. To get the best protection from the Side Air Bags, occupants must wear their seat belts properly and sit upright with their backs against the seats. Children must be properly restrained in a child restraint or booster seat that is appropriate for the size of the child. WARNING! • Side Air Bags need room to inflate. Do not lean against the door or window. Sit upright in the center of the seat.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 93 The Side Air Bags will not deploy in all side collisions, including some collisions at certain angles, or some side collisions that do not impact the area of the passenger compartment. The Side Air Bags may deploy during angled or offset frontal collisions where the Advanced Front Air Bags deploy. faster-developing event may deploy the seat belt pretensioners as well as the Side Air Bags on both sides of the vehicle.
94 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE deploy and unfold. The abrasions are similar to fric- Do not drive your vehicle after the air bags have detion rope burns or those you might get sliding along a ployed. If you are involved in another collision, the air carpet or gymnasium floor. They are not caused by bags will not be in place to protect you. contact with chemicals. They are not permanent and normally heal quickly.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 95 Enhanced Accident Response System Enhanced Accident Response System Reset In the event of an impact, if the communication network Procedure remains intact, and the power remains intact, depending In order to reset the Enhanced Accident Response System on the nature of the event, the ORC will determine functions after an event, the ignition switch must be whether to have the Enhanced Accident Response Sys- changed from ignition START or ON/RUN to ignition OFF.
96 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the OFF position or in the ACC position, the air bag While the air bag system is designed to be maintenance system is not on and the air bags will not inflate. free, if any of the following occurs, have an authorized dealer service the air bag system immediately.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 97 WARNING! WARNING! (Continued) Ignoring the Air Bag Warning Light in your instrument panel could mean you won’t have the air bags to protect you in a collision. If the light does not come on as a bulb check when the ignition is first placed in the on position, and stays on after you start the vehicle, or if it comes on as you drive, have an authorized dealer service the air bag system immediately.
98 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) seat attachment bolts), take the vehicle to your authorized dealer. Only manufacturer approved seat accessories may be used. If it is necessary to modify the air bag system for persons with disabilities, contact your authorized dealer. Event Data Recorder (EDR) This vehicle is equipped with an event data recorder (EDR).
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 99 To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR. Child Restraints Everyone in your vehicle needs to be buckled up at all times, including babies and children.
100 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE There are different sizes and types of restraints for NOTE: children from newborn size to the child almost large • For additional information, refer to www.seatcheck.org enough for an adult safety belt. Always check the child or call 1–866–732–8243. seat Owner’s Manual to make sure you have the correct seat for your child. Carefully read and follow all the • Canadian residents should refer to Transport Canada’s website for additional information: www.tc.gc.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 101 Summary Of Recommendations For Restraining Children In Vehicles Infants and Toddlers Small Children Larger Children Children Too Large for Child Restraints Child Size, Height, Weight Or Age Children who are two years old or younger and who have not reached the height or weight limits of their child restraint Children who are at least two years old or who have out-grown the height or weight limit of their rear-facing child restraint Children who have out-
102 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants And Child Restraints Safety experts recommend that children ride rear-facing in the vehicle until they are two years old or until they reach either the height or weight limit of their rear-facing child restraint. Two types of child restraints can be used rear-facing: infant carriers and convertible child seats. The infant carrier is only used rear-facing in the vehicle.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 103 WARNING! (Continued) function as it was designed by the car seat manufacturer, and your child may be more severely injured as a result. Older Children And Child Restraints Children who are two years old or who have outgrown their rear-facing convertible child seat can ride forwardfacing in the vehicle.
104 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE seat. The child and belt-positioning booster seat are held in the vehicle by the seat belt. WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the child restraint manufacturer’s directions exactly when installing an infant or child restraint.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 105 2. Do the child’s knees bend comfortably over the front position. If the shoulder belt contacts the face or neck, of the vehicle seat – while they are still sitting all the move the child closer to the center of the vehicle, or use way back? a booster seat to position the seat belt on the child correctly. 3. Does the shoulder belt cross the child’s shoulder between their neck and arm? WARNING! 4.
106 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Recommendations For Attaching Child Restraints Restraint Type Combined Weight of the Child + Child Restraint Rear-Facing Child Restraint Rear-Facing Child Restraint Forward-Facing Child Restraint Forward-Facing Child Restraint Up to 65 lbs (29.5 kg) More than 65 lbs (29.5 kg) Up to 65 lbs (29.5 kg) More than 65 lbs (29.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 107 Lower Anchors And Tethers For Children (LATCH) Restraint System Your vehicle is equipped with the child restraint anchorage system called LATCH, which stands for Lower Anchors and Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCHequipped child seats. There are two lower anchorages located at the back of the seat cushion where it meets the seatback and one top tether anchorage located behind the seating position.
108 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH Positions For Installing Child Restraints In This Vehicle Second Row Bench • Second Row Captains Chairs • Lower Anchorage Symbol 2 anchorages per seating position Top Tether Anchorage Symbol
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 109 Frequently Asked Questions About Installing Child Restraints With LATCH What is the weight limit (child’s weight + 65 lbs (29.5 kg) Use the LATCH anchorage system until weight of the child restraint) for using the the combined weight of the child and the LATCH anchorage system to attach the child restraint is 65 lbs (29.5 kg). Use the child restraint? seat belt and tether anchor instead of the LATCH system once the combined weight is more than 65 lbs (29.
110 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Frequently Asked Questions About Installing Child Restraints With LATCH Can the rear-facing child restraint touch Yes The child seat may touch the back of the the back of the front passenger seat? front passenger seat if the child restraint manufacturer also allows contact. See your child restraint owner’s manual for more information. Can the head restraints be removed? Yes The 2nd row head restraints on bench and fixed quad seats are removable.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 111 Locating LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback. They are just visible when you lean into the rear seat to install the child restraint. You will easily feel them if you run your finger along the gap between the seatback and seat cushion.
112 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH Anchorages (Third Row 60/40 Anchorages Shown) Tether Strap Anchorages (Third Row 60/40 Anchorage Shown) LATCH-compatible child restraint systems will be equipped with a rigid bar or a flexible strap on each side. There are tether strap anchorages behind each Each will have a hook or connector to attach to the lower rear seating position located on the back of the anchorage and a way to tighten the connection to the anchorage.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 113 rear-facing child restraints will also be equipped with a Always follow the directions of the child restraint manutether strap. The tether strap will have a hook at the end facturer when installing your child restraint. Not all child to attach to the top tether anchorage and a way to tighten restraint systems will be installed as described here. the strap after it is attached to the anchorage.
114 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE forward and rearward in the vehicle, you may wish to 6. Test that the child restraint is installed tightly by move it to its rear-most position to make room for the pulling back and forth on the child seat at the belt path. It should not move more than 1 inch (25.4 mm) child seat. You may also move the front seat forward in any direction. to allow more room for the child seat. 3.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 115 WARNING! • Improper installation of a child restraint to the LATCH anchorages can lead to failure of the restraint. The child could be badly injured or killed. Follow the child restraint manufacturer’s directions exactly when installing an infant or child restraint. • Child restraint anchorages are designed to withstand only those loads imposed by correctly-fitted child restraints.
116 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle Second Row Bench • Cinch = Cinching Latch Plate • ALR = Switchable Automatic Locking Retractor Second Row Captains Chair
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 117 Lap/Shoulder Belt Systems Frequently Asked Question About Installing Child Restraints With Seat Belts What is the weight limit (child’s Weight limit of the Child Restraint Always use the tether anchor when weight + weight of the child reusing the seat belt to install a forstraint) for using the Tether Anchor ward facing child restraint, up to with the seat belt to attach a forthe recommended weight limit of ward facing child restraint? the child restraint.
118 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Can the buckle stalk be twisted to tighten the seat belt against the belt path of the child restraint? Installing A Child Restraint With A Switchable Automatic Locking Retractor (ALR) Yes In positions with cinching latch plates (CINCH), the buckle stalk may be twisted up to 3 full turns. Do not twist the buckle stalk in a seating position with an ALR retractor. 2.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 119 back into the retractor. As the webbing retracts, you 9. Test that the child restraint is installed tightly by will hear a clicking sound. This means the seat belt is pulling back and forth on the child seat at the belt path. It should not move more than 1 inch (25.4 mm) now in the Automatic Locking mode. in any direction. 6. Try to pull the webbing out of the retractor.
120 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Next, pull enough of the seat belt webbing from the 6. Test that the child restraint is installed tightly by retractor to pass it through the belt path of the child pulling back and forth on the child seat at the belt path. It should not move more than 1 inch (25.4 mm) restraint. Do not twist the belt webbing in the belt in any direction. path. 3.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 121 If the belt still cannot be tightened after you shorten the buckle, disconnect the latch plate from the buckle, turn the buckle around one half turn, and insert the latch plate into the buckle again. If you still cannot make the child restraint installation tight, try a different seating position. WARNING! (Continued) (LATCH) Restraint System” for the location of approved tether anchorages in your vehicle.
122 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE tether anchorage for that seating position, move the 4. Remove slack in the tether strap according to the child child restraint to another position in the vehicle if one restraint manufacturer’s instructions. is available. 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 123 WARNING! (Continued) child. Use only the anchorage position directly behind the child seat to secure a child restraint top tether strap. • If your vehicle is equipped with a split rear seat, make sure the tether strap does not slip into the opening between the seatbacks as you remove slack in the strap.
124 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. CAUTION! Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result. Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or NOTE: A new engine may consume some oil during its first few thousand miles (kilometers) of operation.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 125 WARNING! • Do not leave children or animals inside parked vehicles in hot weather. Interior heat build-up may cause serious injury or death. • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. • Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts.
126 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • If it is necessary to sit in a parked vehicle with the engine running, adjust your heating or cooling controls to force outside air into the vehicle. Set the blower at high speed. Safety Checks You Should Make Inside The Vehicle Seat Belts Inspect the seat belt system periodically, checking for cuts, frays, and loose parts. Damaged parts must be replaced immediately.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 127 not lit during starting, see your authorized dealer. If the light stays on, flickers, or comes on while driving, have the system checked by an authorized dealer. Defroster Check operation by selecting the defrost mode and place the blower control on high speed. You should be able to feel the air directed against the windshield. See your authorized dealer for service if your defroster is inoperable.
128 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Check mounting of mats on a regular basis. Always properly reinstall and secure floor mats that have been removed for cleaning. • Always make sure that objects cannot fall into the driver footwell while the vehicle is moving. Objects can become trapped under the brake pedal and accelerator pedal causing a loss of vehicle control. • If required, mounting posts must be properly installed, if not equipped from the factory.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 129 Door Latches Check for proper closing, latching, and locking. Fluid Leaks Check area under vehicle after overnight parking for fuel, engine coolant, oil, or other fluid leaks. Also, if gasoline fumes are detected or if fuel, power steering fluid (if equipped), or brake fluid leaks are suspected. The cause should be located and corrected immediately.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS 䡵 MIRRORS . . . . . . . . . . . . . . . . . . . . . . . . . . . .138 ▫ Inside Day/Night Mirror — If Equipped . . . .138 ▫ Automatic Dimming Mirror — If Equipped . . .138 ▫ Outside Mirrors . . . . . . . . . . . . . . . . . . . . . .140 ▫ Driver’s Outside Automatic Dimming Mirror — If Equipped . . . . . . . . . . . . . . . . . . . . . . . . . . .140 ▫ Outside Mirrors Folding Feature . . . . . . . . . .140 ▫ Power Mirrors — If Equipped . . . . . . . . . . . .
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Operation . . . . . . . . . . . . . . . . . . . . . . . . . . .155 ▫ Power Lumbar — If Equipped . . . . . . . . . . . .192 ▫ Phone Call Features . . . . . . . . . . . . . . . . . . . .163 ▫ Heated Seats — If Equipped . . . . . . . . . . . . . .192 ▫ Uconnect Phone Features . . . . . . . . . . . . . . . .166 ▫ Manual Front/Second Row Seat Adjuster . . . .195 ▫ Advanced Phone Connectivity . . . . . . . . . . . .
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 䡵 DRIVER MEMORY SEAT — IF EQUIPPED . . . . .220 ▫ Daytime Running Lights — If Equipped . . . . .228 ▫ Programming The Memory Feature . . . . . . . . .221 ▫ Front Fog Lights — If Equipped . . . . . . . . . . .229 ▫ Linking And Unlinking The Remote Keyless Entry Transmitter To Memory . . . . . . . . . . . . . . . . .221 ▫ Dimmer Controls . . . . . . . . . . . . . . . . . . . . .229 ▫ Memory Position Recall . . . . . . . . . . . . . . . . .
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 䡵 䡵 䡵 䡵 ▫ Windshield Washers. . . . . . . . . . . . . . . . . . . .236 ▫ To Vary The Speed Setting . . . . . . . . . . . . . . .245 ▫ Mist Feature . . . . . . . . . . . . . . . . . . . . . . . . .237 ▫ To Accelerate For Passing . . . . . . . . . . . . . . . .247 ▫ Rear Wiper And Washer . . . . . . . . . . . . . . . . .237 䡵 PARKSENSE REAR PARK ASSIST — IF EQUIPPED . . . . . . . . . . . . . . . . . . . . . . . . . ▫ Rain Sensing Wipers — If Equipped . . .
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 䡵 OVERHEAD CONSOLES . . . . . . . . . . . . . . . . .258 ▫ Troubleshooting Tips . . . . . . . . . . . . . . . . . . .270 ▫ Front Overhead Console. . . . . . . . . . . . . . . . .258 ▫ General Information. . . . . . . . . . . . . . . . . . . .271 ▫ Courtesy/Interior Lighting . . . . . . . . . . . . . .258 䡵 POWER SUNROOF — IF EQUIPPED . . . . . . . .271 ▫ Sunglass Storage (Non-Sunroof Only) . . . . . . .259 ▫ Opening Sunroof — Express . . . . . . . . . . .
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 䡵 ELECTRICAL POWER OUTLETS — IF EQUIPPED . . . . . . . . . . . . . . . . . . . . . . . . . . .275 䡵 POWER INVERTER — IF EQUIPPED. . . . . . . . .279 䡵 CUPHOLDERS . . . . . . . . . . . . . . . . . . . . . . . .280 ▫ Instrument Panel Cupholders . . . . . . . . . . . . .281 ▫ Driver Seatback Storage — If Equipped . . . . . .285 ▫ Umbrella Holder . . . . . . . . . . . . . . . . . . . . .286 ▫ Second Row Floor Storage Bins . . . . . . . . . . . .
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 䡵 REAR WINDOW FEATURES . . . . . . . . . . . . . .298 䡵 ROOF LUGGAGE RACK — IF EQUIPPED . . . .299 ▫ Rear Window Defroster . . . . . . . . . . . . . . . . .298 ▫ Deploying The Crossbars . . . . . . . . . . . . . . . .300 䡵 LOAD LEVELING SYSTEM — IF EQUIPPED . .299 䡵 SUN SCREENS — IF EQUIPPED . . . . . . . . . . . .
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror — If Equipped A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle). The mirror should be adjusted while set in the day position (toward the windshield).
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pushing the button at the base of the mirror. A light to the left of the button will illuminate to indicate when the dimming feature is activated. The sensor to the right of the button does not illuminate. 3 NOTE: This feature is disabled when the vehicle is moving in reverse.
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE by the inside automatic dimming mirror and will automatically adjust for headlight glare when the inside To receive maximum benefit, adjust the outside mirror(s) mirror adjusts. to center on the adjacent lane of traffic with a slight overlap of the view obtained on the inside mirror. Outside Mirrors Folding Feature Outside Mirrors WARNING! Vehicles and other objects seen in an outside convex mirror will look smaller and farther away than they really are.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 Using the mirror control switch, push on any of the four arrows for the direction that you want the mirror to move. Left and Right side power mirror preselected positions can be controlled by the optional Driver Memory Seat Feature. Refer to “Driver Memory Seat” in “Understanding The Features Of Your Vehicle” for further information. Heated Mirrors — If Equipped These mirrors are heated to melt frost or ice.
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Tilt Mirrors In Reverse (Available With Memory Seat Only) — If Equipped Tilt Mirrors in Reverse provides automatic outside mirror positioning which will aid the drivers view of the ground rearward of the front doors. The driver’s outside mirror will move slightly downward from the present position when the vehicle is shifted into REVERSE. The driver’s outside mirror will then return to the original position when the vehicle is shifted out of REVERSE position.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 Resetting The Power Folding Outside Mirrors You may need to reset the power folding mirrors if the following occurs: • The mirrors are accidentally blocked while folding. • The mirrors are accidentally manually folded/ unfolded. • The mirrors come out of the unfolded position. • The mirrors shake and vibrate at normal driving speeds.
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Illuminated Vanity Mirrors — If Equipped BLIND SPOT MONITORING (BSM) — IF An illuminated vanity mirror is located on the sun visor. EQUIPPED To use the mirror, rotate the sun visor down and swing The Blind Spot Monitoring (BSM) system uses two radarthe mirror cover upward. The lights turn on automati- based sensors, located inside the rear bumper fascia, to detect highway licensable vehicles (automobiles, trucks, cally.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 3 Rear Detection Zones BSM Warning Light When the vehicle is started, the BSM warning light will The BSM detection zone covers approximately one lane momentarily illuminate in both outside rear view mirrors width on both sides of the vehicle 12 ft (3.8 m). The zone to let the driver know that the system is operational.
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE both sides of the vehicle when the vehicle speed reaches The area on the rear fascia where the radar sensors are approximately 6 mph (10 km/h) or higher and will alert located must remain free of snow, ice, and dirt/road contamination so that the BSM system can function the driver of vehicles in these areas. properly.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 Entering From The Side Entering From The Rear Vehicles that move into your adjacent lanes from either Vehicles that come up from behind your vehicle on either side of the vehicle. side and enter the rear detection zone with a relative speed of less than 30 mph (48 km/h).
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Overtaking Traffic If you pass another vehicle slowly (with a relative speed of less than 15 mph (24 km/h) and the vehicle remains in the blind spot for approximately 1.5 seconds, the warning light will be illuminated. If the difference in speed between the two vehicles is greater than 15 mph (24 km/h), the warning light will not illuminate.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 The BSM system is designed not to issue an alert on The BSM system will not alert you of objects that are stationary objects such as guardrails, posts, walls, foliage, traveling in the opposite direction of the vehicle in berms, etc. However, occasionally the system may alert adjacent lanes. on such objects. This is normal operation and your vehicle does not require service.
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) system is not designed to detect pedestrians, bicyclists, or animals. Even if your vehicle is equipped with the BSM system, always check your vehicle’s mirrors, glance over your shoulder, and use your turn signal before changing lanes. Failure to do so can result in serious injury or death. Rear Cross Path (RCP) Opposing Traffic WARNING! The Blind Spot Monitoring system is only an aid to help detect objects in the blind spot zones.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 NOTE: In a parking lot situation, oncoming vehicles can be obscured by vehicles parked on either side. If the sensors are blocked by other structures or vehicles, the system will not be able to alert the driver. When RCP is on and the vehicle is in REVERSE, the driver is alerted using both the visual and audible alarms, including reducing the radio volume.
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Modes Of Operation Blind Spot Alert Lights/Chime Modes Of Operation With EVIC When operating in Blind Spot Alert Lights/Chime mode, the BSM system will provide a visual alert in the appropriate side view mirror based on a detected object. If the turn signal is then activated, and it corresponds to an alert present on that side of the vehicle, an audible chime will also be sounded.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 When the system is in RCP, the system shall respond with both visual and audible alerts when a detected object is present. Whenever an audible alert is requested, the radio volume is reduced. Turn/hazard signal status is ignored; the RCP state always requests the chime.
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE UCONNECT PHONE — IF EQUIPPED Uconnect Phone is a voice-activated, hands-free, invehicle communications system. Uconnect Phone allows you to dial a phone number with your mobile phone using simple voice commands (e.g., “Call” ѧ “Mike” ѧ “Work” or “Dial” ѧ “248-555-1212”). Your mobile phone’s audio is transmitted through your vehicle’s audio system; the system will automatically mute your radio when using the Uconnect Phone.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 system at a time. The system is available in English, access the system. When you push the button you will hear the word Uconnect followed by a BEEP. The beep Spanish, or French languages. is your signal to give a command. WARNING! Any voice commanded system should be used only in safe driving conditions following all applicable laws, including laws regarding phone use. Your attention should be focused on safely operating the vehicle.
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The radio display will be used for visual prompts from • For each feature explanation in this section, only the compound form of the voice command is given. You the Uconnect Phone such as “CELL” or caller ID on can also break the commands into parts and say each certain radios. part of the command when you are asked for it.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 To activate the Uconnect Phone, simply push the Phone The following are general phone to Uconnect Phone button and follow the audible prompts for direc- pairing instructions: tions. Uconnect Phone sessions begin with a push of 1. Enable Bluetooth on your mobile phone. button on the radio control head. the Phone 2. Push the Phone button to begin. Cancel Command At any prompt, after the beep, you can say “Cancel” and 3.
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • You will then be asked to give your mobile phone a Dial By Saying A Number priority level between one and seven, with one being To dial a number using Voice Command: the highest priority. button to begin. 1. Push the Phone You can pair up to seven mobile phones to your Uconnect Phone. However, at any given time, only one mobile 2. After the “Ready” prompt and the following beep, say “Dial.” phone can be in use, connected to your Uconnect System.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 2. After the “Ready” prompt and the following beep, say • To call a name from the Uconnect Phonebook or downloaded Phonebook, follow the procedure in “Call “Call.” by Saying a Name” section.
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Either the mobile phone’s phonebook or the mobile 3. When prompted, say the name of the new entry. phone’s SIM card phonebook is downloaded. • Use of long names helps the Voice Command and is recommended. For example, say “Robert Smith” or • This downloaded phonebook cannot be edited or “Robert” instead of “Bob.” deleted on the Uconnect Phone. These can only be edited on the mobile phone. The changes are trans- 4.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 The Uconnect Phone will allow you to enter up to 32 2. After the “Ready” prompt and the following beep, say names in the phonebook with each name having up to “Phonebook Edit Entry.” four associated phone numbers and designations. Each • You will then be asked for the name of the phonelanguage has a separate 32-name phonebook accessible book entry that you wish to edit. only in that language.
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE mobile and a home number, but you can add “John 2. After the “Ready” prompt and the following beep, say Doe’s” work number later using the “Phonebook Edit “Phonebook Delete.” Entry” feature. 3. After you enter the Phonebook Delete menu, you will Delete Uconnect Phonebook Entry then be asked for the name of the entry that you wish to delete.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 Delete/Erase “All” Uconnect Phonebook Entries List All Names In The Uconnect Phonebook NOTE: To list ALL names in the Uconnect Phonebook using voice Command: • ONLY the phonebook in the current language is de1. Push the Phone leted. button to begin. • Automatic downloaded phonebook entries cannot be 2. After the “Ready” prompt and the following beep, say “Phonebook List Names.” deleted or edited.
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE button until you 4. The Uconnect Phone will then prompt you as to the the call, push and hold the Phone hear a single beep, indicating that the incoming call number designation you wish to call. was rejected. 5. The selected number will be dialed.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 Making A Second Call While Current Call Is In Progress To make a second call while you are currently on a call, push the Voice Command button and say “Dial” or “Call” followed by the phone number or phonebook entry you wish to call. The first call will be on hold while the second call is in progress. To go back to the first call, refer to “Toggling Between Calls” in this section. To combine two calls, refer to “Conference Call” in this section.
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the second call has established, push and hold the Redial button until you hear a double beep, indiPhone • Push the Phone button to begin. cating that the two calls have been joined into one • After the “Ready” prompt and the following beep, say conference call. “Redial.” Call Termination • The Uconnect Phone will call the last number that was To end a call in progress: dialed from your mobile phone. button. 1.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 ends, or until the vehicle battery condition dictates • Continue to follow the system prompts to complete the language selection. cessation of the call on the Uconnect Phone and transfer of the call to the mobile phone. After selecting one of the languages, all prompts and • After the ignition key is cycled to OFF, a call can voice commands will be in that language.
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If the phone is not reachable and the Uconnect Phone is • If supported, this number may be programmable on some systems. To do this, push the Phone button operational, you may reach the emergency number as and say “Setup,” followed by “Emergency.” follows: • The Uconnect Phone does slightly lower your chances of successfully making a phone call as to that for the • After the “Ready” prompt and the following beep, say mobile phone directly.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 Roadside Assistance/Towing Assistance Voice Mail Calling If you need roadside assistance: To learn how to access your voice mail, refer to “Working with Automated Systems.” • Push the Phone button to begin. Working With Automated Systems • After the “Ready” prompt and the following beep, say This method is used in instances where one generally has “Towing Assistance.
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE required to enter your PIN followed with a pound, (3 NOTE: button 7 4 6 #), you can push the Voice Command • You may not hear all of the tones due to mobile phone and say, “3 7 4 6 # Send.” Saying a number, or network configurations. This is normal.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 Turning Confirmation Prompts ON/OFF using Uconnect Phone. The status is given for network signal strength, phone battery strength, etc. Turning confirmation prompts off will stop the system from confirming your choices (e.g., the Uconnect Phone Dialing Using The Mobile Phone Keypad will not repeat a phone number before you dial it). You can dial a phone number with your mobile phone keypad and still use the Uconnect Phone (while dialing button to begin.
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE from your Uconnect Phone paired mobile phone to the Uconnect Phone or vice versa, push the Voice Command When you mute the Uconnect Phone, you will still be button and say “Transfer Call.” able to hear the conversation coming from the other party, but the other party will not be able to hear you. To Connect Or Disconnect Link Between The mute the Uconnect Phone: Uconnect Phone And Mobile Phone Mute/Un-Mute (Mute ON/OFF) • Push the Voice Command button.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 2. After the “Ready” prompt and the following beep, say To select another mobile phone using Voice Command: “Setup Phone Pairing.” 1. Push the Phone button to begin. 3. When prompted, say “List Phones.” 2. After the “Ready” prompt and the following beep, say “Setup Select Phone” and follow the prompts.
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Delete Uconnect Phone Paired Mobile Phones Voice Training To delete Uconnect phone paired mobile phones using For users experiencing difficulty with the system recogVoice Command: nizing their voice commands or numbers, the Uconnect Phone Voice Training feature may be used. To enter this button to begin. 1. Push the Phone training mode, follow one of the two following proce2. After the “Ready” prompt and the following beep, say dures: “Setup Phone Pairing.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 Voice Training session should be completed when the Voice Command vehicle is parked with the engine running, all windows For best performance: closed, and the blower fan switched off. • Adjust the rearview mirror to provide at least ½ inch This procedure may be repeated with a new user. The (1 cm) gap between the overhead console (if equipped) system will adapt to the last trained voice only. and the mirror. Reset • Always wait for the beep before speaking.
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Performance is maximized under: • Low-to-medium blower setting • Low-to-medium vehicle speed • Low road noise • Smooth road surface • Fully closed windows • Dry weather condition NOTE: • Storing names in the phonebook when the vehicle is not in motion is recommended. • It is not recommended to store similar sounding names in the Uconnect Phonebook.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 Far End Audio Performance Audio quality is maximized under: • Low-to-medium blower setting • Low-to-medium vehicle speed • Low road noise • Smooth road surface • Fully closed windows • Echo at the phone far end can sometimes be reduced by lowering the in-vehicle audio volume. • In a convertible vehicle, system performance may be compromised with the convertible top down.
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Read Messages: 2. After the “Ready” prompt and the following beep, say “SMS Send” or “Send Message.” If you receive a new text message while your phone is connected to Uconnect Phone, an announcement will be 3. You can either say the message you wish to send or made to notify you that you have a new text message. If say “List Messages.” There are 20 preset messages. you wish to hear the new message: butTo send a message, push the Voice Command button.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 11. See You in 15 minutes 16. Can this wait? Bluetooth Communication Link 12. I am on my way 17. Bye for now 13. I’ll be late 18. When can we meet? 14. Are you there yet? 19. Send number to call Mobile phones have been found to lose connection to the Uconnect Phone. When this happens, the connection can generally be re-established by switching the phone off/ on. Your mobile phone is recommended to remain in Bluetooth ON mode. 15.
