Upgrading The Computer
Upgrading the Hard Disk Drive 6 - 5
6
3. Carefully (a fan and cable are attached to the under side of the cover) lift up
the bay cover.
4. Carefully disconnect the fan cab le , and remove the cover .
5. Remove screws - from the hard disk cover.
8 9
8
8
9
Fan Cable
Make sure you recon-
nect the fan cable
before screwing down
the bay cover.
Figure 6 - 3
Bay Cover Removal
Figure 6 - 4
Hard Disk Assembly
Screws
8
10 11
10
11
