Quick Start Guide
LED Indicators 1 - 7
1
LED Indicators
The LED indicators on the computer display helpful information about the current status of the computer.
Table 1 - 2 - LED Indicators
Icon Color Description Icon Color Description
Green The Computer is On Orange The Battery is Charging
Blinking
Green
The Computer is In Sleep Mode
Blinking
Orange
The Battery has Reached Critically Low
Power Status
Orange The AC/DC Adapter is Plugged In Green The Battery is Fully Charged
Green Number Lock is Activated Green Hard Disk Activity
Green Caps Lock is Activated Orange The Bluetooth Module is Powered On
Green Scroll Lock is Activated Green The WLAN Module is Powered On