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 3
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 Voice Commands Primary zero one two three four five six seven eight nine star (*) plus (+) pound (#) add location Alternate (s) Primary all call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol Francais help Alternate (s) 3
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Primary home language list names list phones mobile mute mute off new entry no other pair a phone phone pairing phonebook previous Alternate (s) pairing phone book Primary record again redial return to main menu select phone send set up towing assistance transfer call Uconnect Tutorial voice training work yes Alternate (s) return or main menu select phone settings or phone set up
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 General Information VOICE COMMAND — IF EQUIPPED This device complies with Part 15 of the FCC rules and Voice Command System Operation RSS 210 of Industry Canada.
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Any voice commanded system should be used only in safe driving conditions following all applicable laws, including laws regarding phone use. Your attention should be focused on safely operating the vehicle. Failure to do so may result in a collision causing serious injury or death. Pushing the Voice Command button while the system is speaking is known as “barging in.” The system will be interrupted, and after the beep, you can add or change commands.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 To hear the first available Menu, push the Voice Com- Main Menu button and say “Help” or “Main Menu.” mand Start a dialogue by pushing the Voice Command button. You may say “Main Menu” to switch to Commands the main menu. The Voice Command system understands two types of commands, Universal commands and Local commands. In this mode, you can say the following commands: Universal commands are available at all times.
188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Radio AM • “Menu Radio” (to switch to the radio menu) To switch to the AM band, say “AM” or “Radio AM.” In • “Main Menu” (to switch to the main menu) this mode, you may say the following commands: Satellite Radio • “Frequency #” (to change the frequency) To switch to satellite radio mode, say “Sat” or “Satellite Radio.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 Disc Mode • “Play” (to play an Artist Name, Playlist Name, Album Name, Track Name, etc.) To switch to the disc mode, say “Disc.” In this mode, you may say the following commands: Bluetooth Streaming (BT) Mode • “Track” (#) (to change the track) • “Next Track” (to play the next track) • “Previous Track” (to play the previous track) • “Main Menu” (to switch to the main menu) To switch to Bluetooth Streaming (BT) mode, say “Bluetooth Streaming.
190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Memo Mode – “Previous” (to play the previous memo) To switch to the voice recorder mode, say “Memo.” In this mode, you may say the following commands: – “Delete” (to delete a memo) – “Delete All” (to delete all memos) • “New Memo” (to record a new memo) — During the Setup recording, you may push the Voice Command button to stop recording.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 • “Tutorial” 2. Repeat the words and phrases when prompted by Uconnect Voice. For best results, the “Voice Training” • “Voice Training” session should be completed when the vehicle is NOTE: Keep in mind that you have to push the Voice parked, engine running, all windows closed, and the button first and wait for the beep Command blower fan switched off. This procedure may be rebefore speaking the “Barge In” commands. peated with a new user.
192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts. In a collision, people riding in these areas are more likely to be seriously injured or killed. • Be sure everyone in your vehicle is in a seat and using a seat belt properly. Power Seats — If Equipped Some models may be equipped with eight-way power seats for the driver and front passenger.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 WARNING! CAUTION! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seat belts and while the vehicle is parked. Serious injury or death could result from a poorly adjusted seat belt. • Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest.
194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Tilting The Seat Up Or Down The angle of the seat cushion can be adjusted in four directions. Pull upward or push downward on the front or rear of the seat switch, the front or rear of the seat cushion will move in the direction of the switch. Release the switch when the desired position has been reached. Reclining The Seatback The angle of the seatback can be adjusted forward or rearward.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 CAUTION! Do not place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path. Power Lumbar — If Equipped Vehicles equipped with power driver or passenger seats may also be equipped with power lumbar. The power lumbar switch is located on the outboard side of the Power Lumbar Switch power seat.
196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time. • Do not place anything on the seat or seatback that insulates against heat, such as a blanket or cushion.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 NOTE: Once a heat setting is selected, heat will be felt within two to five minutes. If the HI-level setting is selected, the system will automatically switch to LO-level after approximately 60 minutes of continuous operation. At that time, the display will change from HI to LO, indicating the change. The LO-level setting will turn OFF automatically after approximately 45 minutes.
198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE You can choose from HI, LO or OFF heat settings. Amber indicator lights in each switch indicate the level of heat in use. Two indicator lights will illuminate for HI, one for LO and none for OFF. Push the switch once to select HI-level heating. Push the switch a second time to select LOlevel heating. Push the switch a third time to shut the heating elements OFF. NOTE: Once a heat setting is selected, heat will be felt within two to five minutes.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seat belts and while the vehicle is parked. Serious injury or death could result from a poorly adjusted seat belt.
200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death. Head Restraints Manual Recline Lever To recline, lean forward slightly, lift the lever, then push back to the desired position and release the lever. Lean forward and lift the lever to return the seatback to its normal position.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201 WARNING! (Continued) never be adjusted while the vehicle is in motion. Driving a vehicle with the head restraints improperly adjusted or removed could cause serious injury or death in the event of a collision. Supplemental Active Head Restraints — Front Seats When AHRs deploy during a rear impact, the front half of the head restraint extends forward to reduce the gap between the back of the occupant’s head and the AHR.
202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjustment Button For comfort the Active Head Restraints can be tilted forward and rearward. To tilt the head restraint closer to the back of your head, pull forward on the bottom of the head restraint. Push rearward on the bottom of the head restraint to move the head restraint away from your head.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203 • In the event of deployment of an Active Head Restraint, refer to “Occupant Restraints/Resetting Active Head Restraints (AHR)” in “Things To Know Before Starting Your Vehicle” for further information. 3 WARNING! Active Head Restraint (Tilted) NOTE: • The head restraints should only be removed by qualified technicians, for service purposes only. If either of the head restraints require removal, see your authorized dealer.
204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Active Head Restraints may be deployed if they are struck by an object such as a hand, foot or loose cargo. To avoid accidental deployment of the Active Head Restraint ensure that all cargo is secured, as loose cargo could contact the Active Head Restraint during sudden stops. Failure to follow this warning could cause personal injury if the Active Head Restraint is deployed.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205 Head Restraints — Third Row NOTE: Seat will not stow in the storage bin unless the armrests are raised. The head restraint in the center position can be raised and lowered for tether routing. Refer to “Occupant Re- 4. Slide the storage bin locking mechanism to the straints” in “Things To Know Before Starting Your Ve“LOCK” position and then pull up on the storage bin hicle” for further information. latch to open the cover.
206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 5. Pull upward on the seatback recliner lever located on The non-adjustable head restraint and seatback will fold the outboard side of the seat. automatically during the seat tumble. No additional actuation is necessary.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207 3 Automatic Folding Seatback Tumbled Second Row Seat The seat will automatically tumble into position for easy 6. Push the seat into the storage bin. storage.
208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! The storage bin cover must be locked and flat to avoid damage from contact with the front seat tracks, which have minimal clearance to the cover. WARNING! Seat In Storage Bin 7. Close the storage bin cover. In a collision, serious injury could result if the seat storage bin covers are not properly latched. • Do not drive the vehicle with the storage bin covers open. • Keep the storage bin covers closed and latched while the vehicle is in motion.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209 To Unstow Second Row Seats WARNING! (Continued) 1. Pull up on the storage bin latch to open the cover. 2. Pull up on the strap to lift the seat out of the storage bin and push the seat rearward to latch the seat anchors. 3. Lift the seatback to the full upright position. • Sitting in a seat with the head restraint in its lowered position could result in serious injury or death in a collision.
210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Raising The Seatback 2. Return the head restraint to the upright position. Raising The Head Restraint 3. Pull up on the seatback recliner lever on the outboard side of the seat to fold head rest and seatback and tumble seat forward.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211 The seat will automatically fold into position for easy The second row Stow ’n Go seats allow easy entry to the entry into the third row. third row seat or rear cargo area. Easy Entry Second Row Pull up on the seatback recliner lever on the outboard side of the seat. WARNING! In the event of a collision you could be injured if the seat is not fully latched. Quad Seats — If Equipped Both Quad seats are adjustable forward or rearward.
212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seat belts and while the vehicle is parked. Serious injury or death could result from a poorly adjusted seat belt.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213 Fold-Flat To fold the seat, lift the recliner lever to the full upward position and push the seatback forward until it rests on the seat cushion. Recline Lever WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death.
214 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For passengers seated in the third row, there is a pull The Quad seats can be tilted forward for easy entry into strap located on the outboard side of the seat near the the third row. With the Quad seat in the fold-flat position, bottom of the seat back. Third row passengers can pull on the strap and push the Quad seat forward for folding the lift up on the easy entry lever located near the bottom of seatback and accessing the easy entry lever.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 215 Removal Second Row Bench Seat — If Equipped The Quad seats can be removed if additional storage is While the bench seat does not stow in the floor, it is needed. With the seat in the easy entry position, push the removable for added cargo space. cross beam forward and up to release the front anchor latches. Second Row Bench Seat Cross Beam For Seat Removal Release levers are located on the rear leg assemblies, near the floor.
216 UNDERSTANDING THE FEATURES OF YOUR VEHICLE indicator button pops up when the seat is unlocked. The upward until the lock indicator button returns into the seat assembly can now be removed from the vehicle and handle. moved on its Easy Out Rollers. WARNING! If not properly latched, the bench seats could become loose. Personal injuries could result. After reinstalling these seats, be sure the red indicator button on the release handles return into the handles.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 217 NOTE: Lower the head restraint by pulling on the release strap marked “1” located on the outboard side of the head restraint. 3 Third Row Power Seat Switch Third Row Power Folding Seat — If Equipped A one-touch power folding seat switch is located in the left rear trim panel as part of a switch bank. Head Restraint Release Strap “1” The switch is only functional when the liftgate is open and the vehicle is in PARK.
218 UNDERSTANDING THE FEATURES OF YOUR VEHICLE One Touch Folding Seat Third Row Rear Panel Power Switch Bank The rear switch bank allows multiple power folding and 1 — Open To Normal unfolding positions for the third row seats. 2 — Stow Left and right third row seats can be folded individually or together.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 219 • The third row power seat system includes obstacle detection for safe operation. When the system detects • Disconnect the center shoulder belt from the small an obstacle, the motors will stop and reverse the buckle and lower the head restraints before attempting motion a short distance to move the seat away from to fold/stow the power third row seats. the obstacle.
220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Lower the outboard head restraints by pulling on the 3. Pull release strap marked “2” located on the rear of the release strap marked “1” located on the outboard side seat to lower the seatback. of the head restraint.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 221 4. Pull release strap marked “3” to release the anchors. 5. Pull release strap marked “4” and tumble the seat rearward into the storage bin.
222 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Pull release strap marked “2” to unlock the recliner. 3. Pulling strap “4” releases the seatback to return to its full upright position. 4. Raise the head restraint to its upright position. WARNING! Stowed Third Row Seat To Unfold Third Row Seats 1. Pull up on the assist strap to lift the seat out of the storage bin and push the seat forward until the anchors latch.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 223 Tailgate Mode Plastic Grocery Bag Retainer Hooks 1. Pull release strap “3”, then pull release strap “4” to Retainer hooks which will hold plastic grocery bag handles are built into the seatbacks of all rear seats and rotate the entire seat rearward. some front seats. The floor supports the partial weight of 2. To restore the seat to its upright position, lift up on the the bagged goods. seatback and push forward until the anchors latch.
224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming The Memory Feature NOTE: To create a new memory profile, perform the following: 1. Cycle the vehicles ignition to the ON/RUN position (do not start the engine). 2. Adjust all memory profile settings to desired preferences (i.e., driver’s seat, outside mirrors, adjustable pedals [if equipped] and radio station presets). 3. Push and release the S (Set) button on the memory switch.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 225 NOTE: Before programming your RKE transmitters you must select the “RKE Linked To Memory” feature • Memory profiles can be set without the vehicle in through the Electronic Vehicle Information Center PARK, but the vehicle must be in PARK to recall a (EVIC). Refer to “Electronic Vehicle Information Center memory profile. (EVIC) ” in “Understanding Your Instrument Panel” for • To set a memory profile to your RKE transmitter, refer further information.
226 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Push and release button (1) or (2) accordingly. To recall the memory setting for driver two, push MEMORY “Memory Profile Set” (1 or 2) will display in the button 2 on the driver’s door or the UNLOCK button on the RKE transmitter linked to Memory Position 2. instrument cluster. 5. Push and release the LOCK button on the RKE trans- A recall can be cancelled by pushing any of the MEMORY buttons on the driver’s door during a recall (S, 1, or 2).
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 227 The distance the driver seat moves depends on where • The Easy Entry/Easy Exit feature is disabled when the you have the driver seat positioned when you remove the driver seat position is less than 0.9 inches (22.7 mm) forward of the rear stop. At this position, there is no key from the ignition switch. benefit to the driver by moving the seat for Easy Exit • When you remove the key from the ignition switch, or Easy Entry. the driver seat will move about 2.
228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Move to the front of the vehicle and look inside the center of the hood opening. Locate, then push the To open the hood, two latches must be released. safety catch lever downward while raising the hood at 1. Pull the hood release lever located on the instrument the same time. panel, below the steering column.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229 Use the hood prop rod to secure the hood in the open position. CAUTION! To prevent possible damage, do not slam the hood to close it. Lower the hood until it is open approximately 6 inches (15 cm), and then drop it. This should secure both latches. Never drive your vehicle unless the hood is fully closed, with both latches engaged. WARNING! Be sure the hood is fully latched before driving your vehicle.
230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Headlights — If Equipped This system automatically turns your headlights on or off based on ambient light levels. To turn the system on, turn the headlight switch to the extreme counterclockwise position aligning the indicator with the AUTO on the headlight switch. When the system is on, the Headlight Time Delay feature is also on. This means your headlights will stay on for up to 90 seconds after you turn the ignition switch OFF.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 231 on when windshield wipers are on may be found on When exiting the vehicle the driver can choose to have vehicles equipped with an automatic headlight system. the headlights remain on for 30, 60 or 90 seconds or not remain on. To change the timer setting, see your authoNOTE: The Headlights with Wipers feature can be rized dealer. turned on or off through the Electronic Vehicle Information Center (EVIC) — if equipped.
232 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lights-On Reminder If the headlights or the parking lights are left on, or if the dimmer control is in the extreme top position after the ignition switch is turned OFF, a chime will sound when the driver’s door is opened. Daytime Running Lights — If Equipped Front Fog Lights — If Equipped To activate the front fog lights, turn on the parking lights or the low beam headlights and push in the headlight switch control knob.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 233 Interior Lighting On Rotate the left dimmer control completely upward to the second detent (extreme top position) to turn on the interior lights. The interior lights will remain on when the dimmer control is in this position. Interior lights are also turned on when a door or liftgate is opened, the Remote Keyless Entry (RKE) transmitter is activated, or when the dimmer control is moved to the extreme top.
234 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The ignition must be cycled to the OFF position for this feature to operate. Interior Lighting Off Rotate the left dimmer control to the off position (extreme bottom). The interior lights will remain off when the doors or liftgate are open. Parade Mode (Daytime Brightness Feature) Rotate the left dimmer control to the first detent. This feature brightens the odometer, radio and overhead displays when the parking lights or headlights are on.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 235 Multifunction Lever The multifunction lever controls the: The multifunction lever is located on the left side of the • Turn Signals steering column. • Headlight Beams Low/High • Flash-To-Pass • Front and Rear Wipers — Washer Functions Turn Signals Move the multifunction lever up or down and the arrows on each side of the instrument cluster flash to show proper operation of the front and rear turn signal lights.
236 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn Signal Warning Flash-To-Pass If the vehicle electronics sense that the vehicle has traveled at over 18 mph (29 km/h) for about 1 mile (1.6 km) with the turn signals on, a chime will sound to alert the driver. You can signal another vehicle with your headlights by lightly pulling the multifunction lever toward you. This will cause the headlights to turn on at high beam and remain on until the lever is released.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 237 NOTE: Broken, muddy or obstructed headlights and taillights of vehicles in the field of view will cause headlights to remain on longer (closer to the vehicle). Also, dirt, film and other obstructions on the windshield or camera lens will cause the system to function improperly.
238 UNDERSTANDING THE FEATURES OF YOUR VEHICLE when the ignition switch is in the LOCK position. After eight minutes of the ignition switch being in the LOCK Perform either of the following steps to deactivate the position and the headlight switch in any position other Automatic High Beam system. than OFF or AUTO, the lights will turn off automatically 1. Select “Automatic High Beams — OFF” through the until the next cycle of the ignition switch or headlight EVIC.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 239 WARNING! Sudden loss of visibility through the windshield could lead to a collision. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with the defroster before and during windshield washer use. Intermittent Wiper System Washer And Wiper Controls NOTE: Always remove any buildup of snow that prevents the windshield wiper blades from returning to the off position.
240 UNDERSTANDING THE FEATURES OF YOUR VEHICLE cycles. The delay intervals will double in duration when Mist Feature the vehicle speed is 10 mph (16 km/h) or less. Push the end of the multifunction lever inward (toward the steering column) to the first detent and release for a Windshield Wiper Operation single wiping cycle. Rotate the end of the lever upward, to the first detent past the intermittent settings for low-speed wiper operation.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 241 Rain Sensing Wipers — If Equipped NOTE: This feature senses moisture on the windshield and • The Rain Sensing feature will not operate when the automatically activates the wipers for the driver. This wiper speed is in the low or high position. feature is especially useful for road splash or overspray • The Rain Sensing feature may not function properly from the windshield washers of the vehicle ahead.
242 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Rain Sensing system has protective features for the • Remote Start Mode Inhibit — On vehicles equipped wiper blades and arms. It will not operate under the with Remote Starting system, Rain Sensing wipers are not operational when the vehicle is in the remote start following conditions: mode.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 243 steering column in position, push the lever upward until fully engaged. WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driving with the steering column unlocked, could cause the driver to lose control of the vehicle. Failure to follow this warning may result in serious injury or death. Tilt/Telescoping Lever To unlock the steering column, push the lever downward (toward the floor).
244 UNDERSTANDING THE FEATURES OF YOUR VEHICLE off. The heated steering wheel can shut off early or may during a remote start. Refer to “Electronic Vehicle Information Center (EVIC)” in “Understanding Your Instrunot turn on when the steering wheel is already warm. ment Panel” for further information. The heated steering wheel control button is located on the center of the instrument panel below the climate WARNING! controls.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 245 ADJUSTABLE PEDALS — IF EQUIPPED The adjustable pedals system is designed to allow a greater range of driver comfort for steering wheel tilt and seat position. This feature allows the brake, accelerator, and clutch pedals (if equipped) to move toward or away from the driver to provide improved position with the steering wheel. 3 The switch is located on the left side of the steering column.
246 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Push the switch rearward to move the pedals rearward • For vehicles equipped with Driver Memory Seat, you (toward the driver). can use your Remote Keyless Entry (RKE) transmitter or the memory switch on the driver’s door trim panel • The pedals can be adjusted with the ignition OFF. to return the adjustable pedals to pre-programmed • The pedals cannot be adjusted when the vehicle is in positions.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 247 WARNING! Do not adjust the pedals while the vehicle is moving. You could lose control and have an accident. Always adjust the pedals while the vehicle is parked. 3 ELECTRONIC SPEED CONTROL — IF EQUIPPED When engaged, the Electronic Speed Control takes over accelerator operations at speeds greater than 25 mph (40 km/h). The Electronic Speed Control buttons are located on the right side of the steering wheel.
248 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: In order to ensure proper operation, the Electronic Speed Control System has been designed to shut down if multiple Speed Control functions are operated at the same time. If this occurs, the Electronic Speed Control System can be reactivated by pushing the Electronic Speed Control ON/OFF button and resetting the desired vehicle set speed. WARNING! Leaving the Electronic Speed Control system on when not in use is dangerous.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 249 The drivers preferred units can be selected through the instrument panel settings if equipped. Refer to “UnderA soft tap on the brake pedal, pushing the CANCEL standing Your Instrument Panel” for more information. button, or normal brake pressure while slowing the The speed increment shown is dependant on the chosen vehicle will deactivate the Electronic Speed Control withspeed unit of U.S. (mph) or Metric (km/h): out erasing the set speed from memory.
250 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • If the button is continually pushed, the set speed will • If the button is continually pushed, the set speed will continue to increase until the button is released, then continue to decrease until the button is released, then the new set speed will be established. the new set speed will be established.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 251 NOTE: The Electronic Speed Control system maintains PARKSENSE REAR PARK ASSIST — IF speed up and down hills. A slight speed change on EQUIPPED moderate hills is normal. The ParkSense Rear Park Assist system provides visual On steep hills, a greater speed loss or gain may occur so and audible indications of the distance between the rear it may be preferable to drive without Electronic Speed fascia and a detected obstacle when backing up, e.g.
252 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The ParkSense Warning Display is located in the Instrument cluster’s EVIC display. It provides both visual and The four ParkSense sensors, located in the rear fascia/ audible warnings to indicate the distance between the bumper, monitor the area behind the vehicle that is rear fascia/bumper and the detected obstacle. within the sensors’ field of view.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 253 ParkSense Display When the vehicle is in REVERSE, the warning display will turn ON indicating the system status. 3 Park Assist System OFF Park Assist System ON The system will indicate a detected obstacle by showing three solid arcs and will produce a one-half second tone. As the vehicle moves closer to the object the EVIC display will show fewer arcs and the sound tone will change from slow, to fast, to continuous.
254 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Slow Tone Fast Tone
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 255 The vehicle is close to the obstacle when the EVIC display shows one flashing arc and sounds a continuous tone.
256 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Distance (inches/cm) Audible Alert Chime Arcs Radio Volume Reduced Greater than 79 inches (200 cm) None None No WARNING ALERTS 79-39 inches 39-25 inches (200-100 cm) (100-65 cm) Single 1/2 Second Tone 3 Solid (Continuous) Yes NOTE: ParkSense will reduce the radio volume, if on, when the system is sounding an audio tone.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 257 Enabling/Disabling ParkSense Service The ParkSense Rear Park Assist System ParkSense can be enabled and disabled through the Customer-Programmable Features section of the EVIC. The available choices are: OFF, Sound Only, or Sound and Display. Refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer-Programmable Features)” in “Understanding Your Instrument Panel” for further information.
258 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When you move the shift lever to the REVERSE position and ParkSense is turned OFF, the EVIC will Clean the ParkSense sensors with water, car wash soap display “PARK ASSIST SYSTEM OFF” message for as and a soft cloth. Do not use rough or hard cloths. Do not long as the vehicle is in REVERSE. scratch or poke the sensors. Otherwise, you could damage the sensors. • ParkSense, when on, will reduce the radio volume when it is sounding a tone.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259 object as a sensor problem, causing the “SERVICE PARK ASSIST SYSTEM” message to be displayed in the EVIC. CAUTION! • ParkSense is only a parking aid and it is unable to recognize every obstacle, including small obstacles. Parking curbs might be temporarily detected or not detected at all. Obstacles located above or below the sensors will not be detected when they are in close proximity.
260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) could detect the ball mount and hitch ball assembly, depending on its size and shape, giving a false indication that an obstacle is behind the vehicle. When the vehicle is shifted out of REVERSE, the rear camera mode is exited and the last selected touchscreen appears again.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 261 that will help indicate the distance to the rear of the vehicle. The following table shows the approximate distances for each zone: Zone Red Yellow Green Distance to the rear of the vehicle 0 - 1 ft (0 - 30 cm) 1 ft - 3 ft (30 cm - 1 m) 3 ft or greater (1 m or greater) WARNING! WARNING! (Continued) Drivers must be careful when backing up even when using the ParkView Rear Back Up Camera.
262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! OVERHEAD CONSOLES • To avoid vehicle damage, ParkView should only be used as a parking aid. The ParkView camera is unable to view every obstacle or object in your drive path. • To avoid vehicle damage, the vehicle must be driven slowly when using ParkView to be able to stop in time when an obstacle is seen. It is recommended that the driver look frequently over his/her shoulder when using ParkView.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 263 If your vehicle is equipped with Remote Keyless Entry (RKE) the lights will also turn on when the UNLOCK button on the RKE transmitter is pushed. The courtesy lights also function as reading lights. Push in on each lens to turn these lights on while inside the vehicle. Push a second time to turn each light off. You may adjust the direction of these lights by pushing the outside ring, which is identified with four directional arrows (LED lamps only).
264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunglass Storage (Non-Sunroof Only) The door will slowly rotate to the full open position. At the front of the overhead console, a compartment is provided for the storage of two pairs of sunglasses. From the closed position, push the door latch to open the compartment. Full Open Position From this position, the door can be fully closed or, by rotating upward about 3/4 of the way and releasing, positioned for conversation mirror use.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 265 Rear Courtesy/Reading Lights — If Equipped The overhead console has two sets of courtesy lights. The lights turn on when a front door, a sliding door or the liftgate is opened. If your vehicle is equipped with Remote Keyless Entry (RKE) the lights will also turn on when the UNLOCK button on the RKE transmitter is pushed. The courtesy lights also function as reading lights. Push in on each lens to turn these lights on while inside the vehicle.
266 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reading Lights Rear Overhead Consoles — If Equipped Overhead Compartment Features 1 — LCD Screen* The rear overhead storage system is available in two 2 — Rear HVAC 3 — Interior Lights versions: with or without sunroof. 4 — Storage An additional LED at the front of the rear console shines * If equipped, otherwise storage. down on the front foot-well area while in courtesy mode, for added convenience.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267 The HomeLink buttons, located on either the overhead console, headliner or sunvisor, designate the three differThe rear overhead console has recessed halo lighting ent HomeLink channels. The HomeLink indicator is around the perimeter of the console base. This feature located above the center button. provides additional lighting options while traveling and is controlled by the headlight switch.
268 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For more efficient programming and accurate transmission of the radio-frequency signal it is recommended that a new battery be placed in the hand-held transmitter of the device that is being programmed to the HomeLink system. To erase the channels place the ignition in the ON/RUN position and push and hold the two outside HomeLink buttons (I and III) for up 20 seconds or until the red indicator flashes.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 269 Programming A Rolling Code For programming garage door openers that were manufactured after 1995. These garage door openers can be identified by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the garage door opener. It is NOT the button that is normally used to open and close the door. The name and color of the button may vary by manufacturer. 3 Training The Garage Door Opener 1 — Door Opener 2 — Training Button 1.
270 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm) away from the HomeLink button you wish to program while keeping the HomeLink indicator light in view. Firmly push and release the “LEARN” or “TRAINING” button. On some garage door openers/devices there may be a light that blinks when the garage door opener/device is in the LEARN/TRAIN mode. 3.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 271 2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm) away from the HomeLink button you wish to program while keeping the HomeLink indicator light To reprogram a channel that has been previously trained, in view. follow these steps: 3. Push and hold the Homelink button you want to 1. Cycle the ignition to the ON/RUN position. program while you push and hold the hand-held 2. Push and hold the desired HomeLink button until the transmitter button.
272 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • To program the two remaining HomeLink buttons, Canadian/Gate Operator Programming repeat each step for each remaining button. DO NOT For programming transmitters in Canada/United States erase the channels. that require the transmitter signals to “time-out” after several seconds of transmission.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 273 2. Place the hand-held transmitter 1 to 3 inches (3 to 8 NOTE: cm) away from the HomeLink button you wish to • If the indicator light stays on constantly, programprogram while keeping the HomeLink indicator light ming is complete and the garage door/device should in view. activate when the HomeLink button is pushed. 3.
274 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Push and hold the desired HomeLink button until the To do this, push and hold the two outside buttons for 20 indicator light begins to flash after 20 seconds. Do not seconds until the red indicator flashes. Note that all channels will be erased. Individual channels cannot be release the button. erased. 3.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 275 If you have any problems, or require assistance, please call toll-free 800-355-3515 or, on the Internet at HomeLink.com for information or assistance. WARNING! • Vehicle exhaust contains carbon monoxide, a dangerous gas. Do not run your vehicle in the garage while programming the transceiver. Exhaust gas can cause serious injury or death. • Your motorized door or gate will open and close while you are programming the universal transceiver.
