Setup
3. Setup
AC Power
Each WELL Panel has an auto-ranging battery charger inside the fixture that works with an input voltage
range of 100 to 240 VAC, 50/60 Hz. To determine the power requirements for the WELL Panel, refer to the
label affixed to the product. You can also refer to the Technical Specifications
chart in this manual.
The listed current rating indicates the maximum current draw during normal operation. For more
information, download Sizing Circuit Breakers from the Chauvet website: www.chauvetprofessional.com.
AC Plug
The WELL Panel charging case comes with a power input cord terminated with a Seetronic Powerkon
connector on one end and an Edison plug on the other end (U.S. market). If the power input cord that
came with your product has no plug, or if you need the change the plug, use the table below to wire the
new plug.
Power Linking
You can link up to 11 WELL Panel products at 120 V, 19 products at 208 V, or 21 products at 230 V. Never
exceed this number. Power linking cords can be purchased separately.
Battery Charge Notes
This product is equipped with a built-in rechargeable lithium ion battery.
• Avoid depleting the battery below 10%.
• For best results, charge the battery in a temperature between 32 °F (0 °C), and 95 °F (35 °C).
• When charging the battery, keep the product at least 1 m from any open flame or hot plate.
• If the battery is completely discharged, the device cannot be turned on immediately when the charger
is connected. Allow a depleted battery to charge for a few minutes before turning on the device.
• While charging, the device may heat up. This is normal and should not affect the device’s lifespan
or performance. If the battery gets hotter than usual, the charger may stop charging.
• When charging the battery, keep the road case’s cover open.
• Always charge the battery with the product in an upright position.
• Do not charge the battery for more than 24 hours.
Storage Notes
• Store charged product(s) in a dry environment, away from direct sunlight.
• Charge or discharge the battery to approximately 50% of capacity before storage.
• Lithium-Ion batteries continue to slowly discharge (self-discharge) when not in use or while in
storage. Routinely check the battery’s charge status.
• Store the battery at temperatures between 41 °F and 68 °F (5 °C and 20 °C).
• Always connect the product to a protected circuit (a circuit breaker or fuse). Make sure
the product has an appropriate electrical ground to avoid the risk of electrocution or fire.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if the
rheostat or dimmer channel serves only as a 0 to 100% switch.
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
