Hardware Specification
Specification
Display
LED indicates HDD status (Defined by Chenbro)
Power LED – Blue ( When HDD is present )
Access LED –Green (When HDD is busy )
Error indicator – Red (Error when retreating signals )
Alarm Buzzer & LED (Red)
Connectors & Switches
Backplane signal connector
Motherboard signal connector
Motherboard USB 2.0 connector
External USB 2.0 Port
Power supply alarm signal connector
Power supply alarm mute connector
Power On/Off Switch
System Reset Switch
Alarm Mute Switch
Function DIP Switch
Dimension 104 (L) x 43 (W) x 1.6 (Thickness) mm
Material FR4 4layer
Alarm Buzzer & LED (Red)
Accommodation Chassis
z RM21508B
z RM31212B
z RM41416B