276 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: • The transmitter has been tested and it complies with FCC and IC rules. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the device. • The term IC before the certification/registration number only signifies that Industry Canada technical specifications were met. POWER SUNROOF — IF EQUIPPED The power sunroof switch is located between the sun visors on the overhead console.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 277 WARNING! (Continued) accessible to children. Do not leave the ignition of a vehicle equipped with Keyless Enter-N-Go in the ACC or ON/RUN mode. Occupants, particularly unattended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death. • In a collision, there is a greater risk of being thrown from a vehicle with an open sunroof.
278 UNDERSTANDING THE FEATURES OF YOUR VEHICLE position. The sunroof will close fully and stop automati- NOTE: If three consecutive sunroof close attempts result cally. This is called “Express Close”. During Express in Pinch Protect reversals, the fourth close attempt will be Close operation, any movement of the switch will stop a Manual Close movement with Pinch Protect disabled. the sunroof.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 279 Wind Buffeting Ignition Off Operation Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions. This is a normal occurrence and can be minimized. If the buffeting occurs with the rear windows open, open the front and rear windows together to minimize the buffeting.
280 UNDERSTANDING THE FEATURES OF YOUR VEHICLE directly to the battery. The driver-side power outlet will NOTE: To ensure proper operation a MOPAR cigar knob also operate a conventional cigar lighter unit (if equipped and element must be used. with an optional Smoker’s Package). CAUTION! • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 281 One outlet in the removable floor console (if equipped) shares a fuse with the lower outlet in the instrument panel and is also connected to the battery. Do not exceed a maximum power of 160 Watts (13 Amps) shared between the lower panel outlet and the removable floor console outlet. On vehicles equipped with the Super Console the power outlets are located under the retractable cover.
282 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The outlet in the rear quarter panel near the liftgate and the upper outlet in the instrument panel are both controlled by the ignition switch. Each of these outlets can support 160 Watts (13 Amps). Do not exceed 160 Watts (13 Amps) for each of these outlets. The power outlets include tethered caps, labeled with a key or battery symbol indicating the power source. The power outlet, located on the lower instrument panel, is powered directly from the battery.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 283 WARNING! CAUTION! (Continued) To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet. • Do not touch with wet hands. • Close the lid when not in use and while driving the vehicle. • If this outlet is mishandled, it may cause an electric shock and failure. CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e.
284 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER INVERTER — IF EQUIPPED To turn on the power outlet, push the switch once. Push the switch a second time to turn the power outlet off. A 110 Volt, 150 Watt inverter outlet converts DC current to AC current, and is located on the left rear trim panel This outlet can power cellular phones, electronics and immediately behind the second row left passenger seat. other low power devices requiring power up to 150 Watts.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 285 WARNING! To avoid serious injury or death: • Do not insert any objects into the receptacles. • Do not touch with wet hands. • Close the lid when not in use. • If this outlet is mishandled, it may cause an electric shock and failure. Instrument Panel Cupholders The instrument panel cupholders are located in a pull-out drawer just above the lower storage bin. 3 CUPHOLDERS There are cupholders located throughout the interior.
286 UNDERSTANDING THE FEATURES OF YOUR VEHICLE variety of container types and sizes. Push down on the For rear passengers two cupholders are located in the pull-out drawer, located in the back of the Super Console. container to engage the cupholder retention features. Pull the drawer out to the first position to use the Super Console — If Equipped cupholders. On models equipped with the Super Console, there are two cupholders located in the center of the console.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 287 Premium Console Cupholders — If Equipped Interior Bottle Holders On models equipped with premium center consoles, There are four bottle holders located in the interior. One there are four cupholders located on the top of the bottle holder is molded into each front interior door trim console. panels, and one bottle holder is molded into each side sliding interior door trim panel. Each holder accommodates up to a 20 oz (.6 L) plastic bottle.
288 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Smoker’s Package Kit — If Equipped With the optional authorized dealer-installed Smoker’s Package Kit, a removable ash receiver is inserted into one of the two cupholders in the center front instrument panel. To install the ash receiver, align the receiver so the thumb grip on the lid is facing rearward. Push the ash receiver into either of the cup wells to secure. Pull upward on the ash receiver to remove for cleaning and/or storage.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 289 STORAGE Glove Compartments Upper and lower glove compartments are located on the passenger side of the instrument panel. 3 Upper Glove Compartment To open the upper compartment, push in on the button, located on the left side of the upper door. The door will automatically open. Upper Compartment To close the compartment door, push downward on the door’s surface to latch the door closed.
290 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lower Glove Compartment Door Trim Panel Storage To open the lower compartment pull out on the release Front Door Storage handle. Both interior front door panels have multiple pockets for storage. WARNING! If containers of hot liquid are placed in the bottle holder, they can spill when the door is closed, burning the occupants. Be careful when closing the doors to avoid injury.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 291 Umbrella Holder An umbrella holder has been conveniently molded into the left front door entry scuff molding.
292 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pull up on the storage bin latch to open the cover. Slide The area below the floor covers, located in front of the the storage bin locking mechanism to the ⬙unlocked⬙ position to allow greater access to the storage bin. second row seats, is available for storage. Second Row Floor Storage Bins CAUTION! The storage bin cover must lay flat and be locked to avoid damage from contact with the front seat tracks, which have minimal clearance to the cover.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 293 WARNING! (Continued) WARNING! (Continued) • Do not operate the storage bin covers while the vehicle is in motion. • Do not use a storage bin latch as a tie down. • In a collision, serious injury could result if the seat storage bin covers are not properly latched. • Do not drive the vehicle with the storage bin covers open. Keep the storage bin covers closed and latched while the vehicle is in motion.
294 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: In the event of an individual being locked inside As a security measure, the Seat Storage Bin Cover has an the storage bin, the storage bin cover can be opened from Emergency Release Lever built into the latching mecha- inside of the bin by pushing on the glow-in-the-dark lever attached to the storage bin cover latching mechanism. nism.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 295 Coat Hooks Coat hooks are located along the headliner for the second and third row seating positions. The coat hook load limit is 10 lbs (4.5 kg). Exceeding the recommended load limit can cause the coat hooks to break or disengage from the vehicle. Cargo Area Storage Overhead Console Features 1 — LCD Screen* 2 — Rear HVAC 3 — Courtesy Lights 4 — Storage * If equipped, otherwise storage.
296 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONSOLE FEATURES There are three consoles available: Basic, Premium and Super. WARNING! Do not operate this vehicle with a console compartment lid in the open position. Driving with the console compartment lid open may result in injury in a collision.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 297 • The cupholders are removable to access a large storage 3. Align the console until the front anchor cup plug hole is centered on the winch hole. bin. • The basic console is removable from the vehicle for 4. Reinstall the clip first and then while pushing downward on the console with slight pressure, reinstall the additional floor space by removing the cap and clip at cover plug. the console base. To Remove The Basic Floor Console 1.
298 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Large console center storage will store headphones for the available rear DVD entertainment system or other The three-compartment console with sliding storage bin, items sliding upper tray with storage and large console storage bin offers multiple configurations. • 12 Volt DC power outlet provides continuous power inside the console for cell phones or other electronics • Four cupholders with dishwasher safe liners for cleanPremium Console — If Equipped ing.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 299 Position 1 shows the console closed with four cupholders Position 2 shows the raised storage tray revealing a large and a convenient storage tray. storage area below.
300 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Position 4 shows the complete console in its rearmost Position 3 shows the top portion of the console in a position. Again, lifting second latch handle at the front of rearward position. This is accomplished by lifting the the console, allows complete access to a lower storage bin and provides additional cupholders for rear passengers. upper most latch at the front of the console.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 301 To Remove The Premium Floor Console 1. Pull up on the bottom release handle in the front of the console. 2. Lift the rear of the console up several inches/ centimeters. 3. Pull rearward to disengage from floor and remove console. To Reinstall The Premium Floor Console: 5. Pull up on the console to be sure it is firmly latched. WARNING! In an accident, serious injury could result if the removable floor console is not properly installed.
302 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Lower Pass Through Super Console The Super Console tambour doors are opened by push- 1 — Front Sliding Tambour Door ing down on the finger tabs and sliding the door. The 2 — Cupholder Light Ring front tambour door slides forward, the rear tambour door 3 — Rear Sliding Tambour Door slides rearward.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 303 NOTE: The front cupholder light ring and pass through REAR WINDOW FEATURES lighting is controlled by a dimming switch located on the Rear Window Defroster instrument panel, refer to “Lights” in “Understanding The Features Of Your Vehicle” for further information. The rear window defroster button is located on Located in the back of the Super Console is a storage the climate control (Mode) knob. Push this button drawer and cupholders for the rear passengers.
304 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Failure to follow these cautions can cause damage to the heating elements: • Use care when washing the inside of the rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements. Labels can be peeled off after soaking with warm water.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 305 NOTE: • Crossbars are error-proofed and cannot be deployed or stowed in the incorrect positions. • To help control wind noise, stow the crossbars in the side rails when they are not in use. Deploying The Crossbars To deploy the crossbars, completely loosen the thumb screws at both ends of the crossbar and lift the crossbar from its stowed position in the side rail. Repeat with crossbar on the opposite side.
306 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Bend the crossbar supports at each end, taking care to keep hand clear of pivoting joint. Slide the thumb screw down. Loosening Crossbars CAUTION! Use care when removing and handling the crossbars to prevent damage to the vehicle.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 307 Then, position the crossbars across the roof. NOTE: The crossbars are identical and can be placed in any two of the three deploy positions.
308 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Make sure the directional arrows on the crossbars align with the directional arrows on the side rails. Set the crossbars into the deployed positions. Tightening Crossbar Stowing The Crossbars Reverse the procedure to stow the crossbars, again, taking care to keep hand clear of pivoting joint. Crossbars Once the crossbars are set into position, tighten the are identical and can be stowed in either rail nest. Once thumb screws completely.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 309 NOTE: Load should always be secured to crossbars first, with rail tie down loops used as additional securing points if needed. Tie loops are intended as supplementary tie down points only. Do not use ratcheting mechanisms with the tie loops. CAUTION! • Check deployed crossbars frequently and retighten thumb screws as necessary. • To avoid damage to the roof rack and vehicle, do not exceed the maximum roof rack load capacity of 150 lb (68 kg).
310 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) • Long loads which extend over the windshield, such as wood panels or surfboards, or loads with large frontal area should be secured to both the front and rear of the vehicle. • Travel at reduced speeds and turn corners carefully when carrying large or heavy loads on the roof rack. Wind forces, due to natural causes or nearby truck traffic, can add sudden upward lift to a load.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 311 3 Sun Screen Retracted Sun Screen Extended Gently pull up on the tab to raise the sun screen. To lower the sun screen, gently lift the tab upward to Continue pulling the sun screen until the tab is near the disengage the hooks, and feed the screen back into the top of the window. base sill. Once the screen is completely to the top of the window, extend the top bar of the sun screen over the two hooks attached to the top of the window.
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS 䡵 INSTRUMENT PANEL FEATURES . . . . . . . . . .318 䡵 ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) — IF EQUIPPED . . . . . . . . . . . . . . . . . .353 䡵 INSTRUMENT CLUSTER — BASE . . . . . . . . . .319 ▫ Electronic Vehicle Information Center (EVIC) 䡵 INSTRUMENT CLUSTER — PREMIUM . . . . . . .325 Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . .355 䡵 WARNING AND INDICATOR LIGHTS . . . . . . .330 ▫ Oil Change Required . . . . . . . . . . . . . . . .
314 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Vehicle Info (Customer Information Features) . .362 ▫ Operating Instructions — Radio Mode . . . . . .374 ▫ Messages # . . . . . . . . . . . . . . . . . . . . . . . . . .363 ▫ Operation Instructions — CD MODE For CD And MP3 Audio Play . . . . . . . . . . . . . . . . . . . . . .377 ▫ Keyless Enter-N-Go Display — If Equipped . . .363 ▫ Compass / Temperature Display . . . . . . . . . .363 ▫ Turn Menu Off . . . . . . . . . . . . . . . . . . . . . . .
UNDERSTANDING YOUR INSTRUMENT PANEL 315 ▫ Operating Instructions (Uconnect Phone) — If Equipped . . . . . . . . . . . . . . . . . . . . . . . . . . .399 䡵 SETTING THE ANALOG CLOCK . . . . . . . . . . .399 䡵 iPod/USB/MP3 CONTROL — IF EQUIPPED . . .400 ▫ Getting Started . . . . . . . . . . . . . . . . . . . . . . .407 ▫ Blu-ray Disc Player . . . . . . . . . . . . . . . . . . . .408 ▫ Play Video Games . . . . . . . . . . . . . . . . . . . . .409 ▫ Connecting The iPod Or External USB Device . .
316 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ VES Remote Control — If Equipped . . . . . . . .424 ▫ Information Mode Display . . . . . . . . . . . . . . .436 ▫ Blu-ray Player Remote Control — If Equipped .427 ▫ Numeric Keypad Menu . . . . . . . . . . . . . . . . .437 ▫ Remote Control Storage . . . . . . . . . . . . . . . . .429 ▫ Station List Menu . . . . . . . . . . . . . . . . . . . . .438 ▫ Locking The Remote Control . . . . . . . . . . . . .430 ▫ Disc Menu . . . . . . . . . . . . . . . . . . . . . .
UNDERSTANDING YOUR INSTRUMENT PANEL 317 䡵 CD/DVD/Blu-ray Disc MAINTENANCE . . . . .455 䡵 RADIO OPERATION AND MOBILE PHONES . .456 ▫ General Information . . . . . . . . . . . . . . . . . . .456 䡵 CLIMATE CONTROLS . . . . . . . . . . . . . . . . . . .456 ▫ Manual Heating And Air Conditioning System — If Equipped . . . . . . . . . . . . . . . . . . . . . . . . .456 ▫ Rear Manual Climate Control — If Equipped . .462 ▫ Automatic Temperature Control (ATC) — If Equipped . . . . . . . . . . . . . . . . . . . . .
318 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Vents 2 — Instrument Cluster 3 — Shift Lever 4 — Radio 5 — Analog Clock 6 — Upper Glove Compartment 7 — Lower Glove Compartment 8 — Climate Controls 9 — DVD – If Equipped 10 — Storage Bin 11 — Cup Holders 13 — Ignition Switch 14 — Hood Release 15 — Dimmer Switch 12 — Switch Bank 16 — Headlight Switch
UNDERSTANDING YOUR INSTRUMENT PANEL 319 INSTRUMENT CLUSTER — BASE 4
320 UNDERSTANDING YOUR INSTRUMENT PANEL 1. Tachometer • This gauge measures engine revolutions per minute (RPM x 1000). Before the pointer reaches the red area, ease up on the accelerator to prevent engine damage. make a record of the odometer reading before the repair/ service, so that you can be sure that it is properly reset, or that the door jamb sticker is accurate if the odometer must be reset at zero. 2.
UNDERSTANDING YOUR INSTRUMENT PANEL 321 gASCAP gASCAP . . . . . . . . . . . . . . . . . . . . . . Fuel Cap Fault If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a noFUSE . . . . . . . . . . . . . . . . . . . . . . . . . . Fuse Fault “gASCAP” message will display in the odometer display area. Tighten the fuel filler cap properly and push the CHAngE OIL . . . . . . . . . . . . . .
322 UNDERSTANDING YOUR INSTRUMENT PANEL CHAngE OIL 3. Turn the ignition switch to the OFF position. Your vehicle is equipped with an engine oil change indicator system. The odometer display will toggle between CHAngE and Oil for approximately 12 seconds, after a single chime has sounded, to indicate the next scheduled oil change interval. The engine oil change indicator system is duty cycle-based, which means the engine oil change interval may fluctuate dependent upon your personal driving style.
UNDERSTANDING YOUR INSTRUMENT PANEL 323 The fuel pump symbol points to the side of the vehicle where the fuel door is located. 5. Temperature Gauge • The temperature gauge shows engine coolant temperature. Any reading within the normal range indicates that the engine cooling system is operating satisfactorily. • The gauge pointer will likely indicate a higher temperature when driving in hot weather or up mountain grades. It should not be allowed to exceed the upper limits of the normal operating range.
324 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER — PREMIUM
UNDERSTANDING YOUR INSTRUMENT PANEL 325 1. Tachometer • This gauge measures engine revolutions per minute (RPM x 1000). Before the pointer reaches the red area, ease up on the accelerator to prevent engine damage. 2. Electronic Vehicle Information Center (EVIC) — If Equipped / Odometer Display / Trip Odometer Display Electronic Vehicle Information Center (EVIC) — If Equipped U.S.
326 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Some of the above warnings will be displayed in the Electronic Vehicle Information Center Display Area When the appropriate conditions exist, the following located in the instrument cluster. odometer messages will display: Refer to ”Electronic Vehicle Information Center (EVIC) — door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Door Ajar If Equipped” in this section for further information. Message Display Area gATE . . . . . . . . . . . . . . . .
UNDERSTANDING YOUR INSTRUMENT PANEL 327 position. To reset the oil change indicator system (after performing the scheduled maintenance), perform the If the vehicle diagnostic system determines that the following steps. Ignition Off Draw (IOD) fuse is improperly installed, or damaged, a “noFUSE” message will display in the odom- 1. Turn the ignition switch to the ON/RUN position (do eter display area. Refer to “Fuses” in “Maintaining Your not start the engine).
328 UNDERSTANDING YOUR INSTRUMENT PANEL The fuel pump symbol points to the side of the vehicle where the fuel door is located. 5. Temperature Gauge • The temperature gauge shows engine coolant temperature. Any reading within the normal range indicates that the engine cooling system is operating satisfactorily. • The gauge pointer will likely indicate a higher temperature when driving in hot weather or up mountain grades. It should not be allowed to exceed the upper limits of the normal operating range.
UNDERSTANDING YOUR INSTRUMENT PANEL 329 WARNING AND INDICATOR LIGHTS IMPORTANT: The warning light switches on in the instrument panel together with a dedicated message and/or acoustic signal when applicable. These indications are indicative and precautionary and as such must Red Telltale Indicator Lights not be considered as exhaustive and/or alternative to the information contained in the Owner Manual, which you are advised to read carefully in all cases.
330 UNDERSTANDING YOUR INSTRUMENT PANEL Seat Belt Reminder Warning Light Red Telltale Light What It Means Seat Belt Reminder Warning Light When the ignition switch is first turned to ON/RUN, this light will turn on for four to eight seconds as a bulb check. During the bulb check, if the driver’s seat belt is unbuckled, a chime will sound. After the bulb check or when driving, if the driver seat belt remains unbuckled, the Seat Belt Reminder Light will flash or remain on continuously.
UNDERSTANDING YOUR INSTRUMENT PANEL 331 Brake Warning Light Red Telltale Light What It Means Brake Warning Light This light monitors various brake functions, including brake fluid level and parking brake application. If the brake light turns on it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the anti-lock brake system reservoir.
332 UNDERSTANDING YOUR INSTRUMENT PANEL Red Telltale Light What It Means the Brake Warning Light, which will turn on when the brake fluid level in the master cylinder has dropped below a specified level. The light will remain on until the cause is corrected. NOTE: The light may flash momentarily during sharp cornering maneuvers, which change fluid level conditions. The vehicle should have service performed, and the brake fluid level checked. If brake failure is indicated, immediate repair is necessary.
UNDERSTANDING YOUR INSTRUMENT PANEL 333 WARNING! Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have a collision. Have the vehicle checked immediately. ON/RUN position. The light should illuminate for approximately two seconds. The light should then turn off unless the parking brake is applied or a brake fault is detected.
334 UNDERSTANDING YOUR INSTRUMENT PANEL Charging System Warning Light Red Telltale Light What It Means Charging System Warning Light This light shows the status of the electrical charging system. The light should come on when the ignition switch is first turned to ON/RUN and remain on briefly as a bulb check. If the light stays on or comes on while driving, turn off some of the vehicle’s nonessential electrical devices or increase engine speed (if at idle).
UNDERSTANDING YOUR INSTRUMENT PANEL 335 Coolant Temperature Warning Light Red Telltale Light What It Means Coolant Temperature Warning Light This light warns of an overheated engine condition. If the light turns on while driving, safely pull over and stop the vehicle. If the A/C system is on, turn it off. Also, shift the transmission into NEUTRAL and idle the vehicle. If the temperature reading does not return to normal, turn the engine off immediately and call for service.
336 UNDERSTANDING YOUR INSTRUMENT PANEL Electronic Throttle Control (ETC) Warning Light Red Telltale Light What It Means Electronic Throttle Control (ETC) Warning Light This light informs you of a problem with the Electronic Throttle Control (ETC) system. If a problem is detected while the engine is running, the light will either stay on or flash depending on the nature of the problem.
UNDERSTANDING YOUR INSTRUMENT PANEL 337 Engine Temperature Warning Light Red Warning Light What It Means Engine Temperature Warning Light This light warns of an overheated engine condition. As engine coolant temperatures rise and the gauge approaches H, this indicator will illuminate and a single chime will sound after reaching a set threshold.
338 UNDERSTANDING YOUR INSTRUMENT PANEL Oil Pressure Warning Light Red Telltale Light What It Means Oil Pressure Warning Light This light indicates low engine oil pressure. The light should turn on momentarily when the engine is started; if the bulb does not come on, have the system checked by an authorized dealer. If the light turns on while driving, stop the vehicle and shut off the engine as soon as possible. A chime will sound when this light turns on.
UNDERSTANDING YOUR INSTRUMENT PANEL 339 Vehicle Security Warning Light — If Equipped Red Telltale Light What It Means Vehicle Security Warning Light This light will flash at a fast rate for approximately 15 seconds when the vehicle security alarm is arming, and then will flash slowly until the vehicle is disarmed. Transmission Temperature Warning Light Red Telltale Light What It Means Transmission Temperature Warning Light This light indicates that the transmission fluid temperature is running hot.
340 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! WARNING! Continuous driving with the Transmission Temperature Warning Light illuminated will eventually cause severe transmission damage or transmission failure. If you continue operating the vehicle when the Transmission Temperature Warning Light is illuminated you could cause the fluid to boil over, come in contact with hot engine or exhaust components and cause a fire.
UNDERSTANDING YOUR INSTRUMENT PANEL 341 Door Open Warning Light — If Equipped Red Telltale Light What It Means Door Open Warning Light This indicator will illuminate when a door is ajar/open and not fully closed.
342 UNDERSTANDING YOUR INSTRUMENT PANEL Yellow Telltale Light What It Means detected in the ESC system. If this light remains on after several ignition cycles, and the vehicle has been driven several miles (kilometers) at speeds greater than 30 mph (48 km/h), see your authorized dealer as soon as possible to have the problem diagnosed and corrected. • The “ESC Off Indicator Light” and the “ESC Indicator Light” come on momentarily each time the ignition switch is turned to ON/RUN.
UNDERSTANDING YOUR INSTRUMENT PANEL 343 Electronic Stability Control (ESC) OFF Indicator Light — If Equipped Yellow Telltale Light What It Means Electronic Stability Control (ESC) OFF Indicator Light This light indicates the Electronic Stability Control (ESC) is off. Loose Fuel Filler Cap Indicator Light Yellow Telltale Light What It Means Loose Fuel Filler Cap Indicator Light This light will illuminate when fuel filler cap is loose. Properly close the filler cap to disengage the light.
344 UNDERSTANDING YOUR INSTRUMENT PANEL Low Fuel Indicator Light Yellow Telltale Light What It Means Low Fuel Indicator Light When the fuel level reaches approximately 3.0 gal (11.0 L) this light will turn on, and remain on until fuel is added. Low Washer Fluid Indicator Light — If Equipped Yellow Telltale Light What It Means Low Washer Fluid Indicator Light This indicator will illuminate when the windshield washer fluid is low.
UNDERSTANDING YOUR INSTRUMENT PANEL 345 Engine Check/Malfunction Indicator Light (MIL) Yellow Telltale Light What It Means Engine Check/Malfunction Indicator Light (MIL) The Engine Check/Malfunction Indicator Light (MIL) is a part of an Onboard Diagnostic System called OBD II that monitors engine and automatic transmission control systems. The light will illuminate when the ignition is in the ON position before engine start.
346 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! WARNING! Prolonged driving with the Malfunction Indicator Light (MIL) on could cause damage to the engine control system. It also could affect fuel economy and driveability. If the MIL is flashing, severe catalytic converter damage and power loss will soon occur. Immediate service is required. A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal operating conditions.
UNDERSTANDING YOUR INSTRUMENT PANEL 347 Yellow Telltale Light What It Means system will continue to operate normally if the BRAKE warning light is not on. If the ABS light is on, the brake system should be serviced as soon as possible to restore the benefits of Anti-Lock Brakes. If the ABS light does not turn on when the ignition switch is placed in the ON/RUN position, have the light inspected by an authorized dealer.
348 UNDERSTANDING YOUR INSTRUMENT PANEL Yellow Telltale Light What It Means the dedicated tire repair kit and contact your authorized dealership as soon as possible. Tire Pressure Low The warning light switches on and a message is displayed to indicate that the tire pressure is lower than the recommended value and/or that slow pressure loss is occurring. In these cases, optimal tire duration and fuel consumption may not be guaranteed.
UNDERSTANDING YOUR INSTRUMENT PANEL 349 As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System (TPMS) that illuminates a low tire pressure telltale when one or more of your tires is significantly under-inflated. Accordingly, when the low tire pressure telltale illuminates, you should stop and check your tires as soon as possible and inflate them to the proper pressure.
350 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when using replacement equipment that is not of the same size, type, and/or style. Aftermarket wheels can cause sensor damage.
UNDERSTANDING YOUR INSTRUMENT PANEL 351 Green Telltale Indicator Lights Turn Signal Indicator Lights Green Telltale Light What It Means Turn Signal Indicator Lights The instrument cluster arrow will flash independently for the LEFT or RIGHT turn signal as selected, as well as the exterior turn signal lamp(s) (front and rear) as selected when the multifunction lever is moved down (LEFT) or up (RIGHT). NOTE: • A continuous chime will sound if the vehicle is driven more than 1 mile (1.
352 UNDERSTANDING YOUR INSTRUMENT PANEL Park/Headlight ON Indicator Light Green Telltale Light What It Means Park/Headlight ON Indicator Light This indicator will illuminate when the park lights or headlights are turned on. Front Fog Indicator Light — If Equipped Green Telltale Light What It Means Front Fog Indicator Light This indicator will illuminate when the front fog lights are on.
UNDERSTANDING YOUR INSTRUMENT PANEL 353 Blue Telltale Indicator Light High Beam Indicator Light Blue Telltale Light What It Means High Beam Indicator Light This indicator shows that the high beam headlights are on. Push the multifunction control lever away from you to switch the headlights to high beam. Pull the lever toward you to switch the headlights back to low beam.
354 UNDERSTANDING YOUR INSTRUMENT PANEL White Telltale Indicator Light Electronic Speed Control SET Light White Telltale Light What It Means Electronic Speed Control SET Light This light will turn on when the electronic speed control is set. Refer to “Electronic Speed Control” in “Understanding The Features Of Your Vehicle” for further information.
UNDERSTANDING YOUR INSTRUMENT PANEL 355 ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) — IF EQUIPPED The EVIC Menu items consists of the following: • Fuel Economy The Electronic Vehicle Information Center (EVIC) features a driver-interactive display that is located in the • Vehicle Speed instrument cluster.
356 UNDERSTANDING YOUR INSTRUMENT PANEL The system allows the driver to select information by • UP Button pushing the following buttons mounted on the steering Push and release the UP button to scroll upwheel: ward through the main menu items (Fuel Economy, Vehicle Info, Tire PSI, Cruise, Messages, Units, System Setup). • DOWN Button Push and release the DOWN button to scroll downward through the main menu items.
