TMT-425 / TMT-425-USB TEXTILE MOISTURE METER OPERATING INSTRUCTIONS
13.0 WARRANTY TABLE OF CONTENTS Electromatic Equipment Co., Inc. (Electromatic) warrants to the original purchaser that this product is of merchantable quality and confirms in kind and quality with the descriptions and specifications thereof.
1.0 POWERING ON 12.0 Turn the gauge on: keep the key pressed for three seconds. If a menu item will exit or the rolling menu until the measuring window is be shown, press displayed. 2.
10.0 IMPORTANT INFORMATION 3.0 Common reasons for incorrect measurements: • • • • • Product temperature out of application range Material below 0°C resp. above +40°C (32 to 104 °F ) may cause faulty measurements. The storage of cold material in a warm storage area usually creates condensed water which may lead to major measuring errors. Not adjusted temperature of the device Make sure that your measuring gauge and the test material are stored under the same temperature conditions.
4.0 VIEW OF THE INSTRUMENT 8.0 DEVICE MAINTENANCE INSTRUCTION Do not drop the instrument or expose it to excessive temperatures. Clean it only with fuzz-free, dry cloth. The device is not waterproof. For more information www.checkline.com Electrodes concerning the treatment of the device, see The frequency for technical check of the instrument depends on the use and required level of accuracy. Measuring head For a fee, we can also carry out a calibration at the factory.
Print data (logs): To print the stored logs, connect the supplied printer cable with the printer. Open the protective cover at the TMT-425 carefully. First insert the plug, which is closer to the plastic housing, into the gauge. Then turn the gauge on. Only then insert the other plug of the cable into the printer and turn him on by the button. The green light should blink. If this is not the case, change the batteries and try again. Press the button until the main menu is opened.
6.0 MEASURING PROCEDURE 7.0 PC CONNECTION AND DATA PRINT Important: For a correct measurement please ensure that the device has the same temperature (+/-3°) as the material under test. For that reason, let your humimeter adjust to the surrounding temperature of the material for at least half an hour before measuring (protect from direct sunlight!). 1. Switch on the device by pressing the power button ( ) for 3 sec.. 2. If desired, the calibration curves can be changed by using the arrow keys. 3.
