5.0 SPECIFICATIONS
5.1 General Specifications
Calibration According to factory procedure
Accuracy For 10% to 100% of range: ± 1% Full Scale
Other calibration material: ± 3% Full Scale or
better
Overload Protection 100% of range
Measuring Principle Strain gauge bridge
Meas. Roller Deflection 0.5 mm, max.
Natural Frequency of
Measuring Spring Approx. 500 Hz, depending on tension range
Signal Processing Analog
Output Signal 0 - 1 V DC, impedance: > 5 kOhm (standard)
Option Code DC 0 - 10 V DC
Damping (fg) Standard: approx. 30 Hz (other values on
request)
Temperature Coefficient Zero point: less than ± 0.05% FS* / °C
Temperature Range 10 – 45 °C
Air Humidity 85% RH, max.
Power Supply 15 to 24 V DC (21mA) (regulated)
Option code A3: max. 50 mA
Housing Aluminium