UNDERSTANDING YOUR INSTRUMENT PANEL 357 Once the RIGHT button has been selected for the desired The main display area will normally display the main submenu list, follow the EVIC prompts to properly select menu or the screens of a selected feature of the main menu. The main display area also displays ⬙pop up⬙ the desired submenu EVIC features. messages that consist of approximately 60 possible warn• BACK Button ing or information messages.
358 UNDERSTANDING YOUR INSTRUMENT PANEL • Unstored Messages seconds and then returns to the previous screen. Examples of this message type are ⬙Memory System UnThis message type is displayed indefinitely or until the available - Not in Park⬙ and ⬙Automatic High Beams On.⬙ condition that activated the message is cleared. Examples of this message type are ⬙Turn Signal On⬙ (if a turn signal is left on) and ⬙Lights On⬙ (if driver leaves the vehicle).
UNDERSTANDING YOUR INSTRUMENT PANEL 359 • Remote start disabled — Start Vehicle to Reset • Remote start active — Push Start Button • Remote start active — Key to Run • Wrong Key • Damaged Key • Key not programmed • Vehicle Not in Park • Key Left Vehicle • Key Not Detected • Press Brake Pedal and Push Button to Start • Service TPM System (refer to “Tire Pressure Monitoring System” in “Starting And Operating”) • Tire Pressure Screen With Low Tire(s) “Inflate Tire to XX” • Turn Signal On • RKE Battery Low •
360 UNDERSTANDING YOUR INSTRUMENT PANEL • Park Assist Disabled • Service Park Assist System • Personal Settings Not Available — Vehicle Not in Park system is permanently unavailable. The driver will receive an EVIC message and the BSM display warning in both mirrors will be permanently illuminated. If this message is present, see an authorized dealer.
UNDERSTANDING YOUR INSTRUMENT PANEL 361 message temporarily, push and release the MENU but- 2. Fully depress the accelerator pedal, slowly, three times ton. To reset the oil change indicator system (after within 10 seconds. performing the scheduled maintenance) refer to the fol3. Turn the ignition switch to the OFF/LOCK position. lowing procedure. NOTE: If the indicator message illuminates when you Vehicles Equipped With Keyless Enter-N-Go start the engine, the oil change indicator system did not 1.
362 UNDERSTANDING YOUR INSTRUMENT PANEL Average Fuel Economy Shows the average fuel economy since the last reset. The Average Fuel Economy can be reset by following the prompt in the EVIC to use the RIGHT button. When the fuel economy is reset, the display will read “zero” for two seconds. Then, the history information will be erased, and the averaging will continue from the last fuel average reading before the reset.
UNDERSTANDING YOUR INSTRUMENT PANEL 363 NOTE: Significant changes in driving style or vehicle RIGHT arrow button. Push and release the RIGHT arrow loading will greatly affect the actual drivable distance of button to display the current speed in mph or km/h. Pushing the RIGHT arrow button a second time will the vehicle, regardless of the DTE displayed value. toggle the unit of measure between mph or km/h.
364 UNDERSTANDING YOUR INSTRUMENT PANEL • Shows the elapsed time traveled for Trip A since the Tire Pressure last reset. Push and release the UP or DOWN button until “Tire PSI:” displays highlighted in the EVIC. Push and release Trip B the RIGHT button to view a graphic of the vehicle with a • Shows the total distance traveled for Trip B since the tire pressure value at each corner of the graphic. last reset.
UNDERSTANDING YOUR INSTRUMENT PANEL 365 Vehicle Info (Customer Information Features) Messages # Push and release the UP or DOWN button until “Vehicle Info” displays in the EVIC. Then, push and release the RIGHT button. Push and release the UP and DOWN button to scroll through the available information displays, then push and release RIGHT to display any one of the following choices. Select from Main Menu using the UP or DOWN buttons.
366 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: A good calibration requires a level surface and an environment free from large metallic objects such as The compass readings indicate the direction the vehicle is buildings, bridges, underground cables, railroad tracks, facing. The EVIC will display eight or fifteen compass etc. readings and the outside temperature.
UNDERSTANDING YOUR INSTRUMENT PANEL 367 4. Push and release the RIGHT button to start the NOTE: Keep magnetic materials away from the top of calibration. The “CAL” indicator will be displayed in the instrument panel, such as iPod’s, Mobile Phones, Laptops and Radar Detectors. This is where the compass the EVIC. module is located, and it can cause interference with the 5. Complete one or more 360–degree turns (in an area compass sensor, and it may give false readings.
368 UNDERSTANDING YOUR INSTRUMENT PANEL 1. Turn the ignition switch ON. Customer-Programmable Features (System Setup) 2. Push and release the UP or DOWN button until the Setup (Customer-Programmable Features) menu is Personal Settings allows you to set and recall features when the transmission is in PARK. If the transmission is reached, then push the RIGHT button. out of PARK or the vehicle begins moving, a warning 3.
UNDERSTANDING YOUR INSTRUMENT PANEL 369 (18 km/h). The system can be enabled with Sound Only, Sound and Display, or turned OFF through the EVIC. To make your selection, push and release the RIGHT arrow button until a check-mark appears next to the feature showing the system has been activated or the check-mark Nav–Turn By Turn is removed showing the system has been deactivated.
370 UNDERSTANDING YOUR INSTRUMENT PANEL opened. To make your selection, push and release the Right arrow button until a check-mark appears next to the feature showing the system has been activated, or the check-mark is removed showing the system has been deactivated. Remote Unlock Sequence When Unlock Driver Door Only On 1st Press is selected, only the driver’s door will unlock on the first push of the Remote Keyless Entry (RKE) transmitter UNLOCK button.
UNDERSTANDING YOUR INSTRUMENT PANEL 371 RIGHT arrow button until a check-mark appears next to showing the system has been activated or the check-mark the feature showing the system has been activated or the is removed showing the system has been deactivated. check-mark is removed showing the system has been Automatic High Beams — If Equipped deactivated. When this feature is selected, the high beam headlights Horn With Remote Lock will deactivate automatically under certain conditions.
372 UNDERSTANDING YOUR INSTRUMENT PANEL the RIGHT button until a check-mark appears next to the feature showing the system has been activated or the check-mark is removed showing the system has been When ON is selected, and the headlight switch is in the deactivated. When the system is deactivated, the system AUTO position, the headlights will turn on approxireverts to the standard intermittent wiper operation. mately 10 seconds after the wipers are turned on.
UNDERSTANDING YOUR INSTRUMENT PANEL 373 Illuminated Approach signaling other drivers that someone may be exiting or entering the vehicle. To make your selection, push and release the RIGHT button until a check-mark appears next to the feature showing the system has been activated or the check-mark is removed, showing the system has been deactivated. When this feature is selected, the headlights will activate and remain on for up to 90 seconds when the doors are unlocked with the RKE transmitter.
374 UNDERSTANDING YOUR INSTRUMENT PANEL vehicle. To make your selection, push and release the RIGHT button until a check-mark appears next to the feature showing the system has been activated or the check-mark is removed showing the system has been deactivated. NOTE: The seat will return to the memorized seat location (if Recall Memory with Remote Key Unlock is set to ON) when the RKE transmitter is used to unlock the door.
UNDERSTANDING YOUR INSTRUMENT PANEL 375 To make your selection, push and release the RIGHT button until a check-mark appears next to the feature, showing the system has been activated, or the checkmark is removed, showing the system has been deactivated. NOTE: If your vehicle has experienced any damage in the area where the sensor is located, even if the fascia is not damaged, the sensor may have become misaligned. Take your vehicle to an authorized dealer to verify sensor alignment.
376 UNDERSTANDING YOUR INSTRUMENT PANEL Power Switch/Volume Control (Rotary) UCONNECT 130 Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction, without stopping. Turning the ON/VOLUME control knob to the right increases the volume, and to the left decreases it.
UNDERSTANDING YOUR INSTRUMENT PANEL 377 another selection. Holding either button will bypass 5. To exit, push any button/knob, or wait five seconds. stations without stopping, until you release it. RW/FF TIME Button Pushing the RW (Rewind) or FF (Fast Forward) buttons Push the TIME button to alternate display of the time and causes the tuner to search for the next frequency in the radio frequency. direction of the arrows. This feature operates in either AM or FM frequencies.
378 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a second Push the rotary TUNE/SCROLL control knob again to time and MID will display. Turn the TUNE/SCROLL exit setting tone, balance, and fade. control knob to the right or left to increase or decrease the AM/FM Button mid-range tones. Push the buttons to select either AM or FM mode. Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display.
UNDERSTANDING YOUR INSTRUMENT PANEL 379 display window. Each button can be set for SET 1 and SET 2 in both AM and FM. This allows a total of 12 AM and 12 FM stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by pushing the pushbutton twice. Operation Instructions — CD MODE For CD And MP3 Audio Play NOTE: • The ignition switch must be in the ON or ACC position to operate the radio.
380 UNDERSTANDING YOUR INSTRUMENT PANEL If you insert a disc with the ignition ON and the radio EJECT Button — Ejecting A CD ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will Push the EJECT button to eject the CD. show the track number, and index time in minutes and seconds. Play will begin at the start of track 1. CAUTION! • This CD player will accept 4–3/4 inch (12 cm) discs only. The use of other sized discs may damage the CD player mechanism.
UNDERSTANDING YOUR INSTRUMENT PANEL 381 the current selection. Pushing and holding the SEEK SET/RND Button (Random Play Button) button will allow faster scrolling through the tracks in Push this button while the CD is playing to activate CD and MP3 modes. Random Play. This feature plays the selections on the compact disc in random order to provide an interesting TIME Button change of pace. Push this button to change the display from a large CD playing time display to a small CD playing time display.
382 UNDERSTANDING YOUR INSTRUMENT PANEL Supported Medium Formats (File Systems) exceeding 20 folders will result in this display. With 200 files, exceeding 50 folders will result in this display.) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than Maximum number of characters in file/folder names: ISO 9660 Level 1 and Level 2, the radio may fail to read • Level 1: 12 (including a separator ⬙.
UNDERSTANDING YOUR INSTRUMENT PANEL 383 Supported MP3 File Formats The radio will recognize only files with the *.MP3 extension as MP3 files. Non-MP3 files named with the *.MP3 extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will not play the file. MPEG Specification MPEG-1 Audio Layer 3 Sampling Frequency (kHz) 48, 44.
384 UNDERSTANDING YOUR INSTRUMENT PANEL Playback Of MP3 Files Operation Instructions — Auxiliary Mode When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files.
UNDERSTANDING YOUR INSTRUMENT PANEL 385 UCONNECT 130 WITH SATELLITE RADIO Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction, without stopping. Turning the ON/VOLUME control knob to the right increases the volume, and to the left decreases it.
386 UNDERSTANDING YOUR INSTRUMENT PANEL another selection. Holding either button will bypass Phone Button Uconnect Phone — If Equipped stations without stopping, until you release it. Push this button to operate the Uconnect Phone feature (if equipped). Refer to “Uconnect Phone” for further Voice Command System (Radio) — If Equipped details. Refer to “Voice Command” in “Understanding The Features Of Your Vehicle.
UNDERSTANDING YOUR INSTRUMENT PANEL 387 3. After adjusting the hours, push the right side TUNE/ INFO Button SCROLL control knob to set the minutes. The minutes Push the INFO button for an RDS station (one with call will begin to blink. letters displayed). The radio will return a Radio Text 4. Adjust the minutes using the right side TUNE/ message broadcast from an FM station (FM mode only). SCROLL control knob. Push the TUNE/SCROLL con- RW/FF trol knob to save time change.
388 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a second Push the rotary TUNE/SCROLL control knob again to time and MID will display. Turn the TUNE/SCROLL exit setting tone, balance, and fade. control knob to the right or left to increase or decrease the MUSIC TYPE Button mid-range tones. Pushing this button once will turn on the Music Type Push the rotary TUNE/SCROLL control knob a third mode for five seconds. Pushing the MUSIC TYPE button time and TREBLE will display.
UNDERSTANDING YOUR INSTRUMENT PANEL 389 Program Type Classical Classic Rock College Country Foreign Language Information Jazz News Nostalgia Oldies Personality Public Rhythm and Blues Religious Music 16-Digit Character Display Classicl Cls Rock College Country Language Inform Jazz News Nostalga Oldies Persnlty Public R&B Rel Musc Program Type Religious Talk Rock Soft Soft Rock Soft Rhythm and Blues Sports Talk Top 40 Weather 16-Digit Character Display Rel Talk Rock Soft Soft Rck Soft R&B Sports Talk Top
390 UNDERSTANDING YOUR INSTRUMENT PANEL If a preset button is activated while in the Music Type SET/RND Button — To Set The Pushbutton (Program Type) mode, the Music Type mode will be Memory exited and the radio will tune to the preset station. When you are receiving a station that you wish to commit to pushbutton memory, push the SET/RND SETUP Button button. The symbol SET 1 will now show in the display Pushing the SETUP button allows you to select between window.
UNDERSTANDING YOUR INSTRUMENT PANEL 391 Every time a preset button is used, a corresponding button number will display. Buttons 1 - 6 discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks. Inserting Compact Disc(s) These buttons tune the radio to the stations that you Gently insert one CD into the CD player with the CD commit to pushbutton memory (12 AM and 12 FM label facing up. The CD will automatically be pulled into stations).
392 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! • This CD player will accept 4–3/4 inch (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. • Do not use adhesive labels. These labels can peel away and jam the player mechanism. • The Uconnect 130 is a single CD player. Do not attempt to insert a second CD if one is already loaded. • Dual-media disc types (one side is a DVD, the other side is a CD) should not be used, and they can cause damage to the player.
UNDERSTANDING YOUR INSTRUMENT PANEL 393 RW/FF Notes On Playing MP3 Files Push and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or another CD button is pushed. The RW (Reverse) button works in a similar manner. The radio can play MP3 files; however, acceptable MP3 file recording media and formats are limited. When writing MP3 files, pay attention to the following restrictions.
394 UNDERSTANDING YOUR INSTRUMENT PANEL Multi-session disc formats are supported by the radio. Multi-session discs may contain combinations of normal • Maximum number of folder levels: 8 CD audio tracks and computer files (including MP3 files). Discs created with an option such as ⬙keep disc open after • Maximum number of files: 255 writing⬙ are most likely multi-session discs. The use of • Maximum number of folders.
UNDERSTANDING YOUR INSTRUMENT PANEL 395 use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rates. MPEG Specification MPEG-1 Audio Layer 3 Sampling Frequency (kHz) 48, 44.1, 32 MPEG-2 Audio Layer 3 24, 22.05, 16 Bit Rate (kbps) 320, 256, 224, 192, 160, 128, 112, 96, 80, 64, 56, 48, 40, 32 160, 128, 144, 112, 96, 80, 64, 56, 48, 40, 32, 24, 16, 8 Playback Of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium.
396 UNDERSTANDING YOUR INSTRUMENT PANEL LIST Button — CD Mode For MP3 Play Pushing the LIST button will bring up a list of all folders on the disc. Scrolling up or down the list is done by turning the TUNE/SCROLL control knob. Selecting a folder by pushing the TUNE/SCROLL control knob will begin playing the files contained in that folder (or the next folder in sequence if the selection does not contain playable files). The folder list will time out after five seconds.
UNDERSTANDING YOUR INSTRUMENT PANEL 397 radio system in your vehicle. Sirius will supply a welcome kit that contains general information, including Push this button to change the display to time of day. The how to setup your on-line listening account. For further time of day will display for five seconds (when the information, call the toll-free number 888-539-7474, or ignition is OFF). visit the Sirius web site at www.siriusxm.com, or at Uconnect (Satellite Radio) — If Equipped www.siriusxm.
398 UNDERSTANDING YOUR INSTRUMENT PANEL decreased performance. Larger luggage items such as bikes should be placed as far rearward as possible, within ESN/SID Access the loading design of the rack. Do not place items directly With the ignition switch in the ON/RUN or ACC posi- on or above the antenna. tion and the radio on, push the SETUP button and scroll Reception Quality using the TUNE/SCROLL control knob until Sirius ID is selected.
UNDERSTANDING YOUR INSTRUMENT PANEL 399 Operating Instructions — Uconnect (Satellite) Mode INFO Button Pushing the INFO button will cycle the display informaNOTE: The ignition switch must be in the ON/RUN or tion between Artist, Song Title, and Composer (if available). Also, pushing and holding the INFO button for an ACC position to operate the radio.
400 UNDERSTANDING YOUR INSTRUMENT PANEL MUSIC TYPE Button SETUP Button Pushing this button once will turn on the Music Type Pushing the SETUP button allows you to select the mode for five seconds. Pushing the MUSIC TYPE button following items: or turning the TUNE/SCROLL control knob within five • Display Sirius ID number — Push the AUDIO/ seconds will allow the program format type to be seSELECT button to display the Sirius ID number. This lected.
UNDERSTANDING YOUR INSTRUMENT PANEL 401 You may add a second channel to each pushbutton by repeating the above procedure with this exception: Push the SET button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2. This allows a total of 12 Satellite channels to be stored into pushbutton memory. The channels stored in SET 2 memory can be selected by pushing the pushbutton twice.
402 UNDERSTANDING YOUR INSTRUMENT PANEL iPod/USB/MP3 CONTROL — IF EQUIPPED NOTE: NOTE: This section is for Uconnect 130/230 radios only. • If the radio has a USB port, refer to the appropriate For Uconnect 430/430N, 730N, 731N, 735N or 431 touchUconnect Multimedia radio User’s Manual for iPod or external USB device support capability. screen radio iPod/USB/MP3 control feature, refer to the separate Supplement Manual.
UNDERSTANDING YOUR INSTRUMENT PANEL 403 NOTE: The glove compartment will have a position Use the connection cable to connect an iPod or external where the iPod or consumer electronic audio device cable USB device to the vehicle’s USB connector port which is can be routed through without damaging the cable when closing the lid. This allows routing of the cable without located in the glove compartment. damaging it while closing the lid.
404 UNDERSTANDING YOUR INSTRUMENT PANEL Using This Feature control mode, audio tracks (if available from audio device) start playing over the vehicle’s audio system. By using an external USB device to connect to the USB port: Play Mode • The audio device can be played on the vehicle’s sound When switched to iPod/USB/MP3 control mode, the system, providing metadata (artist, track title, album, iPod or external USB device automatically starts Play mode.
UNDERSTANDING YOUR INSTRUMENT PANEL 405 • Jump backward in the current track by pushing and holding the << RW button. Holding the << RW button long enough will jump to the beginning of the current track. • Jump forward in the current track by pushing and holding the FF >> button. the next screen of data for that track. Once all screens have been viewed, the last INFO button push will go back to the play mode screen on the radio.
406 UNDERSTANDING YOUR INSTRUMENT PANEL device, or push the VR button and say ⬙Shuffle ON⬙ or ⬙Shuffle Off.⬙ If the RND icon is showing on the radio display, then the shuffle mode is ON. through the list faster. During fast scroll, a slight delay in updating the information on the radio display may be noticeable. During all List modes, the iPod displays all lists in “wrap-around” mode.
UNDERSTANDING YOUR INSTRUMENT PANEL 407 Pushing a PRESET button will display the current list on the top line and the first item in that list on the second line. To exit List mode without selecting a track, push the same PRESET button again to go back to Play mode. LIST button: The LIST button will display the top level menu of the iPod or external USB device. • Turn the TUNE control knob to list the top-menu item to be selected and push the TUNE control knob.
408 UNDERSTANDING YOUR INSTRUMENT PANEL Bluetooth Streaming Audio (BTSA) Selecting A Different Audio Device Music can be streamed from your cellular phone to the 1. Uconnect phone system. 2. Refer to the Uconnect Radio Supplement for further information on Bluetooth connectivity. 3. Controlling BTSA Using Radio Buttons Push the Phone button to begin. After the ⬙Ready⬙ prompt and following the beep, say ⬙Setup⬙, then say ⬙Select Audio Devices.
UNDERSTANDING YOUR INSTRUMENT PANEL 409 Browse Browsing is not available on a Bluetooth Streaming Audio (BTSA) device. Only the current song that is playing will display info. Uconnect MULTIMEDIA — VIDEO ENTERTAINMENT SYSTEM (VES) — IF EQUIPPED Your rear seat Video Entertainment System (VES) is designed to give your family years of enjoyment. You can play your favorite CDs or DVDs, listen to audio over the wireless headphones, or plug and play a variety of standard video games or audio devices.
410 UNDERSTANDING YOUR INSTRUMENT PANEL • Turn on the Player (if equipped on Dual Screen Sys- Blu-ray Disc Player tem) by pushing the Power button, located on the far Play A Blu-ray Disc left, or by pushing the button on the Remote Control. To view a Blu-ray disc, insert the disc into the Blu-ray • When the Video Screen(s) are open and a DVD/Blu- VES disc Player. Playback will begin automatically after ray Disc is inserted into the VES player, the screen(s) the Blu-ray is recognized by the disc drive.
UNDERSTANDING YOUR INSTRUMENT PANEL 411 Using The Remote Control Play Video Games • Select an audio channel (Channel 1 for 2nd row screen Connect the video game console to the Auxiliary RCA and Channel 2 for 3rd row screen), then push the input jacks or HDMI port, located on the left side behind the second row seat. source key and select VES Disc from the menu. • Push popup/menu key to navigate disc menu and options.
412 UNDERSTANDING YOUR INSTRUMENT PANEL When connecting an external source to the AUX input, be sure to follow the standard color coding for the VES jacks: NOTE: Certain high-end video games, such as Playstation3 and XBox360 will exceed the power limit of the vehicle’s Power Inverter. Refer to the Power Inverter section in your vehicle’s Owner’s Manual for more information. Using The Remote Control 1. Push the MODE button on the Remote Control. Select VES AUX1 Mode On The VES Screen 2.
UNDERSTANDING YOUR INSTRUMENT PANEL 413 displayed, press the HIDE LIST button on the touch- 3. Press the 1 button on the touchscreen and then press screen to display the Rear VES Controls screen. either AUX 1 or AUX 2 in the VES column (depending which AUX input is used). To exit press the back arrow button at the top of the touchscreen.
414 UNDERSTANDING YOUR INSTRUMENT PANEL Listen To An Audio Source On Channel 2 While A Video Is Playing On Channel 1 Ensure the Remote Control and Headphone switch is on Channel 2. Using The Remote Control 1. Push the SOURCE button on the Remote Control and the Mode Select Screen will display, unless a video is playing then only a small banner will appear on the bottom of the screen. 2.
UNDERSTANDING YOUR INSTRUMENT PANEL 415 displayed, press the HIDE LIST button on the touchscreen to display the Rear VES Controls screen. the touchscreen and choose an audio source. To exit press the back arrow button on the touchscreen at the top left of the left screen. 4 Rear VES Button On The Touchscreen 3.
416 UNDERSTANDING YOUR INSTRUMENT PANEL 3. To watch a DVD on Screen 1 for second row passengers, ensure the Remote Control and Headphone NOTE: Typically there are two different ways to operate switch is on Channel 1. the features of the Video Entertainment System (VES). 4. To watch a DVD on Screen 2 for third row passengers, • The Remote Control ensure the Remote Control and Headphone switch is on Channel 2.
UNDERSTANDING YOUR INSTRUMENT PANEL 417 NOTE: • Channel/Screen 1 select mode information is shown on the left side of the screen. • Channel/Screen 2 select mode information is shown on the right side of the screen. • The VES will retain the last setting when turned off. Using The Touchscreen Radio Controls 1. Push the MENU button on the radio faceplate. Select DISC Mode On The VES Screen 2. Press the Rear VES button on the touchscreen to display the Rear VES Controls.
418 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • To view a DVD on the radio push the RADIO/MEDIA button on the radio faceplate, then press the DISC tab button on the touchscreen and then the VIEW VIDEO button on the touchscreen. • Viewing a DVD on the Touchscreen radio screen is not available in all states/provinces. If available, the vehicle must be stopped and the shift lever must be in the PARK position for vehicles with an automatic transmission.
UNDERSTANDING YOUR INSTRUMENT PANEL 419 2. While looking at Screen 1 or 2, highlight VES DISC by either pushing Up/Down/Left/Right buttons or by 1. Insert the DVD with the label facing up. The VES repeatedly pushing the SOURCE button, then push player automatically selects the appropriate mode ENTER/OK on the Remote Control. after the disc is recognized and starts playing the DVD.
420 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • Channel/Screen 1 select mode information is shown on the left side of the screen. • Channel/Screen 2 select mode information is shown on the right side of the screen. • The VES will retain the last setting when turned off. Using The Touchscreen Radio Controls 1. Push the MENU button on the radio faceplate. 2. Press the Rear VES button on the touchscreen to Rear VES Button On The Touchscreen display the Rear VES Controls.
UNDERSTANDING YOUR INSTRUMENT PANEL 421 • Viewing a DVD on the Touchscreen radio screen is not available in all states/provinces. If available, the vehicle must be stopped and the shift lever must be in the PARK position for vehicles with an automatic transmission. In vehicles with a manual transmission the parking brake must be engaged. Play A Blu-ray Disc Using The Blu-ray Player — If Equipped Select Channel/Screen 1 And DISC In The VES Column NOTE: 1. Insert the Blu-ray Disc with the label facing up.
422 UNDERSTANDING YOUR INSTRUMENT PANEL 2. To watch a Blu-ray Disc on Screen 1 for second row NOTE: passengers, ensure the Remote Control and Head• Channel/Screen 1 select mode information is shown phone switch is on Channel 1. on the left side of the screen. 3. To watch a Blu-ray Disc on Screen 2 for third row • Channel/Screen 2 select mode information is shown passengers, ensure the Remote Control and Headon the right side of the screen. phone switch is on Channel 2.
UNDERSTANDING YOUR INSTRUMENT PANEL 423 3. Press the 1 or 2 button on the touchscreen and then the VES Disc button on the touchscreen in the VES column. To exit press the back arrow button at the top left of the screen. Listen To An Audio Source While A Video Is Playing Ensure the Remote Control and Headphone switch are on the same channel. If watching a video on Screen 1 (second row), then Channel 2 could be used for audio.
424 UNDERSTANDING YOUR INSTRUMENT PANEL 2. While looking at the video screen, either push Up/ Using The Touchscreen Radio Controls Down/Left/Right on the Remote Control to highlight 1. Push the MENU button on the radio faceplate. the desired audio source or repeatedly push the SOURCE button on the remote until the desired audio 2. Press the Rear VES button on the touchscreen to display the Rear VES Controls. If a channel list is source appears on the screen.
UNDERSTANDING YOUR INSTRUMENT PANEL 425 3. To listen to an audio source on Channel 2 while a video is playing on Channel 1, press the 2 button on the touchscreen and choose an audio source. To exit press the back arrow button at the top left of the left screen.
426 UNDERSTANDING YOUR INSTRUMENT PANEL • Selecting a video source on Channel 2, the video source will display on the third row screen or Screen 2 • VES is able to transmit two channels of stereo audio and can be heard on Channel 2. and video simultaneously. • The 2nd row screen and 3rd row screen of the Video • The Blu-ray Disc Player can play CDs, DVDs and Entertainment System can play two separate discs by Blu-ray Discs.
UNDERSTANDING YOUR INSTRUMENT PANEL 427 VES Remote Control — If Equipped Controls And Indicators 1. Power – Turns the screen and wireless headphone transmitter for the selected Channel on or off. To hear audio while the screen is closed, push the Power button to turn the headphone transmitter on. 2. Channel Selector Indicators – When a button is pushed, the currently affected channel or channel button is illuminated momentarily. 3. Light – Turns the remote control backlighting on or off.
428 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Channel/Screen Selector Switch – Indicates which 7. POP UP/MENU – Push to return to the main menu of channel is being controlled by the remote control. a DVD disc, to select a satellite audio channel from the When the selector switch is in the Channel 1 position, Station list, or select playback modes (SCAN/ the remote controls the functionality of headphone RANDOM for a CD). Channel 1 (right side of the screen). When the selector 8.
