Technical Specifications
WELL Panel User Manual Rev. 2
6. Technical Specifications
Dimensions and Weight
Note: Dimensions in inches are rounded.
Power
Light Source
Photometrics
Thermal
DMX
Ordering
Length Width Height Weight
17.17 in (436 mm) 5.31 in (135 mm) 10.24 in (260 mm) 22.6 lb (10.3 kg)
Power Supply Type Range Voltage Selection
Switching (internal) 100 to 240 VAC, 50/60 Hz Auto-ranging
Parameter 120 V, 60 Hz 208 V, 60 Hz 230 V, 50 Hz
Consumption (single) 123 W 124 W 123 W
Operating Current (single) 1.029 A 0.587 A 0.532 A
Power I/O U.S./Worldwide UK/Europe
Power input connector Seetronik Powerkon Seetronik Powerkon
Power output connector Seetronik Powerkon Seetronik Powerkon
Power cord plug Edison (U.S.) Local Plug
Type Color Quantity Power Current Lifespan
LED
Red 24
1 to 3 W 500 mA 50,000 hours
Green 24
Blue 24
Warm white 24
Beam Angle Field Angle Illuminance @ 5 m
Without Filter 14° 25.6° 2,761 lux
With Filter 32.3° 58.6° 544 lux
Maximum External Temperature Cooling System
113 °F (45 °C) Convection
I/O Connector Channel Range
Wireless 4, 8, 12, 13, or 21 channels
Product Name Item Name Item Code UPC Number
WELL Panel WELLPANEL 781462220471
