Specifications
Specifications C - 5
C
Communication Built-In 56K Fax Modem
Built-In 10/100/1000Mb Base-TX Ethernet LAN
Intel® WiFi Link 5300 Series (3*3 - 802.11a/g/n) Wireless LAN Mini-Card Module (
Option
)
Intel® WiFi Link 5100 Series (1*2 - 802.11a/g/n) Wireless LAN Mini-Card Module (
Option
)
3rd Party 802.11b/g Wireless LAN Mini-Card Module with USB interface (Option)
Bluetooth 2.0 + EDR (Enhanced Data Rate) Module (Factory Option)
1.3M or 2.0M Pixel PC Camera Module with USB interface (Factory Option )
3.5G Module
:
UMTS/HSPDA-based 3.5G Mini-Card Module with USB Interface (Factory Option)
Quad-band GSM/GPRS (850 MHz, 900 MHz, 1800 MHz, 1900 MHz)
UMTS WCDMA FDD (2100 MHz)
Operating
Systems
Supported
Windows XP SP3 Windows Vista 64bit SP1
Home Premium/ Business/ Enterprise/ Ultimate
Power
Management
Supports ACPI 3.0 Supports Resume from Modem Ring
Supports Wake on LAN
Feature Specification
UMTS Modes
Note that UMTS modes CAN NOT be used in North America.