UNDERSTANDING YOUR INSTRUMENT PANEL 429 11. MUTE – Push to mute the headphone audio output 16. BACK – When navigating in menu mode, push to return to the previous screen. When navigating a for the selected channel. DVDs disc menu, the operation depends on the disc’s 12. SLOW – If Equipped – Push to slow playback of a contents. DVD disc. Push play (䉴) to resume normal play. 17. 䉳䉳 – In radio modes, push to seek to the previous 13. STATUS – If Equipped – Push to display the current tunable station.
430 UNDERSTANDING YOUR INSTRUMENT PANEL Blu-ray Player Remote Control — If Equipped Controls And Indicators 1. Power – Turns the screen and wireless headphone transmitter for the selected Channel on or off. To hear audio while the screen is closed, push the Power button to turn the headphone transmitter on. 2. Channel Selector Indicators – When a button is pushed, the currently affected channel or channel button is illuminated momentarily. 3. SOURCE – Push to enter Source Selection screen.
UNDERSTANDING YOUR INSTRUMENT PANEL 431 6. SETUP – Push to access the Blu-ray Setup menu 11. KEYPAD – Push to navigate chapters or titles. screen. When a disc is loaded in the Blu-ray player (if 12. ▪ (Stop) – Stops disc play. equipped) and the VES mode is selected and the disc is stopped, push the SETUP button to access the 13. 䉳䉳 – Push and release to jump to the previous audio Blu-ray Setup menu. track or video chapter. Push and hold to fast rewind through the current audio track or video chapter. 7.
432 UNDERSTANDING YOUR INSTRUMENT PANEL Remote Control Storage The video screen(s) come with a built in storage compartment for the remote control which is accessible when the screen is opened. To remove the remote, use your index finger to pull and rotate the remote towards you. Do not try to pull the remote straight down as it will be very difficult to remove.
UNDERSTANDING YOUR INSTRUMENT PANEL 433 Locking The Remote Control Replacing The Remote Control Batteries All remote control functionality can be disabled as a parental control feature. The remote control requires two AAA batteries for operation. To replace the batteries: • To disable the Remote Control from making any 1. Locate the battery compartment on the back of the changes, push the Video Lock button on the DVD remote, then slide the battery cover downward. player (if equipped).
434 UNDERSTANDING YOUR INSTRUMENT PANEL Headphones Operation The headphones receive two separate channels of audio using an infrared transmitter from the video screen. Front seat occupants receive some headphone audio coverage to allow them to adjust the headphone volume for the young rear seat occupants that may not be able to do so for themselves.
UNDERSTANDING YOUR INSTRUMENT PANEL 435 Blu-ray Headphones Operation The headphones receive two separate channels of audio using an infrared transmitter from the video screen. Front seat occupants receive some headphone audio coverage to allow them to adjust the headphone volume for the young rear seat occupants that may not be able to do so for themselves.
436 UNDERSTANDING YOUR INSTRUMENT PANEL Controls The headphone power indicator and controls are located on the right ear cup. NOTE: • When both switches are on Channel 1, the Remote is controlling Channel 1 and the headphones are tuned to the audio of the VES Channel 1. NOTE: The rear video system must be turned on before • When both switches are on Channel 2, the Remote is sound can be heard from the headphones.
UNDERSTANDING YOUR INSTRUMENT PANEL 437 4. When the Mode Selection menu appears on screen, use the cursor buttons on the remote control to navigate to the available modes and push the OK button to select the new mode. Unwired Stereo Headphone Lifetime Limited Warranty Who Does This Warranty Cover? This warranty covers the initial user or purchaser (⬙you⬙ or ⬙your⬙) of this 5. To cancel out of the Mode Selection menu, push the particular Unwired Technology LLC (⬙Unwired⬙) wireless headphone (⬙Product⬙).
438 UNDERSTANDING YOUR INSTRUMENT PANEL TECHNOLOGY IS NOT LIABLE FOR ANY INJURIES OR DAMAGES TO PERSONS OR PROPERTY RESULTING FROM THE USE OF, OR ANY FAILURE OR DEFECT IN, THE PRODUCT, NOR IS UNWIRED LIABLE FOR ANY GENERAL, SPECIAL, DIRECT, INDIRECT, INCIDENTAL, CONSEQUENTIAL, EXEMPLARY, PUNITIVE OR OTHER DAMAGES OF ANY KIND OR NATURE WHATSOEVER. Some states and jurisdictions may not allow the exclusion or limitation of incidental or consequential damages, so the above limitation may not apply to you.
UNDERSTANDING YOUR INSTRUMENT PANEL 439 icon will be visible on the VES screen. When in shared When in shared disc mode both the radio and the VES mode, the same audio source is heard in the shared have control of the video functions. The VES has the ability to control the following video modes: headphone channel 1 or channel 2. If the radio functions (FM, AM, or SAT) are in the shared mode with the VES, only the radio is able to control the radio functions.
440 UNDERSTANDING YOUR INSTRUMENT PANEL Information Mode Display Numeric Keypad Menu Information Mode Video Screen Display 1 2 3 4 5 6 — — — — — — Channel 1 Mode Channel 1 Shared Status Channel 1 Audio Only/Mute Channel 2 Mode Channel 2 Shared Status Channel 2 Audio Only/Mute 7 — Channel 1 ENTER/OK Button Action 8 — Channel 2 ENTER/OK Button Action 9 — Clock 10 — Video Lock 11 — Not Available / Error Numeric Keypad Menu When the display for either Channel 1 or Channel 2 shows DIRECT TUNE, pushing th
UNDERSTANDING YOUR INSTRUMENT PANEL 441 makes it easy to enter a specific tuner frequency, satellite Station List Menu channel, or track number. To enter the desired digit: When listening to Satellite audio, pushing the remote 1. Push the remote control’s navigation buttons (䉱, 䉲, 䉴, 䉳) control’s POP UP/MENU button displays a list of all available channels. Navigate this list using the remote to navigate to the desired digit. control’s navigation buttons (䉱, 䉲) to find the desired 2.
442 UNDERSTANDING YOUR INSTRUMENT PANEL Disc Menu list of all commands which control playback of the disc. Using the options you can activate or cancel Scan play and Random play. Display Settings When watching a video source (DVD Video with the disc in Play mode, Aux Video, etc.), pushing the remote control’s SETUP button activates the Display Settings menu. These settings control the appearance of the video on the screen.
UNDERSTANDING YOUR INSTRUMENT PANEL 443 Disc Features control the remote DVD player’s (if the remote control’s power button to turn audio on. If equipped) settings of DVD being watched in the remote audio is still not heard, check that fully charged batteries are installed in the headphones. player.
444 UNDERSTANDING YOUR INSTRUMENT PANEL The Blu-Ray Player is capable of the playing the following types of discs (12 cm diameter): • BD: BDMV (Profile 1.1), BDAV • DVD: DVD-Video, DVD-Audio, AVCREC, AVCHD, DVD-VR end with the extension “.div”, “divx” or “.avi.” To prevent incorrect playback, do not use these extensions for any other types of files. • For DivX files, only DivX Home Theater Profile Ver.3.0 is supported. • Any file that is copy protected will not play.
UNDERSTANDING YOUR INSTRUMENT PANEL 445 • DivX Home Theater Profile 3.0 requires: • Maximum resolution 720 x 480 @ 30fps or 720 x 576 @ 25fps • Minimum resolution 16 x 16 • Maximum frame rate for progressive source 30 frames per second • Maximum field rate for interlaced source 60 fields per second for the DVD/Blu-ray Disc does not match the region code for the player, the disc will stop playing and a warning will be displayed.
446 UNDERSTANDING YOUR INSTRUMENT PANEL content recorded to a DVD-R or DVD-RW disc. DVD- • For CD Data (or CD-ROM) discs, always use the ROM discs (either pressed or recorded) are not supISO-9660 (Level 1 or Level 2), Joliet, or Romeo format. ported. Other formats (such as HFS, or others) are not supported.
UNDERSTANDING YOUR INSTRUMENT PANEL 447 The recommended method for labeling recordable discs • For MP3 files, only version 1 ID3 tag data (such as artist name, track title, album, etc.) are supported. (CD-R, CD-RW, and DVD-R) is with a permanent marker. Do not use adhesive labels as they may separate from the • For Blu-ray files, only version 1.0 / 1.1 / 2.2 / 2.3 and disc, become stuck, and cause permanent damage to the 2.4 ID3 tag data (such as artist name, track title, album, DVD player. etc.
448 UNDERSTANDING YOUR INSTRUMENT PANEL supported. For both formats, the recommended skipping forward 1.0 to 3.0 seconds at a time. If the end sample rate is either 44.1 kHz or 48 kHz. of the disc is reached, the DVD player will return to the beginning of the disc and attempt to play the start of the • To change the current file, use the DVD player’s 䉱 first track.
UNDERSTANDING YOUR INSTRUMENT PANEL 449 Display Other Language Setup All of the Language settings have a special ⬙Other⬙ setting to accommodate languages other than Japanese or English. These languages are selected using a special fourdigit code. To enter a new language code, activate the DVD Setup Menu.
450 UNDERSTANDING YOUR INSTRUMENT PANEL selecting the digit, push the remote control’s Right Rating And Password Setup cursor button to select the next digit. Repeat this digit The Rating and Password settings work together to selection sequence for all four digits. control the types of DVDs that your family watches. Most • When the entire four-digit code is entered, push the DVD-Video discs have a rating (from 1 to 8) assigned to remote control’s ENTER/OK button.
UNDERSTANDING YOUR INSTRUMENT PANEL 451 The default rating is Level 8 (play all discs without a To set the password, activate the DVD Setup Menu and password) and the default password is 0000. follow these additional instructions: • Using the remote control Left and Right cursor buttons, select the Rating tab. • Highlight ⬙Change Password⬙, and then push the remote control’s ENTER/OK button. • Enter the current password.
452 UNDERSTANDING YOUR INSTRUMENT PANEL • After the four-digit password is entered, push the remote control’s ENTER/OK button. If the password is correct, the set password screen is displayed. • Using the remote control’s Up and Down cursor buttons to set the value for the current digit and the remote control’s Right cursor button to select digits, enter the new password. • After the four-digit password is entered, push the remote control’s ENTER/OK button to accept the change.
UNDERSTANDING YOUR INSTRUMENT PANEL 453 To set the rating, activate the DVD Setup Menu and • Using the remote control’s Up and Down cursor follow these additional instructions: buttons, select the new rating level, and then push the remote control’s ENTER/OK button to accept the • Using the remote control’s Left and Right cursor change. buttons, select the Rating tab. Product Agreement • Highlight ⬙Change Rating⬙, and then push the remote Software control’s ENTER/OK button. • Enter the current password.
454 UNDERSTANDING YOUR INSTRUMENT PANEL Code, you expressly assume all risk and liability associ- • THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT PORTFOLIO LICENSE FOR THE PERated with downloading and using the Source Code and SONAL AND NON-COMMERCIAL USE OF A CONcomplying with the user agreements that accompany SUMER TO (i) ENCODE VIDEO IN COMPLIANCE each Source Code. Please note that we cannot respond to WITH THE VC-1 STANDARD (⬙VC-1 VIDEO⬙) any inquiries regarding the source code.
UNDERSTANDING YOUR INSTRUMENT PANEL 455 film and videos and their soundtracks. When a prohib- • This product incorporates copyright protection techited use of an unauthorized copy is detected, a message nology that is protected by U.S. patents and other intellectual property rights. Use of this copyright prowill be displayed and playback or copying will be tection technology must be authorized by Macroviinterrupted.
456 UNDERSTANDING YOUR INSTRUMENT PANEL ABOUT DIVX VIDEO: DivX is a digital video format Trademark created by DivX, LLC, a subsidiary of Rovi Corporation. • Blu-ray Disc, Blu-ray and the logos are trademarks of This is an official DivX Certified device that plays DivX the Blu-ray Disc Association. video. Visit divx.com for more information and software • Java is a registered trademark of Oracle and/or its tools to convert your files into DivX videos. affiliates.
UNDERSTANDING YOUR INSTRUMENT PANEL 457 STEERING WHEEL AUDIO CONTROLS — IF EQUIPPED o’clock positions. The right-hand rocker switch has a pushbutton in the center, and controls the volume and mode of the sound system. Pushing the top of the rocker switch will increase the volume. Pushing the bottom of the rocker switch will decrease the volume. Pushing the center button changes the operation of the radio from AM to FM, or to CD mode, depending on which radio is in the vehicle.
458 UNDERSTANDING YOUR INSTRUMENT PANEL The button located in the center of the left-hand switch CD/DVD/Blu-ray Disc MAINTENANCE will tune to the next preset station that you have pro- To keep a CD/DVD/Blu-ray Disc in good condition, take grammed in the radio preset push-button. the following precautions: CD Player 1. Handle the disc by its edge; avoid touching the Pushing the top of the switch once will go to the next surface. track on the CD. Pushing the bottom of the switch once 2.
UNDERSTANDING YOUR INSTRUMENT PANEL 459 NOTE: If you experience difficulty in playing a particular disc, it may be damaged (i.e., scratched, reflective coating removed, a hair, moisture or dew on the disc) oversized, or have protection encoding. Try a known good disc before considering disc player service. General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada.
460 UNDERSTANDING YOUR INSTRUMENT PANEL Manual Heating And Air Conditioning System — If Equipped The controls for the manual system in this vehicle contain a series of outer rotary dials and inner push knobs. These comfort controls can be set to obtain desired interior conditions. upper and lower rear outlets. When the front control is in Floor, Defrost, or Mix modes, airflow will be directed out of the rear floor outlets.
UNDERSTANDING YOUR INSTRUMENT PANEL 461 1. Left Front Temperature Control 4. Rear Temperature Control — If Equipped Provides left front seat occupant with independent tem- Provides temperature control for the rear cabin. Turn left perature control. Turn left for cooler or right for warmer for cooler or right for warmer temperature settings in the rear cabin. temperature settings. 2. Rear Blower Control — If Equipped 5.
462 UNDERSTANDING YOUR INSTRUMENT PANEL 7. Front Defrost Mode Air is directed through the windshield and side window demist outlets. Use Defrost mode with maximum blower and temperature settings for best windshield and side window defrosting. NOTE: The air conditioning compressor may operate in Mix and Defrost, even if the A/C button is not pushed. This dehumidifies the air to help dry the windshield. To improve fuel economy, use these modes only when necessary. 8.
UNDERSTANDING YOUR INSTRUMENT PANEL 463 CAUTION! (Continued) • Do not use scrapers, sharp instruments, or abrasive window cleaners on the interior surface of the window. • Keep all objects a safe distance from the window. 9. Recirculation Control Button Push this button to choose between outside air intake or recirculation of the air inside the vehicle. An indicator light will illuminate when you are in Recirculation mode.
464 UNDERSTANDING YOUR INSTRUMENT PANEL 10. Air Conditioning (A/C) Button Push and release to change the current setting. The indicator illuminates when ON. 12. Bi-Level Mode Button Air is directed through the panel and floor outlets. NOTE: There is a difference in temperature (in any conditions other than full cold or full hot), between NOTE: If your air conditioning performance seems the upper and lower outlets for added comfort.
UNDERSTANDING YOUR INSTRUMENT PANEL 465 The rear blower and temperature controls for the rear seat passengers are located in the headliner, near the If ECONOMY mode is desired, push the A/C button to center of the vehicle. turn off the indicator light and the A/C compressor. Rotate the temperature control knob to the desired temperature. Also, make sure to select only Panel, Bi-Level or Floor modes. Economy Mode Max A/C For maximum cooling use the A/C and Recirculation mode buttons at the same time.
466 UNDERSTANDING YOUR INSTRUMENT PANEL Rear Blower Control Rear Temperature Control The rear blower control knob can be manually set to off, or any fixed blower speed, by rotating the knob from low to high. This allows the rear seat occupants to control the volume of air circulated in the rear of the vehicle. To change the temperature in the rear of the vehicle, rotate the temperature knob counterclockwise to lower the temperature, and clockwise to increase the temperature.
UNDERSTANDING YOUR INSTRUMENT PANEL 467 • When occupants in the vehicle select the AUTO mode operation, a comfort temperature can be set by using Air comes from both the headliner outlets and the the temperature up and down buttons, and the auto floor outlets. blower operation will be set automatically. NOTE: In many temperature positions, the Bi-Level • The system can be controlled manually, if desired.
468 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Blower Control Display This display shows the current Blower speed selection. 3. Left Front Seat Occupant Temperature Display This display shows the temperature setting for the left front seat occupant. 4. Mode Display This display shows the current Mode selection (Panel, Bi-Level, Floor, Mix). 5. Rear Temperature Control Display Front ATC Panel 1. Air Conditioning (A/C) Button This display shows the current Rear Temperature Control settings.
UNDERSTANDING YOUR INSTRUMENT PANEL 469 7. Auto Indicator 11. Rear Control Button This indicates when the system is in Auto mode. Provides toggle operation between front control screen and rear control screen. Push the button to activate the 8. Right Front Seat Occupant Temperature Display rear climate control screen and allow the front seat This display shows the temperature setting for the right occupants control over the rear climate settings. front seat occupant. 12. Rear Window Defrost 9.
470 UNDERSTANDING YOUR INSTRUMENT PANEL 14. Auto Temperature Control Button 17. Mode Control Button Controls airflow temperature, distribution, volume, and the amount of air recirculation automatically. Push and release to select. Refer to “Automatic Operation” for more information. Performing this function will cause the ATC to switch between manual mode and automatic modes. Push and release to select between Modes (Panel, BiLevel, Floor, Mix).
UNDERSTANDING YOUR INSTRUMENT PANEL 471 Automatic Temperature Control (ATC) NOTE: • It is not necessary to move the temperature settings. The system automatically adjusts the temperature, 1. Push the AUTO button on the front ATC Panel and the mode and fan speed to provide comfort as quickly as words Front Auto will illuminate in the front ATC possible. display, along with two temperatures for the driver and front passenger.
472 UNDERSTANDING YOUR INSTRUMENT PANEL Manual Operation Override NOTE: This system offers a full complement of manual override • If the system is in Mix or Defrost Mode, the A/C can features. The AUTO symbol in the front ATC display will be turned off, but the A/C system shall remain active be turned off when the system is being used in the to prevent fogging of the windows. manual mode.
UNDERSTANDING YOUR INSTRUMENT PANEL 473 Controlling The Rear Climate Controls From The Front ATC Panel The Three-Zone ATC system allows for adjustment of the rear climate controls from the front ATC panel. To change the rear system settings: 4 • Push ⬙REAR⬙ button to change control to rear control mode, Rear display (below) will appear. Control functions now operate rear system. • To return to Front screen, push ⬙REAR⬙ button again, or it will revert to the Front screen after six seconds.
474 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Blower Control Display This display shows the current Blower speed selection. 4. Rear Auto Indicator This indicates when the system is in Rear Auto mode. Rear Mode Control Headliner Mode Air comes from the outlets in the headliner. Each of these outlets can be individually adjusted to direct the flow of air. Moving the air vanes of the outlets to one side will shut off the airflow.
UNDERSTANDING YOUR INSTRUMENT PANEL 475 Pushing the Rear Temperature Lock button on the front ATC panel, illuminates a lock symbol in the rear display. The rear temperature and air source are controlled from the front ATC panel. Rear second row occupants can only adjust the rear ATC control when the Rear Temperature Lock button is turned off. 4 The rear ATC system is located in the headliner, near the center of the vehicle.
476 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Rotate the Rear Blower, Rear Temperature and the Rear Mode Control knobs to suit your comfort needs. customer-programmable feature. Refer to the “Electronic Vehicle Information Center (EVIC) — CustomerProgrammable Features” in this Section. 3. ATC is selected by adjusting the rear blower knob Rear Blower Control counterclockwise to AUTO. Once the desired temperature is displayed, the ATC System will automatically achieve and maintain that comfort level.
UNDERSTANDING YOUR INSTRUMENT PANEL 477 Rear Temperature Control Headliner Mode To change the temperature in the rear of the vehicle, Air comes from the outlets in the headliner. Each rotate the temperature knob counterclockwise to lower of these outlets can be individually adjusted to the temperature, and clockwise to increase the tempera- direct the flow of air. Moving the air vanes of the outlets ture. The rear temperature settings are displayed in the to one side will shut off the airflow.
478 UNDERSTANDING YOUR INSTRUMENT PANEL Recirculation Control Operating Tips When outside air contains smoke, odors, or high humidity, or if rapid cooling is desired, you may wish to recirculate interior air by pushing the Recirculation control button. Recirculation mode should only be used temporarily. The recirculation LED will illuminate when this button is selected. Push the button a second time to turn off the Recirculation mode LED and allow outside air into the vehicle.
UNDERSTANDING YOUR INSTRUMENT PANEL 479 coolant selection. Use of the air Recirculation mode Outside Air Intake during Winter months is not recommended, because it Make sure the air intake, located directly in front of the may cause window fogging. windshield, is free of obstructions such as leaves. Leaves collected in the air intake may reduce airflow, and if they Vacation/Storage enter the plenum, they could plug the water drains.
480 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips Chart
STARTING AND OPERATING CONTENTS 䡵 STARTING PROCEDURES . . . . . . . . . . . . . . . .485 ▫ Brake/Transmission Shift Interlock System . . .494 ▫ Automatic Transmission . . . . . . . . . . . . . . . .486 ▫ Fuel Economy (ECON) Mode . . . . . . . . . . . . .494 ▫ Keyless Enter-N-Go — If Equipped . . . . . . . .487 ▫ Six-Speed Automatic Transmission . . . . . . . . .495 ▫ Normal Starting. . . . . . . . . . . . . . . . . . . . . . .487 䡵 DRIVING ON SLIPPERY SURFACES . . . . . . . . .
482 STARTING AND OPERATING ▫ Power Steering Fluid Check . . . . . . . . . . . . . .508 ▫ Trailer Sway Control (TSC) . . . . . . . . . . . . . .523 䡵 PARKING BRAKE . . . . . . . . . . . . . . . . . . . . . .508 䡵 TIRE SAFETY INFORMATION . . . . . . . . . . . . .523 䡵 BRAKE SYSTEM . . . . . . . . . . . . . . . . . . . . . . .511 ▫ Tire Markings . . . . . . . . . . . . . . . . . . . . . . . .523 䡵 ELECTRONIC BRAKE CONTROL SYSTEM . . . .511 ▫ Tire Identification Number (TIN). . . . . . . . . . .
STARTING AND OPERATING 483 ▫ Spare Tires — If Equipped . . . . . . . . . . . . . . .541 ▫ Gasoline/Oxygenate Blends . . . . . . . . . . . . . .559 ▫ Tire Spinning . . . . . . . . . . . . . . . . . . . . . . . .543 ▫ E-85 Usage In Non-Flex Fuel Vehicles . . . . . . .560 ▫ Tread Wear Indicators . . . . . . . . . . . . . . . . . .544 ▫ MMT In Gasoline . . . . . . . . . . . . . . . . . . . . .560 ▫ Life Of Tire . . . . . . . . . . . . . . . . . . . . . . . . .545 ▫ Materials Added To Fuel . . . . . . .
484 STARTING AND OPERATING ▫ Cruising Range . . . . . . . . . . . . . . . . . . . . . . .565 䡵 TRAILER TOWING . . . . . . . . . . . . . . . . . . . . .571 ▫ Replacement Parts . . . . . . . . . . . . . . . . . . . .565 ▫ Common Towing Definitions . . . . . . . . . . . . .571 ▫ Maintenance . . . . . . . . . . . . . . . . . . . . . . . .566 ▫ Towing Tips . . . . . . . . . . . . . . . . . . . . . . . . .582 䡵 ADDING FUEL . . . . . . . . . . . . . . . . . . . . . . . .
STARTING AND OPERATING 485 STARTING PROCEDURES WARNING! (Continued) Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts. WARNING! • Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage.
486 STARTING AND OPERATING Automatic Transmission Using Fob With Integrated Key (Tip Start) The shift lever must be in the NEUTRAL or PARK NOTE: Normal starting of either a cold or a warm position before you can start the engine. Apply the brakes engine is obtained without pumping or pressing the before shifting into any driving gear. accelerator pedal.
STARTING AND OPERATING 487 Keyless Enter-N-Go — If Equipped 3. Push firmly on the center of the button to secure it into position. This feature allows the driver to oper- Removing The Button ate the ignition switch with the push 1. The ENGINE START/STOP button can be removed of a button, as long as the ENGINE from the ignition switch for Key Fob use. START/STOP button is installed and the Remote Start/Keyless Enter-N-Go 2.
488 STARTING AND OPERATING 2. Press and hold the brake pedal while pushing the 3. If the shift lever/gear selector is not in PARK, the ENGINE START/STOP button must be held for two ENGINE START/STOP button once. seconds or three short pushes in a row with the vehicle 3. The system takes over and attempts to start the speed above 5 mph (8 km/h) before the engine will vehicle. If the vehicle fails to start, the starter will shut off.
STARTING AND OPERATING 489 Keyless Enter-N-Go Functions — With Driver’s Foot OFF The Brake Pedal/Clutch Pedal (In PARK Or NEUTRAL Position) Extreme Cold Weather (Below –20°F or −29°C) To ensure reliable starting at these temperatures, use of an externally powered electric engine block heater (availThe Keyless Enter-N-Go feature operates similar to an able from your authorized dealer) is recommended. ignition switch. It has three positions, OFF, ACC and If Engine Fails To Start RUN.
490 STARTING AND OPERATING WARNING! (Continued) • If the vehicle has a discharged battery, booster cables may be used to obtain a start from a booster battery or the battery in another vehicle. This type of start can be dangerous if done improperly. Refer to “Jump-Starting” in “What To Do In Emergencies” for further information. Clearing A Flooded Engine (Using ENGINE START/STOP Button) 3. Push and release the ENGINE START/STOP button once.
STARTING AND OPERATING 491 The starter motor will disengage automatically in 10 The engine block heater must be plugged in at least one seconds. Once this occurs, release the accelerator pedal, hour to have an adequate warming effect on the engine. place the ignition in the LOCK position, wait 10 to 15 The engine block heater cord is routed under the hood on seconds, then repeat the “Normal Starting” procedure. the driver’s side of the vehicle.
492 STARTING AND OPERATING AUTOMATIC TRANSMISSION CAUTION! Damage to the transmission may occur if the following precautions are not observed: • Shift into or out of PARK or REVERSE only after the vehicle has come to a complete stop. • Do not shift between PARK, REVERSE, NEUTRAL, or DRIVE when the engine is above idle speed. • Before shifting into any gear, make sure your foot is firmly pressing the brake pedal. NOTE: You must press and hold the brake pedal while shifting out of PARK.
STARTING AND OPERATING 493 WARNING! (Continued) WARNING! (Continued) PARK, securing the vehicle against unwanted movement. • Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage. • Never leave children alone in a vehicle, or with access to an unlocked vehicle. Allowing children to be in a vehicle unattended is dangerous for a number of reasons.
494 STARTING AND OPERATING LOCK/OFF position, and the transmission is locked in Fuel Economy (ECON) Mode PARK whenever the ignition switch is in the LOCK/OFF The Fuel Economy (ECON) mode can improve the vehiposition. cle’s overall fuel economy during normal driving condiNOTE: If a malfunction occurs, the system will trap the tions.
STARTING AND OPERATING 495 When the Fuel Economy (ECON) Mode is engaged, the Six-Speed Automatic Transmission vehicle control systems will change the following: The transmission gear position display (located in the • The transmission will upshift sooner and downshift instrument cluster) indicates the transmission gear range. You must press the brake pedal to move the shift lever later.
496 STARTING AND OPERATING The transmission shift lever has only PARK, REVERSE, NEUTRAL, and DRIVE shift positions. Manual downshifts can be made using the Electronic Range Select (ERS) shift control (refer to “Electronic Range Select (ERS) Operation” in this section for further information). Moving the shift lever to the left or right (–/+) while in the DRIVE position will select the highest available transmission gear, and will display that gear in the instrument cluster as 1, 2, 3, etc.
