Operation
WELL Panel User Manual Rev. 2
Configuration (Standalone)
Use standalone configuration to operate the product without a DMX controller.
Auto Programs
Auto programs allow for dynamic blinder effects without a DMX controller.
1. Go to the Auto Show main level.
2. Select the desired auto (Auto 1–5).
3. Select the desired speed (1–100).
Static Mode
The Static mode allows for permanent dimmer and strobe presets without a DMX controller.
1. Go to the Static main level.
2. Select Fixed Color, Color Temperature, or Manual Color Mixer.
3. For Fixed Color:
Select the desired fixed color (R, G, B, W, GB, RB, RG, RGB, RW, GW, BW, RGW, RBW, GBW,
or RGBW).
For Color Temperature:
a. Select the desired color temperature (refer to the Color Temperature Chart
).
b. Set the desired output value (Dimmer <000–255>).
For Manual Color Mixer:
a. Select the desired color (Red, Green, Blue, or White).
b. Set the desired value for the selected color (000–255).
c. Repeat steps a-b until the static color is set as desired.
Red Shift
The Red Shift function allows the light in the fixture to mimic halogen lamp dimming.
1. Go to the Settings main level.
2. Select the Red Shift option.
3. Select from No (disables Red Shift function) or Yes (enables Red Shift function).
Dimmer Profiles
This setting determines how fast the output of the WELL Panel changes when you modify the output value.
This setting provides four different options to simulate the dimming curve of an incandescent lighting product.
1. Go to the Dimmer Mode main level.
2. Select a dimmer curve (Off, Dimmer 1, Dimmer 2, or Dimmer 3).
White Balance
This setting controls the maximum values for each LED color.
1. Go to the White Balance main level.
2. Select Off (uses factory default white setting) or Manual (sets a custom white balance).
a. For Manual, select a color to edit (Red, Green, Blue, or White).
b. Set the maximum value of the selected color (125–255).
c. Repeat steps a-b until the white balance is set as desired.
LED Frequency
This option changes the Pulse Width Modulation (PWM) frequency of the LEDs on the WELL Panel.
1. Go to the LED Frequency main level.
2. Select PWM Frequency (600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, or 25Khz).
The auto programs cannot be edited.
Off: The output is proportional (linear) to the dimmer channel value.
Dimmer 1-3: The output follows the dimmer value based on the corresponding dimmer
curve, DIM1 being the fastest.
