6.30 On-Demand Data Logging Mode
When configured for On-Demand Data Logging Mode, up to 100 data points
can be stored in memory along with the calculated average and standard
deviation of the stored values. Each data point can be manually entered into
memory.
When the key is pressed the currently displayed tension reading will
be stored into memory and the memory location (a number from 1 to 100) will
momentarily flash on the display.
Note: The first time the key is pressed the“ M” indicator will flash
on and off on the LCD display. When the memory is full (100 data points in
memory), the “M” indicator will stop flashing and remain on the display.
6.31
Viewing Data Stored In On-Demand Data Logging Mode
To view data stored in Extended Memory press the key.
The following will be displayed when the key is pressed repeatedly.
Each time the key is pressed the displayed value will change.
To Store a Data Point in memory, press the key.
STORE
Action Display Will Show LCD Indicator
Press RECALL key Maximum Value MAX
Press RECALL key Minimum Value MIN
Press RECALL key Average Value “ A ”
Press RECALL key Standard Deviation “ d ”
Press RECALL key Date Point #1 “ 1 ”
Press RECALL key Data Point #2 “ 2 ”
● ● ●
● ● ●
● ● ●
Press RECALL key Data Point #100 “ 100 ”
16
STORE
STORE
RECALL
RECALL
Press the key at any time to exit the Recall Mode.
6.32 To Clear All Data Stored In The Extended Memory.
Press the key and the key simultaneously.
6.40 Continuous Data Logging Memory Mode
When configured for Continuous Data Logging Mode, up to 100 data points can
be stored in memory along with the calculated average, peak and standard
deviation values of the data stored in memory. Each displayed value is auto-
matically entered into memory at a rate equal to the selected Display Update
Rate of 0.5, 1, 2 or 4 seconds.
When the key is pressed the “M” indicator on the LCD Display will
begin to flash indicating that each displayed value is being automatically
stored in memory. The indicator will continue to flash until the key is
pressed again to stop the automatic storage or until the memory is full. The
indicator will stop flashing and remain on the display.
17
MAX
MIN
A
100 2 1
Maximum Value
Data Point 100 Data Point #2 Data Point #1
Minimum Value Average Value Standard Deviation
POWER
EXIT
STORE
RECALL
To start or stop the automatic storage of each displayed tension value into
memory, press the key.
STORE
STORE
STORE
