Operation
WELL Panel User Manual Rev. 2
Infrared Remote Control
Infrared (IR) mode allows the product to be controlled with an infrared remote controller. The IR remote can
remotely set the product to various modes; adjust the color, speed, and sensitivity; and set the strobe.
The
WELL Panel is compatible with the IR remote (sold separately) from Chauvet.
IR Remote Operation
Be sure the IR remote is pointing directly at the product and there is nothing in between the remote and the
product.
It may be necessary to turn the product off and on again when switching from
W-DMX to IRC and vise-versa.
Automatic Mode
Automatic mode will enable the automatic programs on the product.
To turn on Automatic mode:
1. Press <AUTO> or <FADE> on the IR remote.
2. Press <+> or <-> to choose between the 5 auto programs.
To adjust the speed of the automatic program:
1. Press <SPEED> on the IR remote.
2. Press <+> or <-> to increase or decrease the speed.
Manual Color Control
To choose a specific color with the IR remote, press any number between <0> and
<9>. To manually control the RGBA percentage:
1. Press <MANUAL> on the IR remote.
2. Press <R>, <G>, <B>, or <A> (red, green, blue, or white) to choose a color.
3. Press <+> or <-> to increase or decrease the value of the selected color.
Miscellaneous Operation
To adjust the strobe rate of the program:
1. Press <STROBE> on the IR remote.
2. Press <+> or <-> to increase or decrease the strobe rate.
3. Press <STROBE> again to turn off the strobe.
To black out the lights:
• Press <BLACKOUT> on the IR remote. This will turn off all the lights until the
button is pressed again.
To adjust the output level:
1. Press <%> on the IR remote.
2. Press <+> or <-> to increase or decrease the output level.
Note: The IR remote will not respond to any inputs when the Black Out mode is activated. If the
remote does not respond when a button is pressed, try pressing <BLACK OUT>. You may have
inadvertently activated the Black Out mode.
