Introduction
2. Introduction
Description
The WELL Panel is a completely wireless, IP65-rated, battery-powered RGBW LED fixture that can be
controlled via W-DMX, DMX, IR remote (not included), or manually from the control panel. The
WELL Panel comes with color-blending filter lens for an even diffused light and Omega brackets for easy
mounting. Its 170° rotation of the panel from the base allows for easy control of direction of light. Selectable
PWM, red shift, and dimmer settings ensure the WELL Panel is always camera-ready.
Features
• Operating modes:
• 4Ch: RGBW control
• 8Ch: dimmer, RGBW control, strobe, red shift
• 12Ch: 3-zone RGBW
• 13Ch: dimmer, RGBW control, strobe, color macros, color temperature, auto programs, auto
speed, dimmer speed mode, red shift
• 21Ch: 16-bit dimmer, 3-zone RGBW, strobe, color macros, color temperature, auto programs,
auto speed, dimmer speed mode, red shift
• A completely wireless, IP65-rated, battery powered fixture with 24-quad color (red, green, blue, and
warm white) LED that is controlled by W-DMX, IR, DMX, or control panel
• High CRI value of 90+ across different color temperatures of white
• Selectable Red Shift emulation over DMX and from the fixture display
• Selectable PWM settings
• Selectable dimming speed and curves
• Built-in color temperature presets
• RDM control over DMX for fixture setup and reporting
• Line voltage input allows fixture to operate while being charged
• Built-in power loss detection when operating under line voltage
• Wireless operation with W-DMX or IR remote (sold separately) and wired DMX operation
• Magnetic color-blending diffuser filter lens included for wider light coverage
• Omega bracket included for easy hanging options
• User-selectable hours of operation (3, 5, 8, or 12 hours) at full output with a recharge time of 4 hours
• Built-in automated programs recallable manually, or by W-DMX or DMX
• 170° rotation of the panel from the base for easy direction of light
• IP65 rating for temporary outdoor stage
