Owner manual

6.11 Viewing Data In Standard Memory
To view data stored in Standard Memory, press the key.
The following will be displayed when the key is pressed repeatedly.
Each time the key is pressed the displayed value with change.
Press the key at any time to exit the Recall Mode.
6.12 To Clear All Data Stored In The Standard Memory
Press the key and the key simultaneously
6.20 Standard Memory with No Auto Power Off (Standard - NAPO)
This memory mode is identical to the Standard Memory Mode detailed above,
except that when configured in this mode the power will not turn off
automatically after 90 seconds of inactivity.
MAX
MIN
PEAK
Maximum Value
Last Reading
Minimum Value Peak Value
Action Display Will Show LCD Indicator
Press RECALL key Maximum Value MAX
Press RECALL key Minimum Value MIN
Press RECALL key Peak Value PEAK
Press RECALL key Last Reading none
RECALL
RECALL
POWER
EXIT
STORE
RECALL
15
6.41 Viewing Data In Continuous Data Logging Mode
To view data stored in the Extended Memory press the key
The following will be displayed when the key is pressed repeatedly.
Each time the key is pressed the displayed value will change.
Press the key at any time to exit the Recall Mode.
6.42
To Clear All Data Stored In The Extended Memory.
Press the key and the key simultaneously.
18
Action Display Will Show LCD Indicator
Press RECALL key Maximum Value MAX
Press RECALL key Minimum Value MIN
Press RECALL key Peak Value “ P ”
Press RECALL key Average Value “ A ”
Press RECALL key Standard Deviation “ d ”
Press RECALL key Date Point #1 “ 1 ”
Press RECALL key Data Point #2 “ 2 ”
● ● ●
● ● ●
● ● ●
Press RECALL key Data Point #100 “ 100 ”
MAX
MIN
A
100 2 1
Maximum Value
Data Point 100 Data Point #2 Data Point #1
Minimum Value
PEAK
Peak Value Average Value Standard Deviation
RECALL
RECALL
POWER
EXIT
STORE
RECALL