STARTING AND OPERATING 497 PARK (P) This range supplements the parking brake by locking the transmission. The engine can be started in this range. Never attempt to use PARK while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range. When parking on a level surface, you may shift the transmission into PARK first, and then apply the parking brake.
498 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Unintended movement of a vehicle could injure those in or near the vehicle. As with all vehicles, you should never exit a vehicle while the engine is running. Before exiting a vehicle, always apply the parking brake, shift the transmission into PARK, turn the engine OFF, and remove the Key Fob.
STARTING AND OPERATING 499 The following indicators should be used to ensure that you have engaged the transmission into the PARK position: • When shifting into PARK, firmly move the shift lever all the way forward and to the left until it stops and is fully seated. CAUTION! (Continued) • DO NOT race the engine when shifting from PARK or NEUTRAL into another gear range, as this can damage the drivetrain.
500 STARTING AND OPERATING WARNING! Do not coast in NEUTRAL and never turn off the ignition to coast down a hill. These are unsafe practices that limit your response to changing traffic or road conditions. You might lose control of the vehicle and have a collision. CAUTION! Towing the vehicle, coasting, or driving for any other reason with the transmission in NEUTRAL can cause severe transmission damage.
STARTING AND OPERATING 501 During cold temperatures, transmission operation may be modified depending on engine and transmission temperature as well as vehicle speed. This feature improves warm up time of the engine and transmission to achieve maximum efficiency. Engagement of the torque converter clutch is inhibited until the transmission fluid is warm (refer to the “Note” under “Torque Converter Clutch” in this section).
502 STARTING AND OPERATING position, the transmission will operate automatically, shifting between all available gears. Tapping the shift lever to the left (-) will activate ERS mode, display the current gear in the instrument cluster, and set that gear as the top available gear. Once in ERS mode, tapping the shift lever to the left (-) or right (+) will change the top If the transmission cannot be reset, authorized dealer available gear. service is required.
STARTING AND OPERATING 503 Transmission Gear Position Display Actual Gear(s) Allowed 1 2 3 4 5 6 D 1 1–2 1–3 1–4 1–5 1–6 1–6 NOTE: To select the proper gear position for maximum • The engine coolant has reached an adequate temperadeceleration (engine braking), tap the shift lever to the ture. left (-) repeatedly as the vehicle slows. The transmission • The vehicle speed is sufficiently high. will shift to the range from which the vehicle can best be slowed down.
504 STARTING AND OPERATING NOTE: The torque converter clutch will not engage until WARNING! the transmission fluid and engine coolant are warm [usually after 1 to 3 miles (2 to 5 km) of driving]. Because Rapid acceleration on slippery surfaces is dangerous. the engine speed is higher when the torque converter Unequal traction can cause sudden pulling of the clutch is not engaged, it may seem as if the transmission front wheels. You could lose control of the vehicle is not shifting into Overdrive when cold.
STARTING AND OPERATING 505 2. Slow down if the road has standing water or puddles. Flowing/Rising Water 3. Replace the tires when tread wear indicators first become visible. 4. Keep tires properly inflated. 5. Maintain sufficient distance between your vehicle and the vehicle in front of you to avoid a collision in a sudden stop. DRIVING THROUGH WATER WARNING! Do not drive on or across a road or path where water is flowing and/or rising (as in storm run-off).
506 STARTING AND OPERATING WARNING! CAUTION! (Continued) • Driving through standing water limits your vehicle’s traction capabilities. Do not exceed 5 mph (8 km/h) when driving through standing water. • Driving through standing water limits your vehicle’s braking capabilities, which increases stopping distances. Therefore, after driving through standing water, drive slowly and lightly press on the brake pedal several times to dry the brakes.
STARTING AND OPERATING 507 CAUTION! (Continued) damage is not covered by the New Vehicle Limited Warranty. • Getting water inside your vehicle’s engine can cause it to lock up and stall out, and cause serious internal damage to the engine. Such damage is not covered by the New Vehicle Limited Warranty. POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces.
508 STARTING AND OPERATING Power Steering Fluid Check Checking the power steering fluid level at a defined service interval is not required. The fluid should only be checked if a leak is suspected, abnormal noises are apparent, and/or the system is not functioning as anticipated. Coordinate inspection efforts through an authorized dealer. CAUTION! Do not use chemical flushes in your power steering system as the chemicals can damage your power steering components.
STARTING AND OPERATING 509 The foot operated parking brake is positioned below the lower left corner of the instrument panel. To apply the parking brake, firmly press the parking brake pedal fully. To release the parking brake, press the parking brake pedal a second time and let your foot up as you feel the brake disengage. When the parking brake is applied with the ignition switch in the ON position, the “Brake Warning Light” in the instrument cluster will illuminate.
510 STARTING AND OPERATING difficult to move the shift lever out of PARK. The parking brake should always be applied whenever the driver is not in the vehicle. WARNING! (Continued) • When leaving the vehicle, always remove the Key Fob from the ignition and lock your vehicle. • Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage.
STARTING AND OPERATING 511 WARNING! (Continued) injury. Also be certain to leave the transmission in PARK. Failure to do so may allow the vehicle to roll and cause damage or injury. CAUTION! If the Brake System Warning Light remains on with the parking brake released, a brake system malfunction is indicated. Have the brake system serviced by an authorized dealer immediately. BRAKE SYSTEM Your vehicle is equipped with dual hydraulic brake systems.
512 STARTING AND OPERATING Your vehicle may also be equipped with Trailer Sway come on when the ignition switch is turned to the ON position, have the light repaired as soon as possible. Control (TSC). Electronic Brake Force Distribution (EBD) Anti-Lock Brake System (ABS) This function manages the distribution of the braking torque between the front and rear axles by limiting braking pressure to the rear axle.
STARTING AND OPERATING 513 You also may experience the following when ABS activates: • The ABS motor noise (it may continue to run for a short time after the stop). • The clicking sound of solenoid valves. • Brake pedal pulsations. • A slight drop of the brake pedal at the end of the stop. These are all normal characteristics of ABS.
514 STARTING AND OPERATING WARNING! (Continued) • The capabilities of an ABS equipped vehicle must never be exploited in a reckless or dangerous manner that could jeopardize the user’s safety or the safety of others. If the “Anti-Lock Brake Warning Light” is on, the brake system should be serviced as soon as possible to restore the benefits of anti-lock brakes.
STARTING AND OPERATING 515 unless braking is no longer desired. Once the brake pedal the brake while stopped on an incline, HSA will continue to hold the brake pressure for a short period. If the driver is released, the BAS is deactivated. does not apply the throttle before this time expires, the system will release brake pressure and the vehicle will WARNING! roll down the hill as normal.
516 STARTING AND OPERATING • HSA will work in REVERSE gear and all forward gears. The system will not activate if the transmission is in PARK or NEUTRAL. For vehicles equipped with a manual transmission if the clutch is pressed HSA will remain active. WARNING! (Continued) safe control of your vehicle. Failure to follow these warnings can result in a collision or serious personal injury.
STARTING AND OPERATING 517 WARNING! (Continued) incline while resuming acceleration, manually activate the trailer brake or apply more vehicle brake pressure prior to releasing the brake pedal. • HSA is not a parking brake. Always apply the parking brake fully when leaving your vehicle. Also, be certain to leave the transmission in PARK. • Failure to follow these warnings can result in a collision or serious personal injury.
518 STARTING AND OPERATING 7. Rotate the steering wheel back to center and then an other, the system will apply the brake of the spinning additional slighty more than one-half turn to the right. wheel. This will allow more engine torque to be applied to the wheel that is not spinning. BLD may remain 8. Turn the ignition switch to the OFF position and then enabled even if TCS and ESC are in a reduced mode. back to the ON position.
STARTING AND OPERATING 519 • Oversteer - when the vehicle is turning more than appropriate for the steering wheel position. • Understeer - when the vehicle is turning less than appropriate for the steering wheel position. The “ESC Activation/Malfunction Indicator Light” located in the instrument cluster will start to flash as soon as the ESC system becomes active. The “ESC Activation/ Malfunction Indicator Light” also flashes when the TCS is active.
520 STARTING AND OPERATING To enter the “Partial Off” mode, momentarily push the “ESC Off” switch and the “ESC Off Indicator Light” will NOTE: Depending upon model and mode of operation, illuminate. To turn the ESC on again, momentarily push the ESC system may have multiple operating modes. the “ESC Off” switch and the “ESC Off Indicator Light” ESC On will turn off. ESC Operating Modes This is the normal operating mode for the ESC. Whenever the vehicle is started, the ESC system will be in this mode.
STARTING AND OPERATING 521 NOTE: The Electronic Stability Control (ESC) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. ESC cannot prevent all accidents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning. ESC also cannot prevent collisions.
522 STARTING AND OPERATING • Each time the ignition is turned ON, the ESC system engine power to lessen the chance that wheel lift will occur. ERM can only reduce the chance of wheel lift will be ON even if it was turned off previously. occurring during severe or evasive driving maneuvers; it • The ESC system will make buzzing or clicking sounds cannot prevent wheel lift due to other factors, such as when it is active.
STARTING AND OPERATING 523 Trailer Sway Control (TSC) TSC uses sensors in the vehicle to recognize an excessively swaying trailer and will take the appropriate actions to attempt to stop the sway. TSC will become active automatically once an excessively swaying trailer is recognized. Note that TSC cannot stop all trailers from swaying. Always use caution when towing a trailer and follow the trailer tongue weight recommendations. Refer to “Trailer Towing” in this section for further information.
524 STARTING AND OPERATING TIRE SAFETY INFORMATION NOTE: Tire Markings • P (Passenger) — Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Example: P215/65R15 95H. • European — Metric tire sizing is based on European design standards. Tires designed to this standard have the tire size molded into the sidewall beginning with the section width. The letter ⬙P⬙ is absent from this tire size designation.
STARTING AND OPERATING 525 • Temporary spare tires are designed for temporary • High flotation tire sizing is based on U.S. design emergency use only. Temporary high pressure comstandards and it begins with the tire diameter molded pact spare tires have the letter “T” or “S” molded into into the sidewall. Example: 31x10.5 R15 LT. the sidewall preceding the size designation. Example: T145/80D18 103M.
526 STARTING AND OPERATING EXAMPLE: 65, 85, 80 = Aspect ratio in percent (%) – Ratio of section height to section width of tire, or 10.
STARTING AND OPERATING 527 EXAMPLE: H = Speed Symbol – A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions – The maximum speed corresponding to the speed symbol should only be achieved under specified operating conditions (i.e.
528 STARTING AND OPERATING Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side. Tires the outboard side, then you will find it on the inboard side of the tire. with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.
STARTING AND OPERATING 529 EXAMPLE: DOT MA L9 ABCD 0301 01 = Number representing the year in which the tire was manufactured (two digits) – 01 means the year 2001 – Prior to July 2000, tire manufacturers were only required to have one number to represent the year in which the tire was manufactured.
530 STARTING AND OPERATING Term Maximum Inflation Pressure Recommended Cold Tire Inflation Pressure Tire Placard Definition The maximum inflation pressure is the maximum permissible cold tire inflation pressure for this tire. The maximum inflation pressure is molded into the sidewall. Vehicle manufacturer’s recommended cold tire inflation pressure as shown on the tire placard.
STARTING AND OPERATING 531 Tire Loading And Tire Pressure Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door.
532 STARTING AND OPERATING Tire And Loading Information Placard This placard tells you important information about the: 1. Number of people that can be carried in the vehicle. 2. Total weight your vehicle can carry. 3. Tire size designed for your vehicle. 4. Cold tire inflation pressures for the front, rear, and spare tires. Loading Tire And Loading Information Placard The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle.
STARTING AND OPERATING 533 NOTE: Under a maximum loaded vehicle condition, Steps For Determining Correct Load Limit gross axle weight ratings (GAWRs) for the front and rear 1. Locate the statement “The combined weight of occuaxles must not be exceeded. For further information on pants and cargo should never exceed XXX lbs or GAWRs, vehicle loading, and trailer towing, refer to XXX kg” on your vehicle’s placard. “Vehicle Loading” in this manual. 2.
534 STARTING AND OPERATING 4. The resulting figure equals the available amount of NOTE: cargo and luggage load capacity. For example, if • If your vehicle will be towing a trailer, load from your “XXX” amount equals 1,400 lbs (635 kg) and there will trailer will be transferred to your vehicle.
STARTING AND OPERATING 535 5
536 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
STARTING AND OPERATING 537 WARNING! (Continued) • Unequal tire pressures from one side of the vehicle to the other can cause the vehicle to drift to the right or left. • Always drive with each tire inflated to the recommended cold tire inflation pressure. Fuel Economy Underinflated tires will increase tire rolling resistance resulting in higher fuel consumption.
538 STARTING AND OPERATING At least once a month: mile (1.6 km) after sitting for a minimum of three hours. The cold tire inflation pressure must not exceed the • Check and adjust tire pressure with a good quality maximum inflation pressure molded into the tire sidepocket-type pressure gauge. Do not make a visual wall. judgement when determining proper inflation.
STARTING AND OPERATING 539 Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) during operation. DO NOT reduce this normal pressure build up or your tire pressure will be too low. Tire Pressures For High Speed Operation WARNING! High speed driving with your vehicle under maximum load is dangerous. The added strain on your tires could cause them to fail. You could have a serious collision. Do not drive a vehicle loaded to the maximum capacity at continuous speeds above 75 mph (120 km/h).
540 STARTING AND OPERATING Tire Repair Tire Types If your tire becomes damaged, it may be repaired if it All Season Tires — If Equipped meets the following criteria: All Season tires provide traction for all seasons (Spring, Summer, Fall and Winter). Traction levels may vary • The tire has not been driven on when flat. between different all season tires.
STARTING AND OPERATING 541 Summer tires do not contain the all season designation or mountain/snowflake symbol on the tire sidewall. Use Summer tires only in sets of four; failure to do so may adversely affect the safety and handling of your vehicle. WARNING! Do not use Summer tires in snow/ice conditions. You could lose vehicle control, resulting in severe injury or death. Driving too fast for conditions also creates the possibility of loss of vehicle control.
542 STARTING AND OPERATING Run Flat Tires — If Equipped Spare Tires — If Equipped Run Flat tires allow you the capability to drive 50 miles NOTE: For vehicles equipped with Tire Service Kit (80 km) at 50 mph (80 km/h) after a rapid loss of inflation instead of a spare tire, please refer to “Tire Service Kit” in pressure. This rapid loss of inflation is referred to as the “What To Do In Emergencies” for further information. Run Flat mode.
STARTING AND OPERATING 543 rotation for your vehicle. If your vehicle has this option, Do not install a wheel cover or attempt to mount a refer to an authorized tire dealer for the recommended conventional tire on the compact spare wheel, since the wheel is designed specifically for the compact spare tire. tire rotation pattern. Do not install more than one compact spare tire and Compact Spare Tire — If Equipped wheel on the vehicle at any given time. The compact spare is for temporary emergency use only.
544 STARTING AND OPERATING front or rear axle of your vehicle, but it is not. This spare tire may have limited tread life. When the tread is worn to the tread wear indicators, the temporary use full size spare tire needs to be replaced. Since it is not the same as your original equipment tire, replace (or repair) the original equipment tire and reinstall on the vehicle at the first opportunity. Limited-Use Spare — If Equipped The limited-use spare tire is for temporary emergency use only.
STARTING AND OPERATING 545 Refer to “Freeing A Stuck Vehicle” in “What To Do In Emergencies” for further information. WARNING! Fast spinning tires can be dangerous. Forces generated by excessive wheel speeds may cause tire damage or failure. A tire could explode and injure someone. Do not spin your vehicle’s wheels faster than 30 mph (48 km/h) for more than 30 seconds continuously when you are stuck, and do not let anyone near a spinning wheel, no matter what the speed.
546 STARTING AND OPERATING worn to the tread wear indicators, the tire should be replaced. Refer to “Replacement Tires” in this section for further information. Life Of Tire The service life of a tire is dependent upon varying factors including, but not limited to: • Driving style. tread life. Rotation of these tires per the vehicle maintenance schedule is highly recommended. WARNING! Tires and the spare tire should be replaced after six years, regardless of the remaining tread.
STARTING AND OPERATING 547 wear and correct cold tire inflation pressures. The manufacturer strongly recommends that you use tires equivalent to the originals in size, quality and performance when replacement is needed. Refer to the paragraph on “Tread Wear Indicator”. Refer to the Tire and Loading Information placard or the Vehicle Certification Label for the size designation of your tire. The Load Index and Speed Symbol for your tire will be found on the original equipment tire sidewall.
548 STARTING AND OPERATING WARNING! (Continued) • Never use a tire with a smaller load index or capacity, other than what was originally equipped on your vehicle. Using a tire with a smaller load index could result in tire overloading and failure. You could lose control and have a collision. • Failure to equip your vehicle with tires having adequate speed capability can result in sudden tire failure and loss of vehicle control.
STARTING AND OPERATING 549 CAUTION! CAUTION! (Continued) To avoid damage to your vehicle or tires, observe the following precautions: • Because of restricted traction device clearance between tires and other suspension components, it is important that only traction devices in good condition are used. Broken devices can cause serious damage. Stop the vehicle immediately if noise occurs that could indicate device breakage. Remove the damaged parts of the device before further use.
550 STARTING AND OPERATING tires. Rotation will increase tread life, help to maintain mud, snow and wet traction levels, and contribute to a smooth, quiet ride. Refer to the “Maintenance Schedule” for the proper maintenance intervals. The reasons for any rapid or unusual wear should be corrected prior to rotation being performed. The suggested rotation method is the “rearward cross” shown in the following diagram. This rotation pattern does not apply to some directional tires that must not be reversed.
STARTING AND OPERATING 551 The tire pressure will vary with temperature by about 1 psi (7 kPa) for every 12°F (6.5°C). This means that when the outside temperature decreases, the tire pressure will decrease. Tire pressure should always be set based on cold inflation tire pressure. This is defined as the tire pressure after a vehicle has not been driven for more than three hours - and in outside ambient temperature.
552 STARTING AND OPERATING For example, your vehicle may have a recommended cold (parked for more than three hours) tire placard pressure of 35 psi (241 kPa). If the ambient temperature is 68°F (20°C) and the measured tire pressure is 30 psi (207 kPa), a temperature drop to 20°F (-7°C) will decrease the tire pressure to approximately 26 psi (179 kPa). This tire pressure is sufficiently low enough to turn on the “Tire Pressure Monitoring Telltale Light.
STARTING AND OPERATING 553 • Seasonal temperature changes will affect tire pressure, and the TPMS will monitor the actual tire pressure in • The TPMS is not intended to replace normal tire care the tire. and maintenance, or to provide warning of a tire Base System failure or condition. NOTE: • The TPMS should not be used as a tire pressure gauge The TPMS uses wireless technology with wheel rim mounted electronic sensors to monitor tire pressure levwhile adjusting your tire pressure. els.
554 STARTING AND OPERATING Tire Pressure Monitoring Low Tire Pressure Warnings The system will automatically update and the “Tire Pressure Monitoring Telltale Light” will extinguish once the updated tire pressures have been received. The “Tire Pressure Monitoring Telltale Light” will illuminate in the instrument cluster, a “LOW TIRE PRESSURE” message will display in the instrument cluster, and an audible chime will be activated when one or more of the four active road tire pressures are low.
STARTING AND OPERATING 555 • Installing some form of aftermarket window tinting • After driving for up to 20 minutes above 15 mph that affects radio wave signals. (24 km/h), the “Tire Pressure Monitoring Telltale Light” will flash on and off for 75 seconds and then • Accumulation of excessive snow and/or ice around remain on solid. the wheels or wheel housings. • For each subsequent ignition switch cycle, a chime will • Using tire chains on the vehicle.
556 STARTING AND OPERATING Premium System — If Equipped The TPMS uses wireless technology with wheel rimmounted electronic sensors to monitor tire pressure levels. Sensors mounted to each wheel as part of the valve stem transmit tire pressure readings to the Receiver Module. TPMS Low Pressure Warnings The “Tire Pressure Monitoring Telltale Light” will illuminate in the instrument cluster, and an audible chime will be activated when one or more of the four active road tire pressures are low.
STARTING AND OPERATING 557 If the ignition switch is cycled, this sequence will repeat, providing the system fault still exists. If the system fault no longer exists, the “Tire Pressure Monitoring Telltale Light” will no longer flash, the “SERVICE TPM SYSTEM” message will not be present, and a pressure value will be NOTE: The vehicle may need to be driven for up to 20 displayed instead of dashes.
558 STARTING AND OPERATING The EVIC will also display a “SERVICE TPM SYSTEM” “LOW TIRE” message will be displayed, a chime will message for a minimum of five seconds when a system sound, and the EVIC will still display a flashing fault possibly related to an incorrect sensor location fault pressure value and the ⬙Inflate Tire to XX⬙ message in is present. In this case, the “SERVICE TPM SYSTEM” the graphic display.
STARTING AND OPERATING 559 • Once you repair or replace the original road tire, and reinstall it on the vehicle in place of the compact spare, the TPMS will update automatically. In addition, the “Tire Pressure Monitoring Telltale Light” will turn off and the graphic in the EVIC will display a new pressure value instead of dashes (- -), as long no tire pressure is below the low pressure warning limit in any of the four active road tires.
560 STARTING AND OPERATING octane “Premium” gasoline is not required, as it will not Reformulated gasoline contains oxygenates and are speprovide any benefit over “Regular” gasoline in these cifically blended to reduce vehicle emissions and improve air quality. engines. While operating on gasoline with an octane number of 87, hearing a light knocking sound from the engine is not a cause for concern. However, if the engine is heard making a heavy knocking sound, see your dealer immediately.
STARTING AND OPERATING 561 CAUTION! (Continued) cause emissions to exceed the applicable standard, and/or cause the “Malfunction Indicator Light” to illuminate. Please observe pump labels as they should clearly communicate if a fuel contains greater than 15% ethanol (E-15). If a Non-FFV vehicle is inadvertently fueled with E-85 fuel, the engine will have some or all of these symptoms: • Operate in a lean mode. • OBD II “Malfunction Indicator Light” on. • Poor engine performance.
562 STARTING AND OPERATING without MMT be used in your vehicle. The MMT content of gasoline may not be indicated on the gasoline pump, therefore, you should ask your gasoline retailer whether the gasoline contains MMT. MMT is prohibited in Federal and California reformulated gasoline. Indiscriminate use of fuel system cleaning agents should be avoided. Many of these materials intended for gum and varnish removal may contain active solvents or similar ingredients.
STARTING AND OPERATING 563 CAUTION! (Continued) some light smoke, your engine may be out of tune or malfunctioning and may require immediate service. Contact your authorized dealer for service assistance. • The use of fuel additives, which are now being sold as octane enhancers, is not recommended. Most of these products contain high concentrations of methanol.
564 STARTING AND OPERATING WARNING! (Continued) time the vehicle is raised. Have any abnormal conditions repaired promptly. Until repaired, drive with all side windows fully open. CAUTION! Only vehicles with the E-85 fuel filler door label or a yellow gas cap can operate on E-85. Ethanol Fuel (E-85) FLEXIBLE FUEL — IF EQUIPPED E-85 General Information The information in this section is unique for Flexible Fuel vehicles only.
STARTING AND OPERATING 565 Fuel Requirements NOTE: If your vehicle is E-85 compatible, it will operate on • Use seasonally adjusted E-85 fuel (ASTM D5798). With unleaded gasoline with any octane rating, or solely E-85 non-seasonally adjusted E-85 fuel, hard starting and fuel, or any mixture of these fuels.
566 STARTING AND OPERATING FCA US Material Standard MS-6395. It is recommended that engine oils that are API Certified and meet the requirements of Material Standard MS-6395 be used. MS-6395 contains additional requirements, developed during extensive fleet testing, to provide additional protection to FCA US LLC engines. Starting Cruising Range Because E-85 fuel contains less energy per gallon/liter than gasoline, an increase in fuel consumption will be experienced.
STARTING AND OPERATING 567 Maintenance CAUTION! Do not use ethanol mixture greater than 85% in your vehicle. It will cause difficulty in cold starting and may affect drivability. ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is located behind the fuel filler door on the left side of the vehicle. If the gas cap is lost or damaged, Fuel Filler Cap be sure the replacement cap is for use with this vehicle. NOTE: The driver’s side sliding door cannot be opened while the fuel door is open.
568 STARTING AND OPERATING CAUTION! WARNING! (Continued) • Damage to the fuel system or emissions control system could result from using an improper fuel tank filler tube cap. A poorly fitting cap could let impurities into the fuel system and may cause the “Malfunction Indicator Light (MIL)” to turn on, due to fuel vapors escaping from the system. • To avoid fuel spillage and overfilling, do not “top off” the fuel tank after filling.
STARTING AND OPERATING 569 Loose Fuel Filler Cap Message VEHICLE LOADING If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a “gASCAP” message will display in the odometer or a “CHECK GASCAP” message will be displayed in the Electronic Vehicle Information Center (EVIC). Refer to “Electronic Vehicle Information Center” in “Understanding Your Instrument Panel” for further information.
570 STARTING AND OPERATING • Vehicle Identification Number (VIN) • Type of Vehicle • Month Day and Hour of Manufacture (MDH) The bar code allows a computer scanner to read the VIN. Gross Vehicle Weight Rating (GVWR) WARNING! Because the front wheels steer the vehicle, it is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have a collision.
STARTING AND OPERATING 571 The best way to figure out the total weight of your vehicle is to weigh it when it is fully loaded and ready for This is the cold tire inflation pressure for your vehicle for operation. Weigh it on a commercial scale to ensure that all loading conditions up to full GAWR. it is not over the GVWR. Curb Weight Figure out the weight on the front and rear of the vehicle The curb weight of a vehicle is defined as the total weight separately.
572 STARTING AND OPERATING have exceeded either GAWR, but the total load is within the specified GVWR, you must redistribute the weight. Improper weight distribution can have an adverse effect on the way your vehicle steers and handles and the way the brakes operate.
STARTING AND OPERATING 573 The recommended way to measure GTW is to put your Tongue Weight (TW) fully loaded trailer on a vehicle scale. The entire weight The tongue weight is the downward force exerted on the of the trailer must be supported by the scale. hitch ball by the trailer. The recommended tongue weight is 10% to 15% of the vehicle’s GTW for a conventional Gross Axle Weight Rating (GAWR) hitch.
574 STARTING AND OPERATING steering and brake control thereby enhancing towing safety. The addition of a friction/hydraulic sway control also dampens sway caused by traffic and crosswinds and contributes positively to tow vehicle and trailer stability.
STARTING AND OPERATING 575 Trailer Hitch Classification The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Trailer Hitch Classification Definitions Class Max.
576 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/ Transmission GCWR (Gross Combined Weight Rating) 8,750 lbs (3 969 kg) Frontal Area Up to 2 persons & Luggage 3,600 lbs (1 633 kg)* 8,750 lbs (3 969 kg) 40 sq ft (3.72 sq m) 3 to 5 persons & Luggage 3,350 lbs (1 519 kg)* 8,750 lbs (3 969 kg) 40 sq ft (3.
STARTING AND OPERATING 577 NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the Tire and Loading Information placard. Refer to “Tire Safety Information” in “Starting and Operating” for further information. Trailer And Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
578 STARTING AND OPERATING NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options or dealer-installed options must be considered as part of the total load on your vehicle. Refer to the “Tire And Loading Information” placard for the maximum combined weight of occupants and cargo for your vehicle. Towing Requirements CAUTION! • Do not tow a trailer at all during the first 500 miles (805 km) the new vehicle is driven.
STARTING AND OPERATING 579 WARNING! WARNING! (Continued) Improper towing can lead to a collision. Follow these guidelines to make your trailer towing as safe as possible: • Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control. You could lose control of your vehicle and have a collision.
580 STARTING AND OPERATING WARNING! (Continued) • Total weight must be distributed between the tow vehicle and the trailer such that the following four ratings are not exceeded: 1. GVWR 2. GTW 3. GAWR 4. Tongue weight rating for the trailer hitch utilized. • Proper tire inflation pressures are essential to the safe and satisfactory operation of your vehicle. Refer to “Tires – General Information” in “Starting And Operating” for proper tire inflation procedures.
