Owner manual

LED Board 80H033215-005 ver. A0~A2
User’s Manual
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: [phone] Fax: [phone] Email: [e-mail]
8
www.chenbro.com
Chassis Assembly Example
Example for RM21508B Mini-SAS backplane wiring
HDD8 HDD7 HDD6 HDD5
HDD4 HDD3 HDD2 HDD1
Mini-SAS cable
LED board signal cable
Chassis fan wiring
(Connecting start from Fan1)
Chassis Fan x4
LED Board
HBA / RAID Card
CN4 jumper set
on
p
ins 1 & 2
CN4 jumper set
on
p
ins 3 & 4
