WELL Panel User Manual Rev. 2
Operation
12Ch
8Ch
4Ch
13 Red shift
000  010 No function
011  127 On
128  255 Off
Channel Function Value Percent/Setting
1Red 1 000  255 0–100%
2Green 1 000  255 0–100%
3Blue 1 000  255 0–100%
4White 1 000  255 0–100%
5Red 2 000  255 0–100%
6Green 2 000  255 0–100%
7Blue 2 000  255 0–100%
8White 2 000  255 0–100%
9Red 3 000  255 0–100%
10 Green 3 000  255 0–100%
11 Blue 3 000  255 0–100%
12 White 3 000  255 0–100%
Channel Function Value Percent/Setting
1Dimmer 000  255 0–100%
2 Dimmer fine 000  255 0–100%
3Red 000  255 0–100%
4Green 000  255 0–100%
5Blue 000  255 0–100%
6White 000  255 0–100%
7 Strobe
000  010 No function
011  255 Strobe, slow to fast
8Red shift
000  010 No function
011  127 On
128  255 Off
Channel Function Value Percent/Setting
1Red 000  255 0–100%
2Green 000  255 0–100%
3Blue 000  255 0–100%
4White 000  255 0–100%
Channel Function Value Percent/Setting