STARTING AND OPERATING 581 Towing Requirements — Trailer Brakes • Do not interconnect the hydraulic brake system or vacuum system of your vehicle with that of the trailer. This could cause inadequate braking and possible personal injury. • An electronically actuated trailer brake controller is required when towing a trailer with electronically actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic brake controller is not required.
582 STARTING AND OPERATING Towing Requirements — Trailer Lights And Wiring Whenever you pull a trailer, regardless of the trailer size, stoplights and turn signals on the trailer are required for motoring safety. The Trailer Tow Package may include a four- and sevenpin wiring harness. Use a factory approved trailer harness and connector. NOTE: Do not cut or splice wiring into the vehicles wiring harness.
STARTING AND OPERATING 583 Towing Tips Before setting out on a trip, practice turning, stopping, and backing up the trailer in an area located away from heavy traffic. Automatic Transmission The DRIVE range can be selected when towing. However, if frequent shifting occurs while in DRIVE, use the Electronic Range Select (ERS) shift control to select a lower gear range.
584 STARTING AND OPERATING If you REGULARLY tow a trailer for more than 45 minutes of continuous operation, then change the transmission fluid and filter as specified for “police, taxi, fleet, or frequent trailer towing”. Refer to the “Maintenance Schedule” for the proper maintenance intervals. Cooling System Electronic Speed Control — If Equipped When stopped for short periods, shift the transmission into NEUTRAL and increase engine idle speed. • Do not use in hilly terrain or with heavy loads.
STARTING AND OPERATING 585 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Flat Tow Dolly Tow On Trailer Wheels OFF the Ground NONE Front Rear ALL NOTE: When recreationally towing your vehicle, always follow applicable state and provincial laws. Contact state and provincial Highway Safety offices for additional details.
586 STARTING AND OPERATING Recreational Towing — All Models Recreational towing is allowed ONLY if the front wheels are OFF the ground. This may be accomplished using a tow dolly or vehicle trailer. If using a tow dolly, follow this procedure: 1. Properly secure the dolly to the tow vehicle, following the dolly manufacturer’s instructions. 2. Drive the front wheels onto the tow dolly. 3. Firmly apply the parking brake. Place the transmission in PARK. 4.
WHAT TO DO IN EMERGENCIES CONTENTS 䡵 HAZARD WARNING FLASHERS . . . . . . . . . . .589 䡵 JACKING AND TIRE CHANGING — IF EQUIPPED . . . . . . . . . . . . . . . . . . . . . 䡵 IF YOUR ENGINE OVERHEATS . . . . . . . . . . . .589 ▫ Jack Location . . . . . . . . . . . . . . . . . . 䡵 TIRE SERVICE KIT — IF EQUIPPED . . . . . . . . .590 ▫ Spare Tire Removal . . . . . . . . . . . . . . ▫ Tire Service Kit Storage . . . . . . . . . . . . . . . . .590 ▫ To Access Spare Tire Winch Drive Nut.
588 WHAT TO DO IN EMERGENCIES ▫ Road Tire Installation . . . . . . . . . . . . . . . . . . .620 䡵 FREEING A STUCK VEHICLE . . . . . . . . . . . . .626 䡵 JUMP-STARTING . . . . . . . . . . . . . . . . . . . . . .622 䡵 SHIFT LEVER OVERRIDE . . . . . . . . . . . . . . . .627 ▫ Preparations For Jump-Start . . . . . . . . . . . . . .622 䡵 TOWING A DISABLED VEHICLE . . . . . . . . . . .628 ▫ Jump-Starting Procedure . . . . . . . . . . . . . . . .
WHAT TO DO IN EMERGENCIES 589 HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located in the In any of the following situations, you can reduce the lower center area of the instrument panel. potential for overheating by taking the appropriate action. Push the switch to turn on the Hazard Warning flasher. When the switch is activated, all direc- • On the highways — slow down.
590 WHAT TO DO IN EMERGENCIES supplement to the radiator and aids in removing heat from the engine cooling system. CAUTION! Driving with a hot cooling system could damage your vehicle. If temperature gauge reads “H”, pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range. If the pointer remains on the “H”, turn the engine off immediately, and call for service.
WHAT TO DO IN EMERGENCIES 591 Tire Service Kit Storage The Tire Service Kit is stowed behind the rear left side trim panel in the rear cargo area. 2. Turn the two rear left side trim panel latches to release the trim panel. 6 Tire Service Kit Tire Service Kit Location 1. Open the liftgate.
592 WHAT TO DO IN EMERGENCIES Tire Service Kit Components And Operation Using The Mode Select Knob And Hoses Your Tire Service Kit is equipped with the following symbols to indicate the air or sealant mode. Selecting Air Mode Push in the Mode Select Knob (5) and turn to this position for air pump operation only. Use the Black Air Pump Hose (7) when selecting this mode.
WHAT TO DO IN EMERGENCIES 593 Using The Power Button Push and release the Power Button (4) once to turn On the Tire Service Kit. Push and release the Power Button (4) again to turn Off the Tire Service Kit. Using The Deflation Button Push the Deflation Button (2) to reduce the air pressure in the tire if it becomes over-inflated.
594 WHAT TO DO IN EMERGENCIES from the vehicle or tire and wheel components. Once the sealant dries, it can easily be peeled off and properly discarded. • For optimum performance, make sure the valve stem on the wheel is free of debris before connecting the Tire Service Kit. • You can use the Tire Service Kit air pump to inflate bicycle tires.
WHAT TO DO IN EMERGENCIES 595 WARNING! (Continued) WARNING! (Continued) • Keep Tire Service Kit away from open flames or heat source. • A loose Tire Service Kit thrown forward in a collision or hard stop could endanger the occupants of the vehicle. Always stow the Tire Service Kit in the place provided. Failure to follow these warnings can result in injuries that are serious or fatal to you, your passengers, and others around you.
596 WHAT TO DO IN EMERGENCIES on the ground. This will provide the best positioning 4. Remove the cap from the valve stem and then screw the fitting at the end of the Sealant Hose (6) onto the of the kit when injecting the sealant into the deflated valve stem. tire and running the air pump. Move the vehicle as necessary to place the valve stem in this position 5. Uncoil the Power Plug (8) and insert the plug into the before proceeding. vehicle’s 12 Volt power outlet. 3.
WHAT TO DO IN EMERGENCIES 597 NOTE: Sealant may leak out through the puncture in the NOTE: If the Mode Select Knob (5) is on Air Mode and tire. the pump is operating, air will dispense from the Air Pump Hose (7) only, not the Sealant Hose (6). If the sealant (white fluid) does not flow within 0 – 10 seconds through the Sealant Hose (6): If the sealant (white fluid) does flow through the Sealant Hose (6): 1. Push the Power Button (4) to turn Off the Tire Service Kit.
598 WHAT TO DO IN EMERGENCIES If the tire does not inflate to at least 26 psi (1.8 Bar) pressure within 15 minutes: • The tire is too badly damaged. Do not attempt to drive the vehicle further. Call for assistance. NOTE: If the tire becomes over-inflated, push the Deflation Button to reduce the tire pressure to the recommended inflation pressure before continuing. If the tire inflates to the recommended pressure or is at least 26 psi (1.8 Bar) pressure within 15 minutes: 1.
WHAT TO DO IN EMERGENCIES 599 distribution of the Tire Service Kit Sealant within the tire. 2. Uncoil the power plug and insert the plug into the Do not exceed 55 mph (90 km/h). vehicle’s 12 Volt power outlet. WARNING! Tire Service Kit is not a permanent flat tire repair. Have the tire inspected and repaired or replaced after using Tire Service Kit. Do not exceed 55 mph (90 km/h) until the tire is repaired or replaced.
600 WHAT TO DO IN EMERGENCIES NOTE: If the tire becomes over-inflated, push the Defla- NOTE: When having the tire serviced, advise the authotion Button to reduce the tire pressure to the recom- rized dealer or service center that the tire has been sealed using the Tire Service Kit. mended inflation pressure before continuing. 2. Disconnect the Tire Service Kit from the valve stem, (F) Sealant Bottle And Hose Replacement: reinstall the cap on the valve stem and unplug from 12 1.
WHAT TO DO IN EMERGENCIES 601 6. Verify that the cap is installed on the fitting at the end Torque Specifications of the Sealant Hose (6) and return the hose to its Lug Nut/Bolt Torque storage area (located on the bottom of the air pump). 7. Return the Tire Service Kit to its storage location in the vehicle. WHEEL AND TIRE TORQUE SPECIFICATIONS Proper lug nut/bolt torque is very important to ensure that the wheel is properly mounted to the vehicle.
602 WHAT TO DO IN EMERGENCIES Wheel Mounting Surface Torque Patterns Tighten the lug nuts/bolts in a star pattern until each After 25 miles (40 km) check the lug nut/bolt torque to be nut/bolt has been tightened twice. sure that all the lug nuts/bolts are properly seated against the wheel.
WHAT TO DO IN EMERGENCIES 603 WARNING! WARNING! (Continued) To avoid the risk of forcing the vehicle off the jack, do not tighten the lug nuts fully until the vehicle has been lowered. Failure to follow this warning may result in personal injury. under a vehicle that is on a jack. If you need to get under a raised vehicle, take it to a service center where it can be raised on a lift. • Never start or run the engine while the vehicle is on a jack.
604 WHAT TO DO IN EMERGENCIES drive” nut is located on the floor, under a plastic cap at the front of the floor console or under front super console forward bin liner. Jack And Tool Location Spare Tire Removal The spare tire is stowed inside a protective cover located under the center of the vehicle between the front doors by means of a cable winch mechanism.
WHAT TO DO IN EMERGENCIES 605 To Access Spare Tire Winch Drive Nut To access the spare tire winch drive nut and lower the spare tire, you will need to refer to one of the following center console configurations. Super Console For vehicles equipped with the Super Console, the spare tire winch assembly drive nut is located beneath the console. 6 Super Console 1 — Lower Drawer 2 — Front Drawer 3 — Front Drawer Liner 1.
606 WHAT TO DO IN EMERGENCIES 2. Open the front drawer to expose the storage compart- Premium/Base/Cargo Center Console ment. Pull the Winch Cover assembly plug (if equipped) to 3. Remove the liner from the console’s storage compart- access the winch drive nut. ment to access the spare tire winch drive nut.
WHAT TO DO IN EMERGENCIES 607 Spare Tire Tools The tool pouch contains three pieces and can be assembled into a spare tire hook; to remove the compact spare tire/cover assembly from under the vehicle, or a Winch T-handle; to raise/lower the compact spare tire/ cover assembly.
608 WHAT TO DO IN EMERGENCIES Spare Tire Removal Instructions The spare tire is located under the vehicle beneath the center console area. Assembling The Spare Tire Hook 1 — Spare Tire Hook/T-handle 2 — Extension 1 3 — Extension 2 Spare Tire And Cover 1. Assemble the spare tire tools into a T-handle and place the square end over the spare tire winch drive nut.
WHAT TO DO IN EMERGENCIES 609 2. Rotate the nut to the left until the winch mechanism stops turning freely. This will allow enough slack in the cable to allow you to pull the spare tire out from underneath the vehicle. CAUTION! The winch mechanism is designed for use with the winch T-handle only. Use of an air wrench or other power tools is not recommended and can damage the winch. 3.
610 WHAT TO DO IN EMERGENCIES 4. Stand the tire/cover assembly upright and remove the Preparations For Jacking wheel spacer by squeezing the winch retaining tabs 1. Park the vehicle on a firm, level surface. Avoid ice or together. Push the retainer through the spare tire to slippery areas. release it from the wheel. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic, pull far enough off the road to avoid being hit when operating the jack or changing the wheel. 2.
WHAT TO DO IN EMERGENCIES 611 6. Block both the front and rear of the wheel diagonally Jacking Instructions opposite of the jacking position. For example, if changing the right front WARNING! tire, block the left rear wheel. Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: • Always park on a firm, level surface as far from the edge of the roadway as possible before raising the NOTE: Passengers should not remain in the vehicle vehicle.
612 WHAT TO DO IN EMERGENCIES WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a jack. • Do not get under the vehicle when it is on a jack. If you need to get under a raised vehicle, take it to a service center where it can be raised on a lift. • Only use the jack in the positions indicated and for lifting this vehicle during a tire change. • If working on or near a roadway, be extremely careful of motor traffic.
WHAT TO DO IN EMERGENCIES 613 2. There are two jack engagement locations on each side of the vehicle body. These locations are on the sill flange of the vehicle body. CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated. Rear jack locations are between a pair of down-facing tabs on the sill flange of the vehicle side body.
614 WHAT TO DO IN EMERGENCIES Rear Jack Engaged Front jack location is on the sill flange of the vehicle body and is located 6 inches (150 mm) from door edge.
WHAT TO DO IN EMERGENCIES 615 WARNING! Being under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never get any part of your body under a vehicle that is on a jack. If you need to get under a raised vehicle, take it to a service center where it can be raised on a lift. Front Jack Engaged 3. Place the wrench on the jack screw and turn to the right until the jack head is properly engaged in the described location.
616 WHAT TO DO IN EMERGENCIES WARNING! CAUTION! (Continued) Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. damaged if the compact spare tire is mounted incorrectly. 5. Remove the wheel lug nuts, for vehicles with wheel covers, remove the cover from the wheel by hand. Do not pry the wheel cover off. Then pull the wheel off the hub. 6. Install the compact spare tire.
WHAT TO DO IN EMERGENCIES 617 WARNING! WARNING! To avoid the risk of forcing the vehicle off the jack, do not tighten the wheel nuts fully until the vehicle has been lowered. Failure to follow this warning may result in serious injury. A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the vehicle. Always stow the jack parts and the spare tire in the places provided. Have the deflated (flat) tire repaired or replaced immediately.
618 WHAT TO DO IN EMERGENCIES NOTE: Refer to the “Spare Tire Tools” section for instructions on assembling the T-handle. 12. Stow the jack, jack handle and winch handle tools back in the stowage compartment. 13. Check the compact spare tire pressure as soon as possible. Correct the tire pressure, as required. WARNING! A loose compact spare tire/cover assembly, thrown forward in a collision or hard stop could endanger the occupants of the vehicle.
WHAT TO DO IN EMERGENCIES 619 3. Turn the compact spare tire so that the valve stem is down, and place the tire into the compact spare tire/cover assembly. Slide the wheel spacer through the center of the wheel and compact spare tire/cover assembly, so that the two retainer tabs snap out and engage the compact spare tire cover on the opposite side. CAUTION! The compact spare tire/cover assembly must be used when the compact spare tire is stored.
620 WHAT TO DO IN EMERGENCIES compact spare tire/cover assembly is positioned correctly against the underside of the vehicle. CAUTION! The winch mechanism is designed specifically to stow a compact spare tire only. Do not attempt to use the winch to stow the full size deflated tire, or any other full-size tire, as the tire may not be held securely. Vehicle damage may result. Road Tire Installation Vehicles Equipped With Wheel Covers 1. Mount the road tire on the axle.
WHAT TO DO IN EMERGENCIES 621 snapping the cover over the two lug nuts. Do not use 7. After 25 miles (40 km) check the lug nut torque with a a hammer or excessive force to install the cover. torque wrench to ensure that all lug nuts are properly seated against the wheel. 4. Install the remaining lug nuts with the cone shaped end of the nut toward the wheel. Lightly tighten the Vehicles Without Wheel Covers lug nuts. 1. Mount the road tire on the axle.
622 WHAT TO DO IN EMERGENCIES 3. Lower the vehicle to the ground by turning the jack NOTE: When using a portable battery booster pack follow the manufacturer’s operating instructions and handle counterclockwise. precautions. 4. Refer to “Torque Specifications” in this section for proper wheel lug nut torque. CAUTION! 5. After 25 miles (40 km) check the lug nut torque with a torque wrench to ensure that all lug nuts are properly seated against the wheel.
WHAT TO DO IN EMERGENCIES 623 Preparations For Jump-Start The battery in your vehicle is located on the left side of the engine compartment. Positive Battery Post WARNING! • Take care to avoid the radiator cooling fan whenever the hood is raised. It can start anytime the ignition switch is ON. You can be injured by moving fan blades. • Remove any metal jewelry such as rings, watch bands and bracelets that could make an inadvertent electrical contact. You could be seriously injured.
624 WHAT TO DO IN EMERGENCIES 3. If using another vehicle to jump-start the battery, park the vehicle within the jumper cables reach, set the parking brake and make sure the ignition is OFF. WARNING! Do not allow vehicles to touch each other as this could establish a ground connection and personal injury could result. Jump-Starting Procedure CAUTION! Failure to follow these procedures could result in damage to the charging system of the booster vehicle or the discharged vehicle.
WHAT TO DO IN EMERGENCIES 625 4. Connect the opposite end of the negative (-) jumper 6. Once the engine is started, remove the jumper cables cable to a good engine ground (exposed metal part of in the reverse sequence: the discharged vehicle’s engine) away from the battery Disconnecting The Jumper Cables and the fuel injection system. 1. Disconnect the negative (-) end of the jumper cable from the engine ground of the vehicle with the disWARNING! charged battery.
626 WHAT TO DO IN EMERGENCIES CAUTION! Accessories plugged into the vehicle power outlets draw power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough without engine operation, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent the engine from starting. FREEING A STUCK VEHICLE If your vehicle becomes stuck in mud, sand or snow, it can often be moved using a rocking motion.
WHAT TO DO IN EMERGENCIES 627 CAUTION! WARNING! (Continued) • When “rocking” a stuck vehicle by shifting between DRIVE and REVERSE, do not spin the wheels faster than 15 mph (24 km/h), or drivetrain damage may result. • Revving the engine or spinning the wheels too fast may lead to transmission overheating and failure. It can also damage the tires. Do not spin the wheels above 30 mph (48 km/h) while in gear (no transmission shifting occurring). explode and injure someone.
628 WHAT TO DO IN EMERGENCIES 4. Press and maintain firm pressure on the brake pedal. 5. Insert the screwdriver or similar tool into the access hole, and push and hold the override release lever forward. 6. Move the shift lever to the NEUTRAL position. 7. The vehicle may then be started in NEUTRAL. 8. Reinstall the shift lever override access cover. TOWING A DISABLED VEHICLE Shift Lever Override Access Cover This section describes procedures for towing a disabled vehicle using a commercial towing service.
WHAT TO DO IN EMERGENCIES 629 Towing Condition Flat Tow Wheel lift Wheels OFF the Ground NONE Rear Flatbed Front ALL Proper towing or lifting equipment is required to prevent damage to your vehicle. Use only tow bars and other equipment designed for this purpose, following equipment manufacturer’s instructions. Use of safety chains is mandatory. Attach a tow bar or other towing device to main structural members of the vehicle, not to bumpers or associated brackets.
630 WHAT TO DO IN EMERGENCIES CAUTION! • Do not use sling type equipment when towing. Vehicle damage may occur. • When securing the vehicle to a flatbed truck, do not attach to front or rear suspension components. Damage to your vehicle may result from improper towing. • Do not push or tow this vehicle with another vehicle as damage to the bumper fascia and transmission may result. The manufacturer recommends towing your vehicle with all four wheels OFF the ground using a flatbed.
MAINTAINING YOUR VEHICLE CONTENTS 䡵 ENGINE COMPARTMENT — 3.6L . . . . . . . . . .633 ▫ Engine Air Cleaner Filter . . . . . . . . . . . . . . . .641 䡵 ONBOARD DIAGNOSTIC SYSTEM — OBD II . .634 ▫ Exhaust System . . . . . . . . . . . . . . . . . . . . . .642 ▫ Loose Fuel Filler Cap Message . . . . . . . . . . . .634 ▫ Maintenance-Free Battery . . . . . . . . . . . . . . .644 䡵 EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . .
632 MAINTAINING YOUR VEHICLE ▫ Appearance Care And Protection From Corrosion . . . . . . . . . . . . . . . . . . . . . . . . . . .659 ▫ Cleaning The Instrument Panel Cupholders . .665 䡵 FUSES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .666 ▫ Totally Integrated Power Module (Fuses) . . . .666 䡵 VEHICLE STORAGE . . . . . . . . . . . . . . . . . . . .674 䡵 REPLACEMENT BULBS . . . . . . . . . . . . . . . . .674 䡵 BULB REPLACEMENT . . . . . . . . . . . . . . . . . .
MAINTAINING YOUR VEHICLE 633 ENGINE COMPARTMENT — 3.
634 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated Onboard Diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emissions well within current government regulations.
MAINTAINING YOUR VEHICLE 635 Loose Fuel Filler Cap Message EMISSIONS INSPECTION AND MAINTENANCE If the vehicle diagnostic system determines that the fuel PROGRAMS filler cap is loose, improperly installed, or damaged, a In some localities, it may be a legal requirement to pass “gASCAP” message will display in the odometer or a an inspection of your vehicle’s emissions control system. “CHECK GASCAP” message will be displayed in the Failure to pass could prevent vehicle registration.
636 MAINTAINING YOUR VEHICLE Your vehicle has a simple ignition actuated test, which you can use prior to going to the test station. To check if your vehicle’s OBD II system is ready, you must do the following: the ignition or start the engine. This means that your vehicle’s OBD II system is not ready and you should not proceed to the I/M station. • The MIL will not flash at all and will remain fully illuminated until you place the ignition in the off position or start the engine.
MAINTAINING YOUR VEHICLE 637 before going to the I/M station. The I/M station can fail NOTE: Intentional tampering with emissions control your vehicle because the MIL is on with the engine systems may void your warranty and could result in civil penalties being assessed against you. running. REPLACEMENT PARTS Use of genuine MOPAR parts for normal/scheduled maintenance and repairs is highly recommended to ensure the designed performance.
638 MAINTAINING YOUR VEHICLE Besides those maintenance items specified in the fixed “Maintenance Schedule”, there are other components which may require servicing or replacement in the future. CAUTION! • Failure to properly maintain your vehicle or perform repairs and service when necessary could result in more costly repairs, damage to other components or negatively impact vehicle performance. Immediately have potential malfunctions examined by an authorized dealer or qualified repair center.
MAINTAINING YOUR VEHICLE 639 dipstick. Adding one quart of oil when the reading is at Engine Oil Selection the MIN mark will result in a MAX reading on these For best performance and maximum protection under all engines. types of operating conditions, the manufacturer only recommends engine oils that are API Certified and meet CAUTION! the requirements of FCA US Material Standard MS-6395. Overfilling or underfilling will cause oil aeration, or loss of oil pressure. This could damage your engine.
640 MAINTAINING YOUR VEHICLE CAUTION! Do not use chemical flushes in your engine oil as the chemicals can damage your engine. Such damage is not covered by the New Vehicle Limited Warranty. Engine Oil Viscosity — 3.6L Engine NOTE: MOPAR SAE 5W-30 engine oil approved to FCA US Material Standard MS-6395 such as Pennzoil, Shell Helix or equivalent may be used when SAE 5W-20 engine oil meeting MS-6395 is not available.
MAINTAINING YOUR VEHICLE 641 quality filters should be used to assure most efficient service. MOPAR engine oil filters are a high quality oil Care should be taken in disposing of used engine oil and filter and are recommended. oil filters from your vehicle. Used oil and oil filters, indiscriminately discarded, can present a problem to the Engine Air Cleaner Filter environment.
642 MAINTAINING YOUR VEHICLE Engine Air Cleaner Filter Selection The quality of replacement engine air cleaner filters varies considerably. Only high quality filters should be used to assure most efficient service. MOPAR engine air cleaner filters are a high quality filter and are recommended. Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system.
MAINTAINING YOUR VEHICLE 643 CAUTION! • The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emissions control device and may seriously reduce engine performance and cause serious damage to the engine. • Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition.
644 MAINTAINING YOUR VEHICLE To minimize the possibility of catalytic converter damage: • Do not shut off the engine or interrupt the ignition, when the transmission is in gear and the vehicle is in motion. • Do not try to start the engine by pushing or towing the vehicle. • Do not idle the engine with any spark plug wires disconnected or removed, such as when diagnostic testing, or for prolonged periods during very rough idle or malfunctioning operating conditions.
MAINTAINING YOUR VEHICLE 645 CAUTION! • It is essential when replacing the cables on the battery that the positive cable is attached to the positive post and the negative cable is attached to the negative post. Battery posts are marked positive (+) and negative (-) and are identified on the battery case. Cable clamps should be tight on the terminal posts and free of corrosion.
646 MAINTAINING YOUR VEHICLE CAUTION! Do not use chemical flushes in your air conditioning system as the chemicals can damage your air conditioning components. Such damage is not covered by the New Vehicle Limited Warranty. Refrigerant Recovery And Recycling R-134a Air Conditioning Refrigerant is a hydrofluorocarbon (HFC) that is endorsed by the Environmental Protection Agency and is an ozone-saving product.
MAINTAINING YOUR VEHICLE 647 4. Disengage the two retaining tabs that secure the filter cover to the HVAC housing, and remove the cover. cover, make sure the retaining tabs fully engage the cover. CAUTION! The A/C air filter is identified with an arrow to indicate airflow direction through the filter. Failure to properly install the filter will result in the need to replace it more often. 7. Rotate the glove compartment door back into position.
648 MAINTAINING YOUR VEHICLE should be wiped clean to remove dust and grit; after lubricating excess oil and grease should be removed. Particular attention should also be given to hood latching components to ensure proper function. When performing other underhood services, the hood latch, release mechanism and safety catch should be cleaned and lubricated. Operation of the wipers on dry glass for long periods may cause deterioration of the wiper blades.
MAINTAINING YOUR VEHICLE 649 Fill the reservoir with windshield washer solvent (not with water as directed on the container, aids cleaning radiator antifreeze) and operate the system for a few action, reduces the freezing point to avoid line clogging, seconds to flush out any residual water. and is not harmful to paint or trim. The washer fluid reservoir will hold a full gallon of fluid Cooling System when the Low Washer Fluid Light illuminates.
650 MAINTAINING YOUR VEHICLE If the cap is sealing properly, the engine coolant (antifreeze) will begin to drain from the coolant recovery Check the engine coolant (antifreeze) protection every 12 bottle. DO NOT REMOVE THE COOLANT PRESSURE months (before the onset of freezing weather, where CAP WHEN THE COOLING SYSTEM IS HOT. applicable).
MAINTAINING YOUR VEHICLE 651 Selection Of Coolant CAUTION! (Continued) Refer to “Fluids, Lubricants, And Genuine Parts” in “Maintaining Your Vehicle” for further information. CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection.
652 MAINTAINING YOUR VEHICLE miles (240,000 km) before replacement. To prevent reduc- • Use only high purity water such as distilled or deioning this extended maintenance period, it is important that ized water when mixing the water/engine coolant (antifreeze) solution. The use of lower quality water you use the same engine coolant (OAT coolant conformwill reduce the amount of corrosion protection in the ing to MS.90032) throughout the life of your vehicle. engine cooling system.
MAINTAINING YOUR VEHICLE 653 HOAT and OAT coolant are mixed in an emergency, have a authorized dealer drain, flush, and refill with OAT coolant (conforming to MS.90032) as soon as possible. Cooling System Pressure Cap The cap must be fully tightened to prevent loss of engine coolant (antifreeze), and to ensure that engine coolant (antifreeze) will return to the radiator from the coolant recovery tank. WARNING! (Continued) an overheated engine. Heat causes pressure to build up in the cooling system.
654 MAINTAINING YOUR VEHICLE puddles on the ground. If ingested by a child or pet, seek When additional engine coolant (antifreeze) is needed to emergency assistance immediately. Clean up any ground maintain the proper level, only OAT coolant that meets the requirements of FCA Material Standard MS.90032 spills immediately. should be added to the coolant bottle. Do not overfill.
MAINTAINING YOUR VEHICLE 655 the coolant expansion bottle. If engine coolant (anti- • Do not change the thermostat for Summer or Winter freeze) needs to be added, the contents of the coolant operation. If replacement is ever necessary, install ONLY the correct type thermostat. Other designs may expansion bottle must also be protected against freezresult in unsatisfactory engine coolant (antifreeze) ing.
656 MAINTAINING YOUR VEHICLE WARNING! (Continued) high brake temperatures, excessive lining wear, and possible brake damage. You would not have your full braking capacity in an emergency. Master Cylinder — Brake Fluid Level Check The fluid level in the master cylinder should be checked when performing underhood services, or immediately if the “Brake System Warning Light” indicates system failure. Clean the top of the master cylinder area before removing the cap.
MAINTAINING YOUR VEHICLE 657 WARNING! (Continued) WARNING! (Continued) • To avoid contamination from foreign matter or moisture, use only new brake fluid or fluid that has been in a tightly closed container. Keep the master cylinder reservoir cap secured at all times. Brake fluid in a open container absorbs moisture from the air resulting in a lower boiling point. This may cause it to boil unexpectedly during hard or prolonged braking, resulting in sudden brake failure. This could result in a collision.
658 MAINTAINING YOUR VEHICLE CAUTION! Using a transmission fluid other than the manufacturer’s recommended fluid may cause deterioration in transmission shift quality and/or torque converter shudder, and will require more frequent fluid and filter changes. Refer to “Fluids, Lubricants, And Genuine Parts” in this section for fluid specifications. Special Additives leaks. Avoid using transmission sealers as they may adversely affect seals.
MAINTAINING YOUR VEHICLE 659 your authorized dealer immediately to have the trans- Appearance Care And Protection From Corrosion mission fluid level checked. Operating the vehicle with Protection Of Body And Paint From Corrosion an improper fluid level can cause severe transmission Vehicle body care requirements vary according to geodamage. graphic locations and usage.
660 MAINTAINING YOUR VEHICLE • If insects, tar, or other similar deposits have accumulated on your vehicle, use MOPAR Super Kleen Bug Corrosion is the result of deterioration or removal of and Tar Remover to remove. paint and protective coatings from your vehicle. • Use a high quality cleaner wax, such as MOPAR The most common causes are: Cleaner Wax to remove road film, stains and to protect • Road salt, dirt and moisture accumulation. your paint finish. Take care never to scratch the paint.
MAINTAINING YOUR VEHICLE 661 • If you carry special cargo such as chemicals, fertilizers, de-icer salt, etc., be sure that such materials are well • If you drive on salted or dusty roads or if you drive packaged and sealed. near the ocean, hose off the undercarriage at least once a month. • If a lot of driving is done on gravel roads, consider mud or stone shields behind each wheel.
662 MAINTAINING YOUR VEHICLE • For aluminum wheels, use MOPAR Wheel Cleaner or • Blot any remaining stain with a clean, damp towel. equivalent. • For tough stains, apply MOPAR Total Clean, or a mild soap solution to a clean, damp cloth and remove stain. CAUTION! Use a fresh, damp towel to remove soap residue. Do not use scouring pads, steel wool, a bristle brush, • For grease stains, apply MOPAR Multi-Purpose or metal polishes. Do not use oven cleaner. These Cleaner to a clean, damp cloth and remove stain.
MAINTAINING YOUR VEHICLE 663 Your leather upholstery can be best preserved by regular cleaning with a damp soft cloth. Small particles of dirt can act as an abrasive and damage the leather upholstery and should be removed promptly with a damp cloth. Stubborn soils can be removed easily with a soft cloth and MOPAR Total Clean. Care should be taken to avoid soaking your leather upholstery with any liquid.
664 MAINTAINING YOUR VEHICLE cleaner. Use caution when cleaning the inside rear window equipped with electric defrosters or windows Your vehicle is equipped with plastic headlights and fog equipped with radio antennas. Do not use scrapers or lights that are lighter and less susceptible to stone breakother sharp instrument that may scratch the elements. age than glass headlights.
MAINTAINING YOUR VEHICLE 665 Seat Belt Maintenance WARNING! (Continued) Do not bleach, dye, or clean the belts with chemical solvents or abrasive cleaners. This will weaken the fabric. Sun damage can also weaken the fabric. assemblies must be replaced after a collision if they have been damaged (i.e., bent retractor, torn webbing, etc.). If the belts need cleaning, use MOPAR Total Clean, a mild soap solution, or lukewarm water.
666 MAINTAINING YOUR VEHICLE the liner thoroughly under warm running water. Shake the excess water from the liner and dry the outer surfaces with a clean soft cloth. Installation Place the liner into the cupholder drawer and push the liner into place so that the retention tabs seat into the corresponding openings in the drawer. FUSES WARNING! • When replacing a blown fuse, always use an appropriate replacement fuse with the same amp rating as the original fuse.
MAINTAINING YOUR VEHICLE 667 This center contains cartridge fuses and mini-fuses. A label that identifies each component may be printed or embossed on the inside of the cover. Totally Integrated Power Module CAUTION! • When installing the Totally Integrated Power Module cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Integrated Power Module, and possibly result in a electrical system failure.
668 MAINTAINING YOUR VEHICLE Cavity J1 J2 J3 J4 J5 J6 Cartridge Fuse 40 Amp Green 30 Amp Pink 30 Amp Pink 25 Amp Clear 25 Amp Clear 40 Amp Green Mini-Fuse – – – – – – J7 30 Amp Pink – J8 J9 40 Amp Green 40 Amp Green – – J10 30 Amp Pink – Description Power Folding Seat Power Liftgate Module Rear Door Module Driver Door Node Passenger Door Node Antilock Brakes Pump/Stability Control System Antilock Brakes Valve/Stability Control System Power Memory Seat – If Equipped Partial Zero Emissions Vehicl
MAINTAINING YOUR VEHICLE 669 Cavity J11 Cartridge Fuse 30 Amp Pink Mini-Fuse – J12 J13 J14 J15 J17 J18 J19 J20 J21 J22 M1 M2 M3 30 Amp Pink 60 Amp Yellow 40 Amp Green 40 Amp Green 40 Amp Green 20 Amp Blue 60 Amp Yellow 30 Amp Pink 20 Amp Blue 25 Amp Clear – – – – – – – – – – – – – 15 Amp Blue 20 Amp Yellow 20 Amp Yellow Description Power Sliding Door Module/Anti–Theft Module – If Equipped HVAC Rear Blower, Radiator Fan Motor Ignition Off Draw (IOD) – Main Rear Window Defogger Front Blower Starter Sol
670 MAINTAINING YOUR VEHICLE Cavity M5 M6 Cartridge Fuse – – Mini-Fuse 25 Amp Clear 20 Amp Yellow M7 – 20 Amp Yellow M8 M9 M10 – – – 20 Amp Yellow 20 Amp Yellow 15 Amp Blue M11 M12 M13 – – – 10 Amp Red 30 Amp Green 20 Amp Yellow Description Inverter Power Outlet #1 (ACC), Rain Sensor, Cigar Lighter (Instrument Panel or with Console Rear) Power Outlet #2 (BATT/ACC SELECT) – Center Seat or with Console Rear Front Heated Seat – If Equipped Rear Heated Seat – If Equipped Ignition Off Draw — Video S
MAINTAINING YOUR VEHICLE 671 Cavity M14 M15 Cartridge Fuse – – Mini-Fuse 20 Amp Yellow 20 Amp Yellow M16 – 10 Amp Red M17 M18 M19 M20 – – – – 15 Amp Blue 15 Amp Blue 25 Amp Clear 15 Amp Blue M21 M22 M23 – – – 20 Amp Yellow 10 Amp Red 10 Amp Red Description Trailer Tow – If Equipped Rear View Mirror, Instrument Cluster, MultiFunction Control Switch, Tire Pressure Monitor, Glow Plug Module – If Equipped Airbag Module/Occupant Classification Module Left Tail/License/Park Lamp, Running Lamps Right
672 MAINTAINING YOUR VEHICLE Cavity M24 M25 M26 M27 Cartridge Fuse – – – – Mini-Fuse 25 Amp Clear 20 Amp Yellow 10 Amp Red 10 Amp Red M28 M29 M30 M31 M32 M33 M34 – – – – – – – 10 Amp Red 10 Amp Red 15 Amp Blue 20 Amp Yellow 10 Amp Red 10 Amp Red 10 Amp Red Description Rear Wiper Fuel Pump, Diesel Lift Pump – If Equipped Power Mirror Switch, Driver Window Switch Wireless Control Module, Keyless Entry Module Powertrain, Transmission Control Module Occupant Classification Module Rear Wiper Module, Power
MAINTAINING YOUR VEHICLE 673 Cavity M35 M36 Cartridge Fuse – – Mini-Fuse 10 Amp Red 20 Amp Yellow M37 – 10 Amp Red M38 – 25 Amp Clear Description Heated Mirrors Power Outlet #3 (Instrument Panel or with Console Center) Antilock Brakes, Stability Control, Stop Lamp, Fuel Pump Door Lock/Unlock Motors, Liftgate Lock/ Unlock Motors The power windows are fused by a 25 Amp circuit • Or, disconnect the negative cable from the battery. breaker located in the Totally Integrated Power Module.
674 MAINTAINING YOUR VEHICLE REPLACEMENT BULBS Interior Bulbs Center & Rear Dome Lamp Center & Rear Reading Lamps Front Door Courtesy Lamp Front Header Reading Lamps – If Equipped Instrument Cluster Lamps Liftgate Lamp(s) Overhead Console Reading Lamps Removable Console Lamp – If Equipped Visor Vanity Lamps NOTE: For lighted switches, see your authorized dealer for replacement instructions.
MAINTAINING YOUR VEHICLE 675 Exterior Bulbs Headlamp – (Low and High Beam Halogen) Headlamp (HID – If Equipped) Low Beam Fog Lamp – If Equipped Front Side Marker Front Park/Turn Signal Rear Turn Signal Lamp Rear Tail, Stop, and Side Marker Lamp Center High-Mounted Stop Lamp Backup Lamp License Bulb Number H11LL D1S H11LL W5W PY27/7W or 3757A 3757A LED (Serviced at Authorized Dealer) LED (Serviced at Authorized Dealer) 3157 168 7
676 MAINTAINING YOUR VEHICLE BULB REPLACEMENT NOTE: Lens fogging can occur under certain atmospheric conditions. This will usually clear as atmospheric conditions change to allow the condensation to change back into a vapor. Turning the lamps on will usually accelerate the clearing process. WARNING! A transient high voltage occurs at the bulb sockets of High Intensity Discharge (HID) headlamps when the headlamp switch is turned ON.
MAINTAINING YOUR VEHICLE 677 3. Twist the headlamp bulb and pull the bulb from the 3. Push the new bulb into the socket and reinstall the headlamp housing. socket by twisting until locked into the headlamp housing. 4. Install the new headlamp bulb and twist until locked Front Side Marker Lamp into the headlamp housing. CAUTION! 1. Raise the hood to access the rear of the headlamp housing. Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life.
678 MAINTAINING YOUR VEHICLE Front Fog Lamp 2. Disconnect wire harness from the bulb. NOTE: Access to the fog lamp bulb is from the rear of 3. Reconnect the wiring harness to the new bulb and the fascia. On the left rear side of the fascia, remove the reinstall the bulb by twisting clockwise. push pin and lower the hinged access door on the air Rear Turn Signal And Backup Lamp dam. 1. Raise the liftgate. 1.
MAINTAINING YOUR VEHICLE 679 NOTE: • If a screwdriver is used, make sure a soft material is placed between the vehicle body and tool so not to scratch the paint. • The PRY location is best closest to the studs while dislodging them separately. 3. Twist the socket and remove it from the lamp assembly. 4. Pull the bulb to remove it from the socket. Tail Lamp Mounting Screws 5. Replace the bulb, reinstall the socket, and reattach the lamp assembly.
680 MAINTAINING YOUR VEHICLE Center High-Mounted Stop Lamp (CHMSL) 2. Twist and remove the socket from the lamp assembly and pull the bulb out to remove. The CHMSL uses LED lamps that are not serviceable separately. The CHMSL must be replaced as an assembly, 3. Push the bulb into the socket, twist the socket into the see your authorized dealer. lamp assembly and reinstall the lamp assembly into place ensuring the locking tab is secure.
MAINTAINING YOUR VEHICLE 681 FLUID CAPACITIES U.S. Metric Fuel (Approximate) 20 Gallons 76 Liters Engine Oil with Filter 3.6L Engine (SAE 5W-20, API Certi6 Quarts 5.6 Liters fied). Cooling System * 3.6L Engine (MOPAR Antifreeze/ 13.4 Quarts 12.6 Liters Engine Coolant 10 Year/150,000 Mile Formula or equivalent) meeting the requirements of FCA Material Standard MS.90032. * Includes heater and coolant recovery bottle filled to MAX level. Add 2.9 Quarts (2.8 Liters) if equipped with a rear heater.
682 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Engine Oil Filter Spark Plugs Fuel Selection Fluid, Lubricant, or Genuine Part We recommend you use MOPAR Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Technology) meeting the requirements of FCA Material Standard MS.90032.
MAINTAINING YOUR VEHICLE 683 CAUTION! CAUTION! (Continued) • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze) or any “globally compatible” coolant (antifreeze).
684 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part Use Only ATF+4 Automatic Transmission Fluid. Failure to use ATF+4 fluid may affect the function or performance of your transmission. We recommend MOPAR ATF+4 Fluid. We recommend you use MOPAR DOT 3. If DOT 3 brake fluid is not available, then DOT 4 is acceptable. We recommend you use MOPAR Power Steering Fluid +4, MOPAR ATF+4 Automatic Transmission Fluid.
MAINTENANCE SCHEDULES CONTENTS 䡵 MAINTENANCE SCHEDULE . . . . . . . . . . . . .686 ▫ Maintenance Chart . . . . . . . . . . . . . . . . . . . .
686 MAINTENANCE SCHEDULES than your authorized dealer, the message can be reset by referring to the steps described under “Electronic Vehicle Your vehicle is equipped with an automatic oil change Information Center (EVIC)” in “Understanding Your indicator system. The oil change indicator system will Instrument Panel” for further information. remind you that it is time to take your vehicle in for scheduled maintenance.
MAINTENANCE SCHEDULES 687 Once A Month Or Before A Long Trip: • Check engine oil level. • Check windshield washer fluid level. • Check the fluid levels of the coolant reservoir, brake master cylinder, and power steering and fill as needed. • Check function of all interior and exterior lights. Required Maintenance Intervals. • Check tire pressure and look for unusual wear or damage.
688 MAINTENANCE SCHEDULES Maintenance Chart Additional Inspections Inspect the CV joints. Inspect front suspension, tie rod ends, boot seals, and replace if necessary. Inspect the brake linings, replace as necessary.
Additional Maintenance Replace engine air filter. Replace cabin/air conditioning filter. Replace spark plugs (3.6L engine). ** Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first.
Change automatic transmission fluid and filter if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing. Change automatic transmission fluid and filter. Inspect and replace PCV valve if necessary.
MAINTENANCE SCHEDULES 691 WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic. • Failure to properly inspect and maintain your vehicle could result in a component malfunction and effect vehicle handling and performance. This could cause an accident.
IF YOU NEED CONSUMER ASSISTANCE CONTENTS 䡵 SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE . . . . . . . . . . . . . . . . . . . . . . .695 ▫ Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY). . . . . . . . . . . . . . . . . . .697 ▫ Prepare For The Appointment. . . . . . . . . . . . .695 ▫ Service Contract . . . . . . . . . . . . . . . . . . . . . .697 ▫ Prepare A List . . . . . . . . . . . . . . . . . . . . . . . .695 䡵 WARRANTY INFORMATION . . . . . . . . . . . . .
694 IF YOU NEED CONSUMER ASSISTANCE 䡵 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES . . . . . . . . . . . . . . . . .701 ▫ Treadwear. . . . . . . . . . . . . . . . . . . . . . . . . . .701 ▫ Traction Grades . . . . . . . . . . . . . . . . . . . . . . .701 ▫ Temperature Grades. . . . . . . . . . . . . . . . . . . .
IF YOU NEED CONSUMER ASSISTANCE 695 SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment Be Reasonable With Requests If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with the service advisor and list the items in order of priority. At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it is advisable to make these arrangements when you call for an appointment.
696 IF YOU NEED CONSUMER ASSISTANCE facilities, factory-trained technicians, special tools, and • Authorized dealer name the latest information to ensure the vehicle is fixed • Vehicle Identification Number (VIN) correctly and in a timely manner. • Vehicle delivery date and mileage This is why you should always talk to an authorized dealer service manager first. Most matters can be re- FCA US LLC Customer Center solved with this process. P.O.
IF YOU NEED CONSUMER ASSISTANCE 697 Mexico, D. F. Canadian residents with hearing difficulties that require assistance can use the special needs relay service offered by Bell Canada. For TTY teletypewriter users, dial 711 and for Voice callers, dial 1-800-855-0511 to connect with a Bell Relay Service operator.
698 IF YOU NEED CONSUMER ASSISTANCE The manufacturer will not stand behind any service contract that is not the manufacturer’s service contract. It is not responsible for any service contract other than the manufacturer’s service contract. If you purchased a service contract that is not a manufacturer’s service contract, and you require service after the manufacturer’s New Vehicle Limited Warranty expires, please refer to the contract documents, and contact the person listed in those documents.
IF YOU NEED CONSUMER ASSISTANCE 699 campaign. However, NHTSA cannot become involved in individual problems between you, your authorized MOPAR fluids, lubricants, parts, and accessories are dealer, and the manufacturer. available from an authorized dealer. They are recommended for your vehicle in order to help keep the vehicle To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1-888-327-4236 (TTY: 1-800-424-9153), operating at its best. or go to http://www.safercar.
700 IF YOU NEED CONSUMER ASSISTANCE PUBLICATION ORDER FORMS To order the following manuals, you may use either the website or the phone numbers listed below. Visa, Mastercard, American Express, and Discover orders are accepted. If you prefer mailing your payment, please call for an order form. Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with diagrams, charts and detailed illustrations.
IF YOU NEED CONSUMER ASSISTANCE 701 Call toll free at: Treadwear • 1-800-890-4038 (U.S.) The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half times as well on the government course as a tire graded 100.
702 IF YOU NEED CONSUMER ASSISTANCE WARNING! The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning, or peak traction characteristics. Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
INDEX 10
704 INDEX About Your Brakes . . . . . . . . . . . . . . . . . . . . . . . .511 Adding Engine Coolant (Antifreeze) . . . . . . . . . . . .651 Adding Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . .567 Adding Washer Fluid . . . . . . . . . . . . . . . . . . . . . .648 Additives, Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . .562 Adjustable Pedals . . . . . . . . . . . . . . . . . . . . . . . . .245 Air Bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INDEX 705 Alterations/Modifications, Vehicle . . . . . . . . . . . . . . .7 Antenna, Satellite Radio. . . . . . . . . . . . . . . . . . . . .398 Antifreeze (Engine Coolant). . . . . . . . . . . . . . .651, 681 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .653 Anti-Lock Brake System (ABS) . . . . . . . . . . . . . . . .512 Anti-Lock Warning Light . . . . . . . . . . . . . . . . . . . .346 Appearance Care . . . . . . . . . . . . . . . . . . . . . . . . .659 Ashtray . . . . . . . . . . .
706 INDEX Anti-Lock (ABS) . . . . . . . . . . . . . . . . . . . . . . . .511 Fluid Check . . . . . . . . . . . . . . . . . . . . . . . . . . .656 Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .508 Warning Light . . . . . . . . . . . . . . . . . . . . . . . . .331 Brake/Transmission Interlock . . . . . . . . . . . . . . . . .494 Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . . . .676 Bulbs, Light . . . . . . . . . . . . . . . . . . . . . . . . . .
INDEX 707 Installing Child Restraints Using The Vehicle Seat Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115 Lower Anchors And Tethers For Children . . . . . .107 Older Children And Child Restraints . . . . . . . . .103 Seating Positions . . . . . . . . . . . . . . . . . . . . . . . .106 Using The Top Tether Anchorage . . . . . . . . . . . .121 Child Safety Locks . . . . . . . . . . . . . . . . . . . . . . . . .55 Clean Air Gasoline . . . . . . . . . . . . . . . . . . . . . . . .
708 INDEX Radiator Cap . . . . . . . . . . . . . . . . . . . . . . . . . .653 Selection Of Coolant (Antifreeze) . . . . . .651, 681, 682 Corrosion Protection . . . . . . . . . . . . . . . . . . . . . . .659 Cruise Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . .354 Cupholders . . . . . . . . . . . . . . . . . . . . . . . . . .285, 665 Customer Assistance . . . . . . . . . . . . . . . . . . . . . . .695 Disposal Antifreeze (Engine Coolant) . . . . . . . . . . . . . . . .653 Door Ajar. . . .
INDEX 709 Electric Remote Mirrors . . . . . . . . . . . . . . . . . . . . .140 Electronic Brake Control System . . . . . . . . . . . . . . .511 Anti-Lock Brake System . . . . . . . . . . . . . . . . . .512 Traction Control System . . . . . . . . . . . . . . . . . . .518 Electronic Speed Control (Cruise Control) . . . . . . . .247 Electronic Stability Control (ESC) . . . . . . . . . . . . . .518 Electronic Throttle Control Warning Light . . . . . . . .336 Electronic Vehicle Information Center (EVIC) . . . .
710 INDEX Event Data Recorder . Exhaust Gas Caution Exhaust System . . . . Exterior Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98 .125, 563 .125, 642 .128, 674 Filters Air Cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . .641 Air Conditioning . . . . . . . . . . . . . . . . . . . .479, 646 Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . .
INDEX 711 Clean Air . . . . . . . . . . . . . . . . . . . . . . . . . . . . .560 Conserving . . . . . . . . . . . . . . . . . . . . . . . . . . . .362 Economy Mode . . . . . . . . . . . . . . . . . . . . . . . .494 Ethanol . . . . . . . . . . . . . . . . . . . . . . . . . . .560, 564 Filler Cap (Gas Cap) . . . . . . . . . . . . . . . . . . . . .567 Gasoline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .559 Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
712 INDEX Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Ignition Key Removal . . . . . . . . . . . . . . . . . . . . . . .13 Illuminated Entry . . . . . . . . . . . . . . . . . . . . . . . . . .20 Immobilizer (Sentry Key) . . . . . . . . . . . . . . . . . . . .15 Information Center, Vehicle . . . . . . . . . . . . . . . . . .355 Inside Rearview Mirror . . . . . . . . . . . . . . . . . . . . .138 Instrument Cluster . . . . . . . . . . . . . . . . . .
INDEX 713 Jump Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . .622 Life Of Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . .546 Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57 Light Bulbs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128 Key Fob Arm The Alarm . . . . . . . . . . . . . . . . . . . . . . . . .18 Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128, 229 Air Bag . . . . . . . . . . . . . . . . . . . . . . .
714 INDEX Headlights On Reminder . . . . . . . . . . . . . . . . . .232 High Beam/Low Beam Select . . . . . . . . . . . . . . .236 Illuminated Entry . . . . . . . . . . . . . . . . . . . . . . . .20 Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .232 License . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .680 Lights On Reminder . . . . . . . . . . . . . . . . . . . . .232 Low Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INDEX 715 Memory Feature (Memory Seat) . . . . . . . . . . . . . . .223 Memory Seat . . . . . . . . . . . . . . . . . . . . . . . . .141, 223 Methanol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .560 Mini-Trip Computer . . . . . . . . . . . . . . . . . . . . . . .363 Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138 Automatic Dimming . . . . . . . . . . . . . . . . . . . . .139 Electric Remote . . . . . . . . . . . . . . . . . . . . . . . . .140 Exterior Folding . .
716 INDEX Oil Filter, Change . . . . . . . . . . . . . . . . . . . . . . . . .641 Placard, Tire And Loading Information . . . . . . . . . .532 Oil Filter, Selection . . . . . . . . . . . . . . . . . . . . . . . .641 Power Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .511 Oil Pressure Light . . . . . . . . . . . . . . . . . . . . . . . . .338 Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Onboard Diagnostic System . . . . . . . . . . . . . . . . . .634 Lift Gate .
INDEX 717 Radial Ply Tires . . . . . . . . . . . . . . . . . . . . . . . . . .539 Radiator Cap (Coolant Pressure Cap) . . . . . . . . . . .653 Radio Operation . . . . . . . . . . . . . . . . . . . . . . . . . .459 Radio Remote Controls . . . . . . . . . . . . . . . . . . . . .457 Rear Air Conditioning. . . . . . . . . . . . . . . . . . .465, 474 Rear Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . .260 Rear Cross Path . . . . . . . . . . . . . . . . . . . . . . . . . .150 Rear Heater . . . . .
718 INDEX Safety Checks Outside Vehicle . . . . . . . . . . . . . . . .128 Seat Belt Reminder . . . . . . . . . . . . . . . . . . . . . . . . .64 Safety Defects, Reporting . . . . . . . . . . . . . . . . . . . .699 Seat Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . .63, 126 Adjustable Shoulder Belt . . . . . . . . . . . . . . . . . . .71 Safety, Exhaust Gas . . . . . . . . . . . . . . . . . . . . . . . .125 Adjustable Upper Shoulder Anchorage . . . . . . . . .71 Safety Information, Tire . . .
INDEX 719 Reclining . . . . . . . . . . . . . . . . . . . . . . . . . . . . .199 Stow ⬘N Go (Fold in Floor) . . . . . . . . . . . . . . . .205 Security Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . .339 Arm The System . . . . . . . . . . . . . . . . . . . . . . . .18 Disarm The System . . . . . . . . . . . . . . . . . . . . . . .18 Tamper Alert . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Selection Of Coolant (Antifreeze) . . . . . . . . . . . . . .
720 INDEX Wheel, Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . .242 Tire Markings . . . . . . . . . . . . . . . . . . . . . . . . . . . .524 Steering Wheel Audio Controls . . . . . . . . . . . . . . .457 Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . .128, 536, 701 Aging (Life Of Tires) . . . . . . . . . . . . . . . . . . . . .546 Steering Wheel Mounted Sound System Controls . . .457 Air Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . .536 Storage . . . . . . . . . .
INDEX 721 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . .524, 536 Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .525 Snow Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . .541 Spare Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . .604 Spinning . . . . . . . . . . . . . . . . . . . . . . . . . . . . .544 Trailer Towing . . . . . . . . . . . . . . . . . . . . . . . . .580 Tread Wear Indicators . . . . . . . . . . . . . . . . . . . .
722 INDEX Transmitter Battery Service (Remote Keyless Entry) . .28 Transmitter, Garage Door Opener (HomeLink) . . . . .267 Transmitter, Remote Keyless Entry (RKE) . . . . . . . . .21 Transporting Pets . . . . . . . . . . . . . . . . . . . . . . . . .123 Tread Wear Indicators . . . . . . . . . . . . . . . . . . . . . .545 Turn Signals . . . . . . . . . . . . . . . . . . . . . .351, 677, 678 UCI Connector . . . . . . . . . . . . . . . . . . . Uconnect Advanced Phone Connectivity . . . . . .
INDEX 723 System Operation . . . . . . . . . . . . . . . . . . . . . . .185 Windshield Defroster. . . . . . . . . . . . . . . . . . . . . . .127 Voice Training . . . . . . . . . . . . . . . . . . . . . . . . .191 Windshield Washers . . . . . . . . . . . . . . . . . . . .238, 648 Voice Recognition System (VR) . . . . . . . . . . . . . . . .185 Windshield Wiper Blades . . . . . . . . . . . . . . . . . . . .648 Wiper Blade Replacement . . . . . . . . . . . . . . . . . . .648 Warning Flasher, Hazard . . . . .
INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s electronic system to provide immunity to radio frequency signals. Mobile two-way radios and telephone equipment must be installed properly by trained personnel. The following must be observed during installation. The positive power connection should be made directly to the battery and fused as close to the battery as possible.
STICK WITH THE SPECIALISTS® 16Y531-126-AA ©2015 FCA US LLC. All Rights Reserved. Chrysler is a registered trademark of FCA US LLC. First Edition Printed in U.S.A.
